DiViS DVR
(Integration)
HD-SDI & HSD1 Series
V X.XX.X
Installation and User's Guide
Digital Video Security System

Digital Video Recorder

www.DiViSdvr.com
DiViS DVR.com
*All contents of this document may change without prior notice, and actual product appearance may differ from
depicted herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-SDI Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Divis HD-SDI Series

Summary of Contents for Divis HD-SDI Series

  • Page 1: Digital Video Recorder

    DiViS DVR (Integration) HD-SDI & HSD1 Series V X.XX.X Installation and User’s Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com DiViS DVR.com *All contents of this document may change without prior notice, and actual product appearance may differ from...

  • Page 2: Table Of Contents

    8-5. Log Viewer 9. POS, Access Control Appendix 1. DVR Management 2. DB Tool 3. Direct Web 4. Tribrid DVR (HD-SDI +D1 series + IP Web Camera) 5. Tribrid DVR (HD-SDI + H.264 series + IP Web Camera ) DiViS...
  • Page 3 The DVR also works in conjunction with sensors to operate security systems: relays can close shutters or ring sirens when motion sensors are triggered, for instance. In addition, our DVR makes it possible to modify DiViS DVR settings and retrieve recorded data remotely through a network or the Internet.

  • Page 4: Specification

    This feature can be controlled remotely. · Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. · Motion Detection and Sensor Trigger Detection features make it possible to utilize more efficient recording methods, such as recording only when movement is detected.
  • Page 5 · Network Support (TCP/IP, LAN, Modem Protocol Support) DiViS supports network access, which allows administrators to login to DVR main program from DiViS-Net or Direct Web and remotely access all the features that are provided locally.

  • Page 6: Installation Notes

    There may be problems due to System Standby mode, screen saver, and energy saving features. * Due to the rapid changes of motherboards and video cards, some components with listed specifications may not work properly. Please contact technical support for the list of tested motherboards. DiViS...

  • Page 7: Driver Installation

    3. Driver Installation 3-1. HD-SDI, D1, H.264 Series Open Driver folder and run “Installer.exe”. (If O/S is 64bit, run Installer64.exe”) Click “Next” Click “Install” DiViS...
  • Page 8 The following chart is a device list for each model. Model Device List HD-SDI series DVR HDH Driver D1 series DVR HS Driver H.264 series Live H264 Capture Device Click “Install this driver software anyway” when a Windows Security message pops up. Depending on the type of board, the number of times the message pops up differs.

  • Page 9: Program Installation

    4. Program Installation Run “Setup.exe”. (Choose the language of the software to be installed.) Click “Next”. Click “Install” to install Microsoft Visual C++ 2008 Package. If this package was installed before, this installation screen will not appear. DiViS...
  • Page 10 ㆍAnyone who uses this computer [all users] : Allows all administrators to use the DVR software if there are multiple Windows user accounts available on the system – it is not accessible through limited user accounts. ㆍOnly for me[User Account Name] : Only current user account can use the DVR software. Click “Next”. DiViS...
  • Page 11 Click “Next” after selecting a folder to install the program. Choose the proper media format (NTSC or PAL) and continue by clicking “Next.” (It doesn’t matter which one is chosen for HD because it uses digital signals.) DiViS...
  • Page 12 Note: Once the Top Admin user is created, it cannot be modified from User Admin Setup. To change the username or password of Top Admin, please refer to Appendix 1. DVR Management. Click “OK” when everything is set. Choose “Yes, I want to restart my computer now” and click “Finish” to restart system. DiViS...
  • Page 13 Setup will install a Program group into the Windows Start menu for easy access to the various DiViS DVR programs DVR Main: DiViS DVR Main DVR Search: DiViS DVR Search DVR Setting: DiViS DVR Setting Utility Auth Tool: A program for discerning whether a stored original image (jpg file) has been altered.

