- Page 1 DiViS DVR - D1 Series Hardware Installation Guide Rev. 1.0 Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein.
-
Page 2: Table Of Contents
INDEX 1. Specification of DiViS-D1 Series ……………………….………………………..2. Products and components ……………………….…………………………………… 2-1. DVR Board ……………………….……………………………………………….. 2-2. Accessories ……………………….………………………………………………. 2-3. Optional Accessories …….……………….……………….…………………….. 3. Board Layout ……………………….…………………………………………………… 3-1. 48016 D1 ……………………….…………………………………………………. 3-2. I/O Board ……………………….…………………………………………………. 4. Installation ……………………….………………………………………………………. 4-1. 48016 D1 Pigtail Type ………………………………………………. - Page 3 For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, Between DiViS products and 48016 D1 board. The pictures and the name of the products are subject to change; however, the usage may be similar.
-
Page 4: Specification Of Divis-D1 Series
Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space. - Page 5 Network Support (PSTN, TCP/IP, LAN, Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. Integration with Text data from External Devices Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.
-
Page 6: Products And Components
2. Product and Components 2.1. DVR Board 48016D1 2-2. Accessories Pigtail Cable Sound Pigtail Cable Watchdog Cable 2-3. Optional Accessories I/O Board Sensor Port Sensor & Relay Cable RS-485 Board RS-232C Cable Back panel Video Cable DiViS... -
Page 7: Board Layout
3. Board Layout 3-1. 48016 D1 3-2. I/O Board DiViS... -
Page 8: Installation
2) Connect 1~16 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect I/O cable to the sensor port. 5) Connect the other side of the I/O cable to the I/O connector. 6) Connect watchdog cable. (White cable must go left of the connector) DiViS... -
Page 9: 48016 D1 Back Panel Type
7) Connect the remaining cable with BNC2 label. 8) Connect the video cable with BNC9 label. 9) Connect the remaining cable with BNC2 label. 10) Connect audio pigtail cable. 11) Connect watchdog cable. (White cable must go left of the connector) DiViS... -
Page 10: Accessories
4, 6, ~ 32, 34 : Camera Signal 2 : Composite Signal 1 : Composite Ground Sensor & Relay I/O Sensor input : 1, 2 ~ 15, 16 Sensor ground : 17, 18 Relay Output : 19, 20, 21, 22, Relay ground : 23, 24 DiViS... -
Page 11: Video And Audio Pigtail Cable
13 ~ 16 : Gray BNC 4, 12 : Green con 8, 16 : White con 5-3. Sensor Port Sensor port pin number 1 ~ 16 : Signal input G : Ground R1, R2, R3, R4 : Relay output DiViS... -
Page 12: Rs232 To Rs422/485 Converter
4) Connect this end to RS-485 Board (3. Power socket) 5) Connect the other end to the connector on DVR board. Step 4 and 5 are not necessary if other power socket was connected in step 3. RS-485 Mode RS-422 Mode DiViS... -
Page 13: Port Converter
6, RS-232 to DVR : Used by Serial port in DVR 7, RS-485(P) to DVR : Used by RS-485 board in DVR 8, Rs-232 to Printer : Used by Serial Printer 9, Rs-485(S) to DVR : Used by RS-485 board in DVR DiViS... -
Page 14: Baud Rate
(2): TX+ (3): RX- (4): RX+ (5): GND 11, SW1, SW2: Used in output of Parallel port 12, SW3, SW4: Used in output of Serial 5-5-3. Baud Rate 5-5-4. Jumper Selection Output of parallel port Output of serial port DiViS...
