DiViS DVR - AMX Series Rev. 1.1 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice.
Page 3
DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, DiViS MPG48016AMX and DiViS MPG96032AMX. The pictures and names of the products are subject to change depending on hardware upgrade.
Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
Page 5
Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. POS, Access Control, ATM Support Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.
DiViS www. DVR.com 4. Installation 4-1. DiViS MPG48016AMX 4-1-1. Pigtail type 1) Connect 1~16 channel video pigtail cable to the top connector. 2) Connect 1~16 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect I/O cable to the sensor port.
DiViS www. DVR.com 4-1-2. Back Panel Type 1) Back Panel. 2) Sensor Cable. 3) When connecting video cables to back panel, make sure to leave the bottom pin on the back panel and have white cables facing up. 4) Connect the video cable with BNC2 label.
Page 12
DiViS www. DVR.com 1) Connect 1~16 channel video pigtail cable to the top connector of the master board. 2) Connect 1~16 channel audio pigtail cable to the bottom connector of the master board. 3) Connect 17~32 channel video pigtail cable to the top connector of the slave board.
DiViS www. DVR.com 5-4. RS232 to RS422/485 Converter * Use Rx+ and Rx- for RS 485 method. - TxData + TxData - RxData + RxData Signal 1) Connect to system’s Com port. 2) Connect to PTZ port converter RS-485 + TV-OUT board 3) Connect a power source to any one of these power sockets.
DiViS www. DVR.com 5-5. PORT Converter 5-5-1. Specification RS-232 from POS DB9 Female Input Parallel Port from POS DB25 Male RS-232 to Printer DB9 Male Serial RS-485(S) to DVR TX(+)(-), RX(+)(-), GND Output Parallel Port to Printer DB25 Female Parallel...
DiViS www. DVR.com 9, Rs-485(S) to DVR : Used by RS-485 board in DVR 10, Terminal Block (1): TX- (2): TX+ (3): RX- (4): RX+ (5): GND 11, SW1, SW2: Used in output of Parallel port 12, SW3, SW4: Used in output of Serial 5-5-3.
