DiViS DVR – LIVCAP Series Rev. 1.5 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com DiViS DVR.com *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein...
Page 3
DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, 24016LIV, 12016LIV, 240N16, 120N16, 240N32, and 480N32 board. The pictures and name of the products are subject to change; however, the usage may be similar.
Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
Page 5
Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. Integration with Text data from External Devices Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.
DiViS w w w . D V R . c o m 2. Products and Components 2-1. DiViS LIVCAP Series Board 120N16 12016LIV 240N32 (2 Boards. Master & Slave) 240N16 24016LIV 480N32 (2 Boards. Master & Slave) 2-2. Accessories Pigtail Cable...
. D V R . c o m 4. Installation 4-1. 120N16 / 240N16 / 12016LIV / 24016LIV 4-1-1. Pigtail Type 1) 1~8 channel pigtail goes to the upper socket. 2) 9~16 channel pigtail goes to the lower socket.
DiViS w w w . D V R . c o m 4-1-2. Back Panel Type 1) Back panel. 2) Sensor Cable. 3) When connect cable to back panel make sure to leave one pin from each end. (The white cables must face the top.) 4) Connect video cable with BNC2 label.
Page 13
DiViS w w w . D V R . c o m 4-2. 240N32 Master Board Camera 1 ~ 8 To Motherboard PC Reset Cable Camera 9 ~ 16 TV Out Port Slave Board Camera 17 ~ 24 Camera 25 ~ 32 1) Power: Power connection for RX Converter.
Page 14
DiViS w w w . D V R . c o m 4-3. 480N32 Master Board Camera 1 ~ 8 PC Reset Cable Camera 9 ~ 16 To Motherboard TV Out Port Camera Slave Board 17 ~ 24 Camera 25 ~ 32 1) Power: Power connection for RX Converter.
DiViS w w w . D V R . c o m 5. Accessories 5-1. Back Panel Camera I/O Sensor & Relay (Digital I/O) Camera Ground 3, 5, ~ 31, 33 Sensor Input 0~15 1~16 Camera Signal 4, 6, ~ 32, 34...
DiViS w w w . D V R . c o m 5-2. Pigtail Pigtail cable 1 ~ 4, 9 ~ 12 : Black BNC 5 ~ 8, 13 ~ 16 : White BNC 5-3. Sensor Board Sensor port pin number...
DiViS w w w . D V R . c o m 5-4. USB to RS422/485 Converter 1) Connect to internal USB header on system motherboard. 2) Connect the other side to RS422/485 Board. 3) Connect a power source to any one of these power sockets.
DiViS w w w . D V R . c o m 5-5. USB to RS422/485 Converter (32ch) USB to RS422/485 Converter + TV-OUT board for 32 channels 1) Connect to internal USB header on system motherboard. 2) Connect the other side to RS422/485 Board.
DiViS w w w . D V R . c o m 5-6. Sound Recording After connecting Microphone, ensure that “Line In” and “Microphone In” is not muted in the Windows sound setting. Note: Direct X 8.0 or higher is required for Sound Recording.
