DiViS DVR
(Integration)
Ver 11.02.2
Installation and User's Guide
Digital Video Security System
Digital Video Recorder
www.divisdvr.com
CHANCE-i USA Corp.
*All contents of this document may change without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR and is the answer not in the manual?

Questions and answers

Related Manuals for Divis DVR

Summary of Contents for Divis DVR

  • Page 1 DiViS DVR (Integration) Ver 11.02.2 Installation and User’s Guide Digital Video Security System Digital Video Recorder www.divisdvr.com CHANCE-i USA Corp. *All contents of this document may change without prior notice.

  • Page 2: Table Of Contents

    DiViS w w w . D V R . c o m INDEX 1. Specification of DiViS 2. Installation Notes 3. Driver Installation 4. Program Installation 5. Configuration 5-1. Disk Tool 5-2. User Admin 5-3. System 5-4. Camera 5-4-1. General 5-4-2.
  • Page 3 One of the many problems with analog tapes is the limited searching capabilities they provide. Searching for a certain event or time period in an analog tape is both tedious and inefficient. Now, with the introduction of DVR, it has become easier, among other things, to find the images you want: simply enter the time and date into the computer and data is retrieved in seconds.

  • Page 4: Specification Of Divis

    Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
  • Page 5 Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images. Text Search allows to search data from external devices with DVR video image when event occurs. This will raise the level of integrity and security.

  • Page 6: Installation Notes

    DiViS w w w . D V R . c o m 2. Installation Notes - Recommend to use Intel Chipset mother board. I) It might be incompatible with mobile system or special system mother board. Type LIVCAP xxxN32 Intel 865 / 875 Chipset Motherboard...

  • Page 7: Driver Installation

    . D V R . c o m 3. Driver Installation Drivers for DiViS CAP, DiViS LIVCAP and, DiViS MPG can be installed by “installer.exe”, which determines DVR model and installs proper Driver. When Hardware Wizard message shows up before the installation, click “Cancel”...
  • Page 8 Model Device List CAP series DVR Capture LIVCAP series DVR Live Capture MPG series DVR MPEG 4 Click “Install”. The above picture shows up when installation is completed. Click “Reboot” to restart the system. It is required to reboot the system to complete installation of drivers.

  • Page 9: Program Installation

    DiViS w w w . D V R . c o m 4. Program Installation Run “Setup.exe”. (Choose the language for the software to be installed.) Click “Next”. Choose the proper media format (NTSC or PAL) and continue by clicking “Next.”...
  • Page 10 Note: Once the Top Admin user created, it cannot be modified from User Admin Setup. To change user name or password for Top Admin user, please refer to the page 52, Appendix 1.DVR Management. Once setup of the software has been complete, the system will need to be restarted to allow the settings to take effect.
  • Page 11 Device Setup: Program to select external device and to make database and setup ExDevice Setup: Program to setup communication and display Whenever the DVR main program is exited (to either search for data or modify settings), a login prompt similar to the...

  • Page 12: Configuration

    Run “DVR Setting”. • Disk tool: Creates a DiViS DB file system. DiViS will create its own file system to store large amounts of DVR data safely in its own dedicated disk space. Notice: DVR Main Program must be turned off prior to any database change.

  • Page 13: Disk Tool

    Creates the number of volumes specified in “Add Volume.” Note: In order to properly add more volumes to the DiViS system, be sure to check that the number of volumes to be added has been stored in the right hand column of the bottom table under “Add Volume.”...

  • Page 14: User Admin

    • Username: User name. • Password: Password. • Confirm password: Confirm password. • Default user: “Default user” will be assumed by the program to be using the DVR main whenever it is loaded. • Security level: Set the type of each user.

  • Page 15: System

    5-3. System • Site Information - Site Name: System name that uniquely identifies the computer (used when send email.) - Site Location: Name of the location at which the DVR computer is located • Network - Allow remote connections : Allow users to log into the system from a remote location through the network Code: Give a unique combination of case-sensitive alphanumeric and numeric character, maximum of 10 characters.
  • Page 16 - Use IP Server: In case of using IP server, check the box. Since IP Server uses Code to identify DVR system rather than its IP address, it is possible to connect DVR system with dynamic IP address. (Code name must be unique for each DVR...
  • Page 17 - Enable hardware watchdog (Auto recovery): If enabled, the watchdog will reboot the entire system if it becomes unstable or encounters errors. - Schedule auto reboot of DVR: If enabled, a schedule to reboot the entire system automatically can be set by clicking “Properties.” This reboot is independent from the watchdog functionality.
  • Page 18 DiViS w w w . D V R . c o m -- Following is the MPG board sound recording option. You can choose as many audio channels as video channels. Notes: 1. The system requires Direct X 8.0 or higher for sound recording.
  • Page 19 - Auto Startup: Enable automatic startup of DVR Main Program upon system start. - Internal program CD burn: Use CD Burn Program in DVR Program (Windows XP required). - External program CD burn: Click “Browse” button to choose external CD Burn Program (CD- RW).

