  • Page 1 DiViS DVR HD-SDI Series Rev. 1.0 Hardware Installation Guide Digital Video Security System Digital Video Recorder www.DiViSdvr.com DiViS DVR.com *All contents of this document may change without prior notice, and actual product appearance may differ from depicted herein.

  • Page 2: Table Of Contents

    DiViS www. DVR.com Index 1. Specification of DiViS HD 2. Installation Notes 2-1. Recommendation for 12004HDH & 24008HDH 2-2. Recommendation for 48016HDH 3. Products and Components 3-1. DiViS HD Series Board 3-2. Optional Accessories 4. Board Description 4-1. 12004HDH 4-2. 24008HDH 4-3.
  • Page 3 DVR board. For the software explanation, please refer to “Installation and User’s Guide”. This guide book is applicable to, among DiViS products, 12004HDH, 24008HDH & 48016HDH board. The pictures and the name of the products are subject to change; however, the usage may be similar.

  • Page 4: Specification Of Divis Hd

    Multi-Viewing allows 1, 4, 6, 9, 10, 16 different camera shots to be displayed onscreen at the same time. Other display features include enlarging all displayed cameras or just one. ㆍ PAN/TILT/ZOOM/FOCUS Capabilities Each connected camera can be manipulated through the DiViS main program as long as each camera supports such capabilities. ㆍ Auto Rebooting System When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order to correct it.
  • Page 5 ㆍ Network Support (PSTN, TCP/IP, LAN ,Modem Protocol Support) DiViS supports network access, which allows administrators to login to DiViS main and remotely access all the features provided locally. ㆍ POS, Access Control, ATM Support Record data from external devices(POS, Access Control, ATM, etc)with DVR video images.

  • Page 6: Installation Notes

    DiViS www. DVR.com 2. Installation Notes 2-1. Recommendation for 12004HDH and 24008HDH - Recommend to use Intel Chipset mother board. I) Not compatible with mother boards that are specifically designed such for Small Form Factor (SFF-Mobile). - Minimum of Intel Core i3 CPU recommended. (Higher than Clarkdale or Lynnfield) I) Recommend to use Intel Ivy Bridge Chipset with Intel Core i7 for best results.

  • Page 7: Products And Components

    DiViS www. DVR.com 3. Products and Components 3-1. DVR Board 12004HDH 24008HDH 48016HDH 3-2. Optional Accessories Sensor Port Sensor Cable RS-485 Board USB RS-485 board cable DiViS...

  • Page 8: Board Description

    DiViS www. DVR.com 4. Board Description 4-1. 12004HDH 1) BNC connector: Connect BNC cable 1 ch. 2) BNC connector: Connect BNC cable 2 ch. 3) BNC connector: Connect BNC cable 3 ch. 4) BNC connector: Connect BNC cable 4 ch.

  • Page 9: 24008Hdh

    DiViS www. DVR.com 4-2. 24008HDH 6 6 7 DiViS...
  • Page 10 DiViS www. DVR.com 1) BNC connector: Connect BNC cable 1 ch. 2) BNC connector: Connect BNC cable 2 ch. 3) BNC connector: Connect BNC cable 3 ch. 4) BNC connector: Connect BNC cable 4 ch. 5) Factory use 6) I/O Board connector: Connect I/O Board.

  • Page 11: 48016Hdh

    DiViS www. DVR.com 4-3. 48016HDH DiViS...
  • Page 12 DiViS www. DVR.com 1) BNC connector: Connect BNC cable 1 ch. 2) BNC connector: Connect BNC cable 2 ch. 3) BNC connector: Connect BNC cable 3 ch. 4) BNC connector: Connect BNC cable 4 ch. 5) Factory use 6) I/O Board connector: Connect I/O Board.

  • Page 13: I/O Board

    DiViS www. DVR.com 4-4. I/O board Bottom side Top side 1) I/O Connector: Connect I/O Cable. 2) Board Connector: Connect to the upper I/O board connector of the capture board. 3) Board Connector: Connect to the lower I/O board connector of the capture board.

  • Page 14: Installation

    DiViS www. DVR.com 5. Installation 5-1. 12004HDH Installation 1) Connect 1~4 channel video BNC cable to the connector. 2) Connect Power cable 3) Connect I/O cable to the sensor port. 4) Connect the other side of the I/O cable to the I/O connector.

  • Page 15: 24008Hdh Installation

    DiViS www. DVR.com 5-2. 24008HDH Installation 1) Connect 1~4 channel video BNC cable to the connector. 2) Connect Power cable 3) Connect I/O cable to the sensor port. 4) Connect the other side of the I/O cable to the I/O connector.

  • Page 16: 48016Hdh Installation

    DiViS www. DVR.com 5-3. 48016HDH Installation DiViS...
  • Page 17 DiViS www. DVR.com 1) Connect 1~4 channel video BNC cable to the connector. 2) Connect Power cable 3) Connect I/O cable to the sensor port. 4) Connect the other side of the I/O cable to the I/O connector. 5) Connect watchdog cable. (Black cable must go bottom of the connector) 6) Connect 4~8 channel video BNC cable to the connector.

  • Page 18: Accessories

    DiViS www. DVR.com 6. Accessories 6-1. USB to RS 422/485 Converter PTZ Device Port Convertor 1) Connect to a COM port on system motherboard. 2) Connect the other side of this cable to RS-485 Board. 3) They are power sockets. It requires connection to only one of them.
