DiViS DVR
– CAP Series
Rev. 1.2
Hardware Installation Guide
Digital Video Security System
Digital Video Recorder
www.DiViSdvr.com
Chance-i USA Corp.
*All contents of this document may change without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAP series and is the answer not in the manual?

Questions and answers

Related Manuals for Divis CAP series

Summary of Contents for Divis CAP series

  • Page 1 DiViS DVR – CAP Series Rev. 1.2 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice.

  • Page 2: Table Of Contents

    DiViS w w w . D V R . c o m INDEX 1. Specification of DiViS 2. Products and components 2-1. DVR Board 2-2. Accessories 3. Board Description 3-1. DiViS CAP2X3004 3-2. DiViS CAP2X6016 4. Installation 4-1. DiViS CAP2X3004 Installation 4-2.
  • Page 3 DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, DiViS CAP2X3004 and DiViS CAP2X6016 board. The pictures and names of the products are subject to change depending on hardware upgrade.

  • Page 4: Specification Of Divis

    Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
  • Page 5 Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. POS, Access Control, ATM Support Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.

  • Page 6: Products And Components

    DiViS w w w . D V R . c o m 2. Products and Components 2.1 DiViS CAP Series Board DiViS CAP2X3004 DiViS CAP2X6016 2.2 Accessories Reset Cable Pigtail Cable RS-485 Board RS-232C Cable Sensor Port (4ch) Sensor Port (16ch)

  • Page 7: Board Description

    DiViS w w w . D V R . c o m 3. Board Description 3-1. DiViS CAP2X3004 3-2. DiViS CAP2X6016 DiViS...

  • Page 8: Dvr Board

    . D V R . c o m 4. Installation 4-1. DiViS CAP2X3004 Installation 1) Connect camera cables to the BNC ports. 2) Sensor cable connects to Sensor port. 3) The other side of sensor cable connects to IO socket on the DVR board.

  • Page 9: Divis Cap2X6016 Installation

    DiViS w w w . D V R . c o m 4-2. DiViS CAP2X6016 Installation 4-2-1. Pigtail Type 1) 1~8 channel pigtail goes to the upper socket. 2) 9~16 channel pigtail goes to the lower socket. 3) Sensor cable connects to Sensor port.

  • Page 10: Back Panel Type

    DiViS w w w . D V R . c o m 4-2-2. Back Panel Type 1) Back panel. 2) Sensor Cable. 3) When connect cable to back panel make sure to leave one pin from each end. White cable should be facing up.

  • Page 11: Accessories

    DiViS w w w . D V R . c o m 5. Accessories 5-1. Back Panel Sensor & Relay (Digital I/O) Camera I/O Sensor Input 0~15 1~16 Camera Ground 3, 5, ~ 31, 33 Input Common 0~1 17, 18...

  • Page 12: Pigtail

    DiViS w w w . D V R . c o m 5-2. Pigtail Pigtail cable 1 ~ 4, 9 ~ 13 : Black BNC 5 ~ 8, 13 ~ 16 : White BNC 5-3. Sensor Board (4 channel) Sensor port pin number...
  • Page 13 DiViS w w w . D V R . c o m 5-5. RS232 to RS422/485 Converter * Use Rx+ and Rx- for RS 485 method. - TxData + TxData - RxData + RxData Signal 1) Connect to system’s Com port.

  • Page 14: Port Converter

    DiViS w w w . D V R . c o m 5-6. PORT Converter 5-6-1. Specification RS-232 from POS DB9 Female Input Parallel Port from POS DB25 Male RS-232 to Printer DB9 Male Serial RS-485(S) to DVR TX(+)(-), RX(+)(-), GND...

  • Page 15: Baud Rate

    DiViS w w w . D V R . c o m 10, Terminal Block - TxData + TxData - RxData + RxData Signal 11, SW1, SW2: Used in output of Parallel port 12, SW3, SW4: Used in output of Serial 5-6-3.

  • Page 16: Sound Recording

    DiViS w w w . D V R . c o m 5-7. Sound Recording After connecting Microphone, ensure that “Line In” and “Microphone In” is not muted in the Windows sound setting. It is required to have Direct X 8.0 or higher.