  • Page 20: Camera

    DiViS w w w . D V R . c o m 5-4. Camera 5-4-1. General If selected, the settings selected in “General”, “Schedule”, “Color & Motion” will be applied to all the cameras. If you would like to customize each...

  • Page 21: Scheduling

    DiViS w w w . D V R . c o m • Pre & Post alarm recording: In order to enable this, you should select “Motion” or “Sensor” in 'Scheduling' menu. - Pre: Recording frame number prior to a Motion detection or Sensor trigger.
  • Page 22 DiViS w w w . D V R . c o m • Notify schedule On this menu, schedule appropriate times in which the system should send remote notifications. - Notify: Press “Notify” and set up the desired time and day-of-the-week.

  • Page 23: Color & Motion

    DiViS w w w . D V R . c o m 5-4-3. Color & Motion This menu allows the user to control the color of the recorded images, modify motion detector settings, and set up relay outputs (sirens, locks, etc.) for the system •...
  • Page 24 DiViS w w w . D V R . c o m RECEIVER: Choose PTZ camera . PTZ ID: Choose ID of PTZ camera . MANUAL SETTING: Selects the serial port that the camera uses to connect to the computer. Refer to camera manufacturer’s documentation to set these values.

  • Page 25: Sensor

    DiViS w w w . D V R . c o m • Motion setting To receive desired optimal detection, configure the following options. - Sensitivity adjustment: Adjusts the level of color difference detection between the foreground and background. - Rate of motion: Adjusts the rate of motion detected by the camera – if the number is higher, the camera will be able to better pick up slower moving objects.

  • Page 26: Backup

    DiViS w w w . D V R . c o m 5-6. Backup Recorded images can be backed up automatically if a backup schedule is set. After completion of automatic backup scheduling, “Backup.exe” must be initiated. The automatic backup will not take effect if “Backup.exe”...

  • Page 27: Event Setup

    DiViS w w w . D V R . c o m Backup always starts from end of last backup session. (First time Backup will start from the very beginning of recorded data) << Example >> 1) Backup (automatic) at 20:00 every day - Data will be backed up at 20:00 each day until data for the day has been completely backed up.
  • Page 28 DiViS w w w . D V R . c o m • Relay: Output 1~4 Relay for desired Latch time(seconds) • E-mail: Send an E-mail. (In System setting, “Use e-mail” must be enabled and configured.) - Subject: subject of email - Content: E-mail content - Attach Image: Attach video image.
  • Page 29 DiViS w w w . D V R . c o m • Preset: If selected sensor is tripped, this feature allows the selected camera to focus into the selected preset position. • Phone Call: When event occurs makes phone call and plays sound file(.wav) (Voice Modem required) - Number 1, 2, 3: Enter up to 3 phone numbers.

  • Page 30: Main

    D V R . c o m 6. Main MPORTANT DVR settings must be set before operating the DiViS main program. : This “hot button” allows instant recording at the push of a button. : Listen to the sound while you are recording sound.
  • Page 31 The blinking lights, if any, on the middle tab row indicate that the camera are to be enabled in the DVR Settings, but image is not coming for any of reason. The solid lights on the bottom tab row tell that the image from the camera is being recorded.
  • Page 32 . D V R . c o m : Left-figure shows the general DVR skin for P/T/Z control. Note that only the basic controls are available in this section of P/T/Z control. : Control Preset, Tour, P/T Speed of PTZ camera.

  • Page 33: Search

    DiViS w w w . D V R . c o m 7. Search Searching for a single or multiple image data by any combination of date, time and camera, is possible. Any image(s) can be saved and printed while searching.
  • Page 34 DiViS w w w . D V R . c o m The camera number(s) will be displayed on the right side. Hours are displayed on the bottom and minutes are displayed on the top. The green blocks indicate the hour time frame at which a recording exists. The associated white blocks indicate the minutes within that hour that contain these recordings.
  • Page 35 AVI Format: Normal AVI (.avi) format file which can be played with Windows Media Player. MP4 Format: DiViS AVI file (.mp4) format which only can be viewed by DiViS AVI Viewer. MP4+EXE Format: Self executable DiViS AVI file (.exe) format. (No...
  • Page 36 DiViS w w w . D V R . c o m : Change Search mode to Common Search, Panorama Search or, Icon Search. Common Search: Normal Search with Single and Multi-Search. Panorama Search: Divide 1 camera recording into 16 multi view mode to search it frame by frame.
  • Page 37 DiViS w w w . D V R . c o m Smart Search allows searching data by detecting motion in the data. This feature allows rapid searching for images by specified time, date, camera, and limiting the searching parameter to specific levels of motion. Specific regions within the video can be selected to search through.
  • Page 38 : When you choose Internal CD Burn from setting program, the following CD burning program in DVR System will be executed. Otherwise, the linked CD burning program will be executed. - ADD File: Choose files to save on CD.