  • Page 14: Configuration

    5. Configuration Run DiViS DVR Setting. • Disk tool: Creates a DiViS DB file system. DiViS will create its own file system to store large amount of DVR data safely in its own dedicated disk space. Note: No database changes can be made while DiViS DVR Main Program is operating.

  • Page 15: Disk Tool

    HDD list, click “Create Volume” to finalize the allocation process. What is a Volume? Volume is the unit used by the DiViS DB system. 1 volume is equivalent to 64MB of physical HD space. All image data is recorded in volume units. When assigned Volumes are full, the program will continue recording by overwriting volumes that contain the oldest previously recorded data.

  • Page 16: User Admin

    - Use Windows Key: Enables the use of keyboard commands, such as Start or Task Manager, which are disabled by default at the start of DiViS DVR Main. • Notify Login: Set duration of login time for a user when the user connects to the main by remote-client (triggered by event notification).

  • Page 17: System

    5-3. System • Site Information - Site Name: Enter name for DiViS DVR system. The name is used when sending e-mails. - Site Location: Enter location of DiViS DVR system. - DVR Information Backup: Allows users to import/export setting values. Click “Properties” to set up.
  • Page 18 - Startup Event Notify: If enabled, email notification will be sent out upon the program startup. Using reserved parameters, it is possible to send starting time (“$$2”) and assigned IP address (“$$3”). Refer to Chapter 5-7. Event Setup for more details. DiViS...
  • Page 19 Press “Properties” button to set sound configurations. (Systems with H.264 series do not have this option available.) -- Installed Audio Devices: If there is a sound device, up to 2 channels of sound recording can be enabled. -- Select Channel: Choose number of sound channels. DiViS...
  • Page 20 -- To Address: The email addresses of the people who will receive email notifications from the system. Multiple email address can be assigned, separated by a semicolon (;), limited up to 50 characters. -- Test: Test the email by sending a testing email. DiViS...
  • Page 21 Click “Properties” to set up. -- Warning message popup: Displays a message box when it cannot write data on disk. -- Disk fail event: Triggers an event when the system fails to write data on disk. (Refer to 5-7. Event Setup) DiViS...
  • Page 22 --- Notify interval: Update the IP address of current DVR system on the IP server once in every time interval. -- Prevent IP: Blocks IP addresses registered on the block list. --- Add, Delete, Modify: Add the IP address entered on “IP Add” field, delete or modify the selected IP address of the list. DiViS...
  • Page 23 Search program. - Setting log off timeout: Set the length of time each user can stay logged in without performing any operations (including mouse movements). All changes will only be applied if “Save & Close” or “Apply” button is clicked. DiViS...

  • Page 24: Camera

    H.264 boards.) • Sound Setting: Select an audio port to record along with the images of current camera. “Sound recording” option under System setup must be configured first. It is allowed to record the same audio channel on multiple cameras. DiViS...

  • Page 25: Scheduling

    - Sensor & Motion: Records images only when the sensor is triggered and/or motion is detected. - Normal & Event: Records at Event frame rate configured at “Select frame rate by camera” under “General” tab when an event is triggered. Otherwise, images will be recorded at Normal frame rate. DiViS...
  • Page 26 Select 7~19 for all days of the week. Recording will be enabled every day from 7:00 to 19:59:59. - Recording images only when movement is detected from 07:00 to 20:00. Use the “Motion” button instead of “Normal” and set as above. All changes will only be applied if “Save & Close” or “Apply” button is clicked. DiViS...

  • Page 27: Color & Motion

    -- Connect Setting: Select the serial port that the camera uses to connect to the computer. Refer to camera manufacturer’s documentation to set these values. -- Speed: P/T-Pan/Tilt speed, F/Z-Focus/Zoom speed, A.P-Auto pan speed (depending on PTZ camera, Speed might not be adjustable). -- Test: Test PTZ camera. DiViS...
  • Page 28 Ex) 1. Select Mode 1. 2. Set area for Mode 1. 3. Set Motion sensitivity as High for Mode 1. 4. Select Mode 2. 5. Set area for Mode 2. 6. Set Motion sensitivity as Low for Mode 2. DiViS...
  • Page 29 - Brightness: Brightness - Contrast: Contrast - Saturation: Saturation - Hue: Hue - Default Value: Set to default value. (Color Control is not supported with HDH boards. If you want to change color, please refer to the HD Camera Manual.) DiViS...

