DiViS DVR
(Integration)
Installation and User's Guide
Ver 12.00.1
Digital Video Security System

Digital Video Recorder

www.DiViSdvr.com
Chance-i USA Corp.
*All contents of this document may change without prior notice, and actual product appearance may differ from depicted
herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Divis DVR

Summary of Contents for Divis DVR

  • Page 1: Digital Video Recorder

    DiViS DVR (Integration) Installation and User’s Guide Ver 12.00.1 Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein.

  • Page 2: Table Of Contents

    Index 1. Specification of DiViS ···························································································· 2. Installation Notes ··································································································· 3. Driver Installation ··································································································· 4. Program Installation ······························································································ 5. Configuration ········································································································· 5-1. Disk Tool ······································································································· 5-2. User Admin ································································································· 5-3. System ·········································································································· 5-4. Camera ········································································································· 5-4-1. General ··································································································· 5-4-2. Scheduling ································································································...
  • Page 3 Searching for a certain event or time period in an analog tape is both tedious and inefficient. Now, with the introduction of DVR, it has become easier, among other things, to find the images you want: simply enter the time and date into the computer and data is retrieved in seconds. No more mundane searches or manual tracking of tapes.

  • Page 4: Specification Of Divis

    Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. This feature can be controlled remotely. · Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. · Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
  • Page 5 Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images. Text Search allows to search data from external devices with DVR video image when event occurs. This will raise the level of integrity and security.

  • Page 6: Installation Notes

    Note: Above recommendation is based on usage of software version 12.00.1 * Due to the rapid changes of motherboards and video cards, some components with listed specifications may not work properly. Please contact technical support for the list of tested motherboards. DiViS...

  • Page 7: Driver Installation

    3. Driver Installation Drivers for CAP, ACAP, LIVCAP, AMX, and D1 can be installed by “installer.exe”, which determines DVR model and installs proper Driver. When Hardware Wizard message shows up before the installation, click “Cancel” to close. Open Driver folder in CD-Rom and run “Installer”.
  • Page 8 Following is a chart of device list. (Depending on model, different device(s) will be displayed) Model Device List CAP series DVR Capture LIVCAP series DVR Live Capture ACAP series DVR Acapture Device AMX series Live MPEG Capture Device 1.1 D1 series Live D1 MPEG Capture Device 1.1...

  • Page 9: Program Installation

    Click “Next”. Choose the proper media format (NTSC or PAL) and continue by clicking “Next.” The last letter of version indicates the type of board. i.e.) CAP – C, LIVCAP – L, ACAP-A, AMX – X, D1 – D. DiViS...
  • Page 10 ㆍAnyone who uses this computer [all users] : Allows all administrators to use the DVR software if there are multiple Windows user accounts available on the system – it is not accessible through limited user accounts. ㆍOnly for me[User Account Name] : Only current user account can use the DVR software.
  • Page 11 Setup will install a Program group into the Windows Start menu for easy access to the various DiViS DVR programs. DVR Main: Main Program DVR Search: Data Search Program DVR Setting: Setting Program Utility Auth Tool: A program for discerning whether a stored original image (jpg file) has been altered...

  • Page 12: Configuration

    5. Configuration Run “DVR Setting”. • Disk tool: Creates a DiViS DB file system. DiViS will create its own file system to store large amount of DVR data safely in its own dedicated disk space. Notice: DVR Main Program must be turned off prior to any database change.

  • Page 13: Disk Tool

    • Max Volume: Number of volumes available on current hard drive (volume). • Used Volume: Number of volumes dedicated to DVR recordings (volume). • Add Volume: Temporarily adds more dedicated space to DVR recordings – will not be finalized until “Create Volume” is clicked (volume).

  • Page 14: User Admin

    • Password: Password. • Confirm password: Confirm the password. • Default user: “Default user” will be assumed by the program to be using the DVR main whenever it is loaded. • Security level: Set the type of each user. • Authority: Adjust detail authorities of a user.

  • Page 15: System

    - Site Name: Name of the system that uniquely identifies the computer (used when sending emails). - Site Location: Name of the location where the DVR computer is located - DVR Information Backup: Allows users to import/export setting values. Note that it must be used under the same board and version of software.
  • Page 16 - Enable hardware watchdog (Auto recovery): If enabled, the watchdog will reboot the entire system if it becomes unstable or encounters errors. - Schedule auto reboot of DVR: If enabled, a schedule to reboot the entire system automatically can be set by clicking “Properties.” This reboot is independent from the watchdog functionality.
  • Page 17 --- SMTP/Login/No RSA: Use SMTP server login without RSA encryption on ID/Password --- SMTP/Login/RSA: Use SMTP server login with RSA encryption on ID/Password --- SMTP/Login/RSA/MD5: Use SMTP server login with RSA encryption and MD5 (Message Digest 5 algorithm) on ID/Password DiViS...
  • Page 18 “Properties” to set up. -- Warning message popup: Displays a message box when it cannot write data on disk. -- Disk fail event: Triggers an event when the system fails to write data on disk.(Refer to 5-7. Event Setup) DiViS...
  • Page 19 -- Use IP Server: In case of using IP server, check the box. Since IP Server uses Code to identify DVR system rather than its IP address, it is possible to connect to a DVR system that has a dynamic IP address (Code name must be unique for each DVR system.) -- IP Server: IP address of system in which IP Server program is running (Server must use static IP address.)

