  • Page 1 DiViS DVR D1 Series Rev. 1.0 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com DiViS DVR.com *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein.

  • Page 2: Table Of Contents

    DiViS www. DVR.com Index 1. Specification of HSD1 2. Installation Notes 2-1. Recommendation for 48016HSD1 2-2. Recommendation for 96032HSD1 3. Products and Components 3-1. DVR Board 3-2. Optional Accessories 4. Board Description 4-1. 48016HSD1 4-2. 96032HSD1 4-3. I/O Board 5. Installation 5-1.
  • Page 3 DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, 48016HSD1 & 96032HSD1 board. The pictures and the name of the products are subject to change; however, the usage may be similar.

  • Page 4: Specification Of Hsd1

    Multi-Viewing allows 1, 4, 6, 9, 10, 16 different camera shots to be displayed onscreen at the same time. Other display features include enlarging all displayed cameras or just one. ㆍ PAN/TILT/ZOOM/FOCUS Capabilities Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. ㆍ Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it.
  • Page 5 ㆍ Network Support (PSTN, TCP/IP, LAN ,Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. ㆍ POS, Access Control, ATM Support Record data from external devices(POS, Access Control, ATM, etc)with DVR video images.

  • Page 6: Installation Notes

    DiViS www. DVR.com 2. Installation Notes 2-1. Recommendation for 48016HSD1 - Recommend to use Intel Chipset mother board. I) Not compatible with mother boards that are specifically designed such for Small Form Factor (SFF-Mobile). - Minimum of Intel Core i3 CPU recommended. (Higher than Clarkdale or Lynnfield) I) Recommend to use Intel Ivy Bridge Chipset with Intel Core i7 for best results.

  • Page 7: Products And Components

    DiViS www. DVR.com 3. Products and Components 3-1. DVR Board 48016HSD1 96032HSD1 3-2. Optional Accessories Sensor Port Sensor Cable RS-485 Board USB RS-485 board cable DiViS...

  • Page 8: Board Description

    DiViS www. DVR.com 4. Board Description 4-1. 48016HSD1 7 7 9 9 11 1) TV-Out select Jumper 2) TV-OUT connector 3) Video input connector: Connect video pigtail cable 1-16ch. 4) Audio input connector: Connect audio pigtail cable 1-16ch. 5) Back panel connector: Connect back panel cable 1-4 ch.

  • Page 9: 96032Hsd1

    DiViS www. DVR.com 4-2. 96032HSD1 DiViS...
  • Page 10 DiViS www. DVR.com 1) TV-Out select Jumper 2) TV-OUT connector 3) Video input connector: Connect video pigtail cable 1-16ch. 4) Audio input connector: Connect audio pigtail cable 1-16ch. 5) Back panel connector: Connect back panel cable 1-4 ch. 6) Back panel connector: Connect back panel cable 5-8 ch.

  • Page 11: I/O Board

    DiViS www. DVR.com 4-3. I/O board Bottom side Top side 1) I/O Connector: Connect I/O Cable. 2) Board Connector: Connect to the upper I/O board connector of the capture board. 3) Board Connector: Connect to the lower I/O board connector of the capture board.

  • Page 12: Installation

    DiViS www. DVR.com 5. Installation 5-1. 48016HSD1 Installation 5-1-1. Pigtail Type 1) Connect 1~16 channel video pigtail cable to the top connector. 2) Connect 1~16 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect I/O cable to the sensor port.

  • Page 13: Back Panel Type

    DiViS www. DVR.com 5-1-2. Back panel Type 1) Back panel. 2) Sensor Cable. 3) When connect cable to back panel make sure to leave one pin from each end. White cable should be faced upside. 4) Connect TV-Out cable to the top pin on back panel. (make sure to have the white cable facing up) 5) Connect the other side of the TV-Out cable to the capture board.

  • Page 14: 96032Hsd1 Installation

    DiViS www. DVR.com 5-2. 96032HSD1 Installation DiViS...
  • Page 15 DiViS www. DVR.com 1) Connect 1~16 channel video pigtail cable to the top connector. 2) Connect 1~16 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect I/O cable to the sensor port. 5) Connect the other side of the I/O cable to the I/O connector.

  • Page 16: Accessories

    DiViS www. DVR.com 6. Accessories 6-1. USB to RS 422/485 Converter PTZ Device Port Convertor 1) Connect to a COM port on system motherboard. 2) Connect the other side of this cable to RS-485 Board. 3) They are power sockets. It requires connection to only one of them.