  • Page 30: Sensor

    - Relay Name: Set Relay name (ex. Front Door Siren). - Relay Trigger Use: If Relay is triggered manually, it will be activated only for selected “Latch time”. All changes will only be applied if “Save & Close” or “Apply” button is clicked. DiViS...

  • Page 31: Backup

    • Schedule table - Add: Add a new schedule to the list. - Modify: Press to store any changes made on the existing schedule. - Delete: Delete currently selected backup schedule. DiViS...
  • Page 32 - Data will be backed up at 20:00 every Saturday until data for that week has been completely backed up. All changes will only be applied if “Save & Close” or “Apply” button is clicked. After automatic Backup schedule has been configured, start the Backup program manually. DiViS...

  • Page 33: Event Setup

    • Second Screen: If system has second monitor, display popup on the selected coordinate of the second monitor. • Remote Notify: Notify to the Net client program (remote client software). • Use Notify Schedule: Use notify schedule (Camera – Schedule – Notify schedule). • Relay: Output 1~4 Relay for desired Latch time (seconds). DiViS...
  • Page 34 • E-mail: Send an E-mail. Note: “Use e-mail” must be enabled under DiViS DVR Setting (DiViS DVR Setting > System Setting > Auxiliary Function). - Subject: Subject of the e-mail. - Content: Content of the e-mail. - Attach Image: Attach an image of the video.
  • Page 35 Play: Play the sound file). - Play Time: Play the sound file for selected period of time. - Interval: Make a call once for every selected time interval. - WAV file must be in form of PCM, 16 Bit, 8 KHz, and Mono. DiViS...

  • Page 36: Main

    6. Main IMPORTANT DVR settings must be set before operating the DiViS DVR Main program. : Enables instant recording at the push of this button. : Listen to the sound while you are recording sound. : Click one of the split image profiles to view multiple cameras at once.
  • Page 37 The blinking lights on the top row, if any, indicate that the camera(s) are enabled in the DiViS DVR Settings, but no signal(s) are being delivered for some reason, such as no camera connectivity or weak signal. The solid lights on the bottom row indicate that the camera is being recorded.
  • Page 38 “Pan/Tilt Camera Method” section, must be configured to activate the control. Setting preset locations is referenced in section 5-4-3. : This menu adjusts the various camera color display settings. Press “Default” button to set the color settings back to their default values. DiViS...

  • Page 39: Search

    4 or 9 view-mode button. Make a left click on any camera numbers to switch with desired camera number. Click “Reset” to load the default camera numbers. : Change the size of the screen under Single-Search mode. DiViS...
  • Page 40 : The calendar allows the user to choose the specific date to search for recorded images. If the calendar is hidden, click on the “Date” button in order to activate it. Dates containing recorded data will be highlighted in red. : Press “Search Tool” or “Image Tool” button to open corresponding tools. DiViS...
  • Page 41 Note: To enhance this feature, it is recommended to install WMV codec provided. This codec is also available from Microsoft website. MP4 Format: Save as DiViS AVI file (.mp4) format which can be viewed by DiViS AVI Viewer only. MP4+EXE Format: Save as self-executable DiViS AVI file (.exe) format (No Player needed).
  • Page 42 This search is useful when a user is not aware of time information of desired data (24 hour → 10 minute → 1 minute, double click using left and right mouse button to navigate). 1~24 hour 10~60 minute 1~10 minute Final data search DiViS...
  • Page 43 A new window pops up to search the data on the time period by double clicking the searched data (the list on the bottom left hand side). : When you choose Internal CD Burn from the DiViS DVR Setting, the following CD burning DiViS...
  • Page 44 Note: 1. If a folder name is assigned on “CD folder”, the files on the list will be stored on the assigned folder. 2. Uncheck the check box if you don’t want to copy files on the list. : Click this button to exit from "DVR Search". DiViS...