  • Page 39: Utility

    The progress is monitored at the right window. If you setup backup schedule from the DVR Configuration, it automatically execute Backup from the configured schedule. • Total: Able to backup by choosing Volume Files directly from the list based on date and hour. It is very fast backup for large volume of data although it can’t select the partial cameras.
  • Page 40 • Auto startup enable: If selected, backup.exe will be automatically initiated up the system restart. This option is also connected to the “Start Backup Timer” option under Backup setting at DVR Setting. (Chap. 5-6) • Burning this backup file on the CD: Execute CD Burn program automatically after backup. Unable to backup if the data size is bigger than the CD capacity.

  • Page 41: Backup Viewer

    DiViS w w w . D V R . c o m 8-2. Backup Viewer Backup data can be viewed only by using the Backup Viewer program. All function for Backup Viewer Program is the same as the Search Program except data open.

  • Page 42: Auth Tool

    DiViS w w w . D V R . c o m 8-3. Auth Tool This program is used to decipher images saved by the ‘Search’ or ‘Backup Viewer’ programs and can distinguish between original and altered images. : If the test image is an actual, unmodified clip, its information should be listed in the table.

  • Page 43: Log Viewer

    DiViS w w w . D V R . c o m Go to beginning of the clip. : Play by 1 frame at a time (back). : Play (with sound if exist). : Pause. : Play by 1 frame at a time (forth).

  • Page 44: Pos, Access Control External Device Setup

    DiViS w w w . D V R . c o m 9. POS, Access Control External Device Setup Device Setup: External Device and DB setup program ExDevice Setup: External Device communication and display setup program Run Device Setup first and then run ExDevice Setup.

  • Page 45: Create Database

    DiViS w w w . D V R . c o m 9-1-2 Create Database Support type of database: Microsoft Access and SQL server - Microsoft Access - Select folder to create DB and click Create Database, Test Database, Compact Database in order to create database and test it.

  • Page 46: Events Setting

    After selecting Device click “Add” button to add event string.(case sensitive.) . Select each registered even string and choose Notify method(Beep, Mark, Popup . Once Event string is transferred from external device, corresponding action (beep, mark or popup) will be executed in the DVR main. DiViS...

  • Page 47: Exdevice Setup

    . D V R . c o m 9-2. ExDevice Setup External device connects to DVR through both Serial port and TCP/IP. Port Converter allows RS-422/485 and parallel connection. 9-2-1. Com Setup Available ports are listed in the left side.

  • Page 48: Lan Setup

    DiViS w w w . D V R . c o m 9-2-2. Lan Setup * Multiple external devices can be connected with single TCP/IP connection. Each device must be given a unique port number. - Choose Lan from list.

  • Page 49: Display Setup

    DiViS w w w . D V R . c o m 9-2-3. Display Setup Setup the property of display of text data. - Choose camera number. - Font select: Click Browse and change font, size and color. - Text position: Setup the position of text. Default is set to top of the screen. As number increases, text will be displayed farther from the top.

  • Page 50: Pos, Access Control Data Search

    DiViS w w w . D V R . c o m 10. POS, Access Control Data search Once External device setup is finished the Main program will show similar to picture above. Each video image and external device data is recorded real time.
  • Page 51 DiViS w w w . D V R . c o m * Event string: when event string has been registered in Device Setup, the event string appears in items Double click on one of searched result will bring a pop-up window as following picture The size of pop-up window is adjustable to feed the demand of larger viewing.

  • Page 52: Appendix

    Appendix 1. DVR Management A system with the DVR software and hardware that upgrades to a different capture card must be reconfigured. This can be done by executing ‘START.exe’. It is located either on the desktop or the directory where DVR software was installed.
  • Page 53 DiViS w w w . D V R . c o m 1.2 General • Video Type: Regional video format type. (NTSC or PAL) • Display Mode: Type of video image in Main screen. • Select Board Channel: The number of channels board is capable of displaying.

  • Page 54: Dbtool

    DiViS w w w . D V R . c o m 2. DBTool - Note - 1. This procedure applies to program version 5.01.00 or later. 2. This utility is required for disks (that contain a database) that are moved from one machine to another and searched through by that machine.
  • Page 55 After using this tool to reconfigure the drives, it will be possible to search through the files located on imported drives. By copying or transferring the ‘MP4DATA’ folder to another machine, it will be possible to search through the saved files immediately as long as the DVR program is installed on that machine. DiViS...

  • Page 56: Direct Web

    Once Direct Web is installed, the system tray icon shown should appear. This program was installed automatically, along with DiViS main program. Note: When there is a collision against the firewall or port in the server with Direct Web, click the right hand button of the mouse on the tray bar icon and select ‘setting’.
  • Page 57 DiViS w w w . D V R . c o m The following picture is an example of the web view after connecting to the server. These are supporting functionalities; Multiplex view mode, PTZ control, image control, voice communication, relay out, etc.