  • Page 20: Camera

    • Pre & Post alarm recording: Applies only if “Motion” or “Sensor” is selected in 'Scheduling' menu. - Pre: Number of recorded frames prior to Motion detection or Sensor trigger. - Post: Number of recorded frames after Motion detection or Sensor trigger. DiViS...

  • Page 21: Scheduling

    - Sensor & Motion: Records images only when the sensor is triggered and/or motion is detected. - Normal & Event: Records at Event frame rate configured at “Select frame rate by camera” under “General” tab when an event is triggered. Otherwise, images will be recorded at Normal frame rate. DiViS...
  • Page 22 Select 7~19 for all days of the week. Recording will be enabled every day from 7:00 to 19:59:59. - Recording images only when movement is detected from 07:00 to 20:00. Use the “Motion” button instead of “Normal” and set as above. DiViS...

  • Page 23: Color & Motion

    -- Connect Setting: Select the serial port that the camera uses to connect to the computer. Refer to camera manufacturer’s documentation to set these values. -- Speed: P/T-Pan/Tilt speed, F/Z-Focus/Zoom speed, A.P- Auto pan speed (Depending on PTZ camera, Speed might not be adjustable.) -- Test: Test PTZ camera. DiViS...
  • Page 24 - Partial area: Click "Add“, and select specific area(s) to detect motion. Up to 10 partial areas can be selected, and they can be deleted by pressing “Delete All" button. - Display detected area: If selected, any regions with motion will show a group of red grids. It may be used to test motion sensitivity. DiViS...

  • Page 25: Sensor

    • Emergency notify: If “Remote notification of events” was enabled in “System” setup, it will automatically send remote notification to the designated Net client software regardless of the notification schedule. • Sensor trigger - Notification: Choose event for sensor detection (Refer to 5.7. Event Setup) DiViS...
  • Page 26 - Relay Index: Select a Relay to configure. (‘Select All’ applies the same setting to all relays) - Relay Name: Set Relay name (ex. Front door siren) - Relay Trigger Use: If Relay is triggered manually, it will be activated only for selected “Latch time” DiViS...

  • Page 27: Backup

    - Start backup timer: Initiate “backup.exe” automatically upon the system startup. The backup program icon will be placed on the system tray if launched successfully. - Overwrite when the disk is full: If selected, assigned backup device will start overwriting when it is full during automatic backup (Overwrites starting from the oldest backup data.) DiViS...

  • Page 28: Event Setup

    - Use PC Speaker: Play Beep using PC speaker (Sound card is not required) • Mark: Display Red dot on camera screen. • Popup: Display a single view Popup in DVR Main. • TV-out: Display the camera through Composite out for selected time period (in seconds) •...
  • Page 29 Note: The following table will help complete the Subject and Content fields. <<Example>> Reserved word Contents Subject: “At $$2, $$1 triggered at camera number $$0. Camera No. Subject: “At 01-18-2005 19:10:12, Motion triggered at camera Events number 3. Time IP address DiViS...
  • Page 30 - WAV file must be in form of PCM, 16 Bit, 8 KHz, Mono. * Making Wav File - Execute sound recorder from Windows: File Properties Convert Now Attributes - Choose PCM, 8.000 KHz, 16 Bit, Mono and start recording. DiViS...

  • Page 31: Main

    6. Main IMPORTANT DVR settings must be set before operating the DiViS main program. : Enables instant recording at the push of this button. : Listen to the sound while you are recording sound. : Click one of the split image profiles to view multiple cameras at once.
  • Page 32 The blinking lights on the top row, if any, indicate that the camera(s) are enabled in the DVR Settings, but no signal(s) are being delivered for some reason, such as no camera connectivity or weak signal.
  • Page 33 : Left-figure shows the general DVR skin for P/T/Z control. Note that only the basic controls are available in this P/T/Z control menu. : Control Preset, Tour, P/T Speed of PTZ camera. (Press “Preset” button to load the control box).