  • Page 45: Utility

    This type of backup process allows selected data to be backed up. On the left window, choose the desired camera, date, hour, and minute to backup. The progress is monitored at the right window. If you have scheduled backup from the DiViS DVR Setting, this program will make backup data according to the schedule.
  • Page 46 • Setting – The folder name for Auto Backup Schedule is “ABxxxxxx”. ex) AB20041206_xxxx • In order to view backup data from other PC, copy the backup folder, install Utility to the PC, and run Backup Viewer to view/search the data. DiViS...

  • Page 47: Backup Viewer

    : Select “JPEG” or “AVI” and press this button to load a corresponding file format. If the image or AVI file has not been altered, it will display corresponding file information as above screenshot – otherwise, no information will be shown. DiViS...

  • Page 48: Avi Viewer

    8-4. AVI Viewer This program is used to play back mp4 format data, created by DiViS software. : Go to beginning of the clip. : Play previous frame (1 frame at a time). : Reversed play. : Play (with sound if exist).

  • Page 49: Log Viewer

    (DB overwrite warning message), and video loss log. : Reload log data. : Popup Search software when double clicked on Sensor and Motion log. : Runs Popup-search software when double clicked on Sensor and Motion log. DiViS...

  • Page 50: Pos, Access Control

    9. POS, Access Control Click “POS” button. POS Setting is automatically installed in this software. For configuration settings, refer to “DiViS POS Setting Manual.” DiViS...

  • Page 51: Appendix

    • Confirm P/W: Reenter the password. 1-2. General • Video Type: Regional video format type (NTSC or PAL). • Display Mode: Type of video image in Main screen. • Select Board Channel: The number of channels board is capable of displaying. DiViS...
  • Page 52 - Audible Warning: if “ON”, computer will beep until DiViS DVR Main is turned on again. - Restart Computer upon closing software by user: if selected, the system will restart when DiViS DVR Main is shut down. It is recommended to enable Auto startup under System Setup of DiViS DVR Setting.

  • Page 53: Dbtool

    Press ↑ button to transfer the drives checked in ‘DB file found in Disk’ to ‘DB Information of the system’. * Disks that are checked in “DB file found in Disk” must be registered here. • Select a drive to start saving (recording) data - Chooses drive at which to start recording data. DiViS...
  • Page 54 • After using this tool to reconfigure the drives, it will be possible to search through the files located on imported drives. • By copying or transferring the ‘M4DATA’ folder to another machine, it will be possible to search through the saved files immediately as long as the DVR program is installed on that machine. DiViS...

  • Page 55: Direct Web

    : Once Direct Web is installed, the system tray icon shown should appear. This program was installed automatically, along with DiViS main program. Note: When there is a collision against the firewall or port in the server with Direct Web, click the right hand button of the mouse on the tray bar icon and select ‘setting’.
  • Page 56 POS Search: Allows users to search recorded images by text data recorded. Refer to the POS Setting manual for details. Sound Search: Click video icon to switch to sound search mode. The timeline will display time frames where sound recording exists. Adjust playback speed and buffering size for better synchronization. DiViS...

  • Page 57: Tribrid Dvr

    4. Tribrid DVR (HD-SDI + D1 Series + *IP Web Cameras) The Tribrid DVR uses HDH board (HD-SDI series), HSD1 board (D1 series), and *IP web cameras all in one system. The following table shows a list of possible combinations of 32 channels for Tribrid.
  • Page 58 Select a desired channel for HD-SDI camera and assign that channel for SDI Camera using drop- down menu as shown above. • Sound Recording Hybrid DVR uses HE board’s sound record for saving audio data. HD-SDI camera can use the sound data saved through HE board (H.264 Series). DiViS...
