DiViS DVR - H.264 Series
Rev. 1.0
Hardware Installation Guide
Digital Video Security System
Digital Video Recorder
www.DiViSdvr.com
Chance-i USA Corp.
*All contents of this document may change without prior notice, and actual product appearance may differ from
depicted herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H.264 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Divis H.264 Series

  • Page 1 DiViS DVR - H.264 Series Rev. 1.0 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein.
  • Page 2: Table Of Contents

    DiViS www. DVR.com INDEX 1. Specification of DiViS 2. Products and components 2-1. H.264 Series Board 2-2. Accessories 2-3. Optional Accessories 3. Board Description 3-1. 12004 H 3-2. 24008 H 3-3. 48016 H 3-4. 96032 H Slave 3-5. I/O Board 4.
  • Page 3 DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, 12004H, 24008H, 48016H and 96032H Slave boards. The pictures and the name of the products are subject to change; however, the usage may be similar.
  • Page 4: Specification Of Divis

    Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it. Motion Detection and Sensor Trigger Detection features make it possible to record images only when movement is detected, preserving volume space and maximizing the use of physical storage space.
  • Page 5 Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. POS, Access Control, ATM Support Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images.
  • Page 6: Products And Components

    DiViS www. DVR.com 2. Product and Components 2-1. H.264 Series Board 12004H 24008H 48016H 96032H Slave DiViS...
  • Page 7: Accessories

    DiViS www. DVR.com 2-2. Accessories 4ch Video & Audio Pigtail Cable 8ch Video Pigtail Cable 8ch Audio Pigtail Cable 16ch Video Pigtail Cable 16ch Audio Pigtail Cable Reset Cable Sensor & Relay Cable Sensor Board DiViS...
  • Page 8: Optional Accessories

    DiViS www. DVR.com 2-3. Optional Accessories RS-485 Board RS-485 Board (for 32ch) RS-232C Cable I/O Board Sensor & Relay Cable Sensor Board Video Cable Back Panel TV-OUT cable 1(for 32ch) TV-OUT cable 2(for 32ch) DiViS...
  • Page 9: Board Description

    DiViS www. DVR.com 3. Board Description 3-1. 12004H TV OUT Connector I/O Connector Video and Audio Factory use Watchdog Connector 3-2. 24008H TV OUT Select TVOut (spot) TVOut (split) Extension Relay Jumper Connector Connector connector Camera 1 ~ 8 I/O Board Connect...
  • Page 10: H Slave

    DiViS www. DVR.com 3-3. 48016H TV OUT Select TVOut (spot) TVOut (split) Extension Relay Jumper Connector Connector connector Camera 1 ~ 8 I/O Board Connect Audio 1 ~ 8 1 ~ 4 Back Panel Factory use Watchdog 5 ~ 8...
  • Page 11: I/O Board

    DiViS www. DVR.com 3-5. I/O Board DiViS...
  • Page 12: Installation

    DiViS www. DVR.com 4. Installation 4-1. 12004H 1) Connect 1~4 channel video pigtail cable to connector. 2) Connect 1~4 channel audio pigtail cable to connector. 3) Connect CCTV monitor. 4) Connect the other side of the I/O cable to the I/O connector 5) Connect I/O cable to the sensor port 6) Connect watchdog cable.
  • Page 13: Pigtail Type

    DiViS www. DVR.com 4-2. 24008H 4-2-1. Pigtail type 1) Connect 1~8 channel video pigtail cable the top connector. 2) Connect 1~8 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect the other side of the I/O cable to the I/O connector.
  • Page 14: Back Panel Type

    DiViS www. DVR.com 4-2-2. Back Panel Type 1) Back Panel. 2) Sensor Cable. 3) With white cable facing up, connect video cables to back panel leaving just one bottom pin. 4) Connect TV-Out cable to the top pin of back panel. (make sure the white cable is facing up) 5) Connect the other side of the TV-Out cable to the capture board.
  • Page 15: Pigtail Type

    DiViS www. DVR.com 4-3. 48016H 4-3-1. Pigtail type 1) Connect 1~16 channel video pigtail cable to the top connector. 2) Connect 1~16 channel audio pigtail cable to the bottom connector. 3) Connect CCTV monitor. 4) Connect I/O cable to the sensor port.
  • Page 16: Back Panel Type

    DiViS www. DVR.com 4-3-2. Back Panel Type 1) Back Panel. 2) Sensor Cable. 3) With white cable facing up, connect video cables to back panel leaving just one bottom pin.. 4) Connect TV-Out cable to the top pin of back panel. (make sure the white cable is facing up) 5) Connect the other side of the TV-Out cable to the capture board.
  • Page 17 DiViS www. DVR.com 4-4. 96032H DiViS...
  • Page 18 DiViS www. DVR.com 1) Connect 1~16 channel video pigtail cable to the top connector of the master board. 2) Connect 1~16 channel audio pigtail cable to the bottom connector of the master board. 3) Connect 17~32 channel video pigtail cable to the top connector of the slave board.
  • Page 19: Accessories

    DiViS www. DVR.com 5. Accessories 5-1. Back Panel Camera I/O Sensor & Relay (Digital I/O) Camera Ground 3, 5, ~ 31, 33 Sensor Input 0~15 1~16 Camera Signal 4, 6, ~ 32, 34 Input Common 0~1 17, 18 TV Out Ground...
  • Page 20: Video And Audio Pigtail Cable

    DiViS www. DVR.com 5-2. Video and Audio Pigtail cable 5-2-1. Video and Audio Pigtail 4ch, 8ch cable Video Pigtail cable Audio Pigtail cable 1~4 BNC : Black BNC 1 : Blue con 2 : Yellow con 3 : Green con...
  • Page 21: Pigtail 16Ch Cable

    DiViS www. DVR.com 5-2-2. Video and Audio Pigtail 16ch cable Video Pigtail cable Audio Pigtail cable 1 ~ 4 : Blue BNC 1, 9 : Red con 5, 13 : Blue con 5 ~ 8 : Orange BNC 2, 10 : Orange con...
  • Page 22: Rs-232 To Rs-422/485 Converter

    DiViS www. DVR.com 5-4. RS232 to RS422/485 Converter * Use Rx+ and Rx- for RS 485 method. - TxData + TxData - RxData + RxData Signal 1) Connect to system’s Com port. 2) Connect to PTZ port converter RS-485 + TV-OUT board 3) Connect a power source to any one of these power sockets.