  • Page 34: Search

    Cameras on 4 or 9 view-mode can be selected as desired. The following screen will popup by double clicking on the 4 or 9 view-mode button. Make a left click on any camera numbers to switch with desired camera number. Click “Reset” to load the default camera numbers. : Change the size of the screen under Single-Search mode. DiViS...
  • Page 35 : The calendar allows the user to choose the specific date to search for recorded images. If the calendar is hidden, click on the “Date” button in order to activate it. Dates containing recorded data will be highlighted in red. : Press “Search Tool” or “Image Tool” button to open corresponding tools. DiViS...
  • Page 36 Note: To enhance this feature, it is recommended to install WMV codec provided. This codec is also available from Microsoft website. MP4 Format: Save as DiViS AVI file (.mp4) format which can be viewed by DiViS AVI Viewer only. MP4+EXE Format: Save as self-executable DiViS AVI file (.exe) format. (No...
  • Page 37 This search is useful when a user is not aware of time information of desired data. (24hour->10minute-> 1minute, Use double click using left and right mouse button to navigate) 1~24hour 10~60minute 1~10minute Final data search DiViS...
  • Page 38 - Bookmark: Able to bookmark for wanted data. Search the data from bookmark list from Search Menu. - Close: Close the smart search window. A new window pops up to search the data on the time period by double clicking the searched data (The list on the bottom left hand side). DiViS...
  • Page 39 : When you choose Internal CD Burn from setting program, the following CD burning program in DVR System will be executed. Otherwise, the linked CD burning program will be executed. - ADD File: Select files that will be stored on CD/DVD.

  • Page 40: Utility

    The progress is monitored at the right window. If you have scheduled backup from the DVR Setting, this program will make backup data according to the schedule. • Total: Able to backup by choosing Volume Files directly from the list based on date and hour. It is a very fast backup process for large volume of data although it can’t select the partial cameras.
  • Page 41 “Start Backup Timer” option und • Burning this backup file on the CD: If selected, Backup.exe will execute CD Burn program automatically er Backup setting at DVR Setting. after backup. Unable to backup if the data size is bigger than the CD capacity.

  • Page 42: Backup Viewer

    : Select “JPEG” or “AVI” and press this button to load a corresponding file format. If the image or AVI file has not been altered, it will display corresponding file information as above screenshot – otherwise, no information will be shown. DiViS...

  • Page 43: Avi Viewer

    8-4. AVI Viewer This program is used to play back mp4 format data, created by DiViS software. : Go to beginning of the clip. : Play by 1 frame at a time (back). : Reversed play : Play (with sound if exist).

  • Page 44: Log Viewer

    (DB overwrite warning message), and video loss log. : Reload log data. : Popup Search software when double clicked on Sensor and Motion log : Runs Popup-search software when double clicked on Sensor and Motion log DiViS...

  • Page 45: Appendix

    Appendix 1. DVR Management Default settings of DVR software and hardware can be modified using ‘START.exe’. This program allows user to change hardware configuration, Top Admin user information, network port configuration, and watchdog options. Note that changing these configurations to inappropriate values may cause malfunction of the system.
  • Page 46 - Use Beep Sound: if “on”, computer will beep when DVR Main is off. - Restart Computer upon closing software by user: if selected, the system will be restarted when DVR Main is closed. It is recommended to use when Auto startup is enabled under system setup.

  • Page 47: Dbtool

    Press ↑ button to transfer the drives checked in ‘DB file found in Disk’ to ‘DB Information of the system’. * Disks that are checked in “DB file found in Disk” must be registered here. • Select a drive to start saving (recording) data - Chooses drive at which to start recording data. DiViS...
  • Page 48 • After using this tool to reconfigure the drives, it will be possible to search through the files located on imported drives. • By copying or transferring the ‘M4DATA’ folder to another machine, it will be possible to search through the saved files immediately as long as the DVR program is installed on that machine. DiViS...

  • Page 49: Direct Web

    : Once Direct Web is installed, the system tray icon shown should appear. This program was installed automatically, along with DiViS main program. Note: When there is a collision against the firewall or port in the server with Direct Web, click the right hand button of the mouse on the tray bar icon and select ‘setting’.
  • Page 50 SOUND SEARCH: Click speaker icon and the timeline will display sound recording (if sound recording exists) with blue bar as shown in above. Select blue section of timeline to search sound recording. Adjust playback speed and buffering size for better synchronization. DiViS...

  • Page 51: Mc (Media Control) Setup

    Therefore, it is required to run “MCSetup.exe” prior to utilize audio recording function of DiViS products. It is located under DiViS DVR (or DVR System) folder. AMX / D1 Series products and the 16 channel audio board do not require this procedure. This procedure is also not required on Window Vista or Windows 7.
  • Page 52 Then, select a matching control from the list of controls available below the device name. Make sure to assign different controls for each component. The Check box below each control mutes the control if checked. Make sure to mute only the control that is for incoming sound to record. DiViS...
  • Page 53 Perform the same procedure for input components, and click on Next. • Save and Finish Setup Click on “Save & Done” to store data and finish Media Control Setup( MC Setup ). • Once Media Control Setup completed, DVR Main will use this information to operate Sound Recording function. DiViS...
