Summary of Contents for Divis CHSM48016
- Page 1 DiViS CHSM48016 - Stand Alone Installation and User’s Guide Rev. 2.0 Digital Video Security System Digital Video Recorder www.DiViSdvr.com Chance-i USA Corp. * All contents of this document may change without prior notice, and actual product appearance may differ from that depicted herein.
-
Page 2: Safety Precaution
Do not insert any metallic object through ventilation grills. Power disconnect: Units with or without ON-OFF switches have power supplied to the unit whenever the power cord is inserted into the main source. To disconnect it from the main source, you have to disconnect the Power cord. DiViS... -
Page 3: Fcc Compliance Statement
Operation of the this equipment in a residential area is likely to cause harmful interference in which cause the user will be required to correct the interference at his own expense. DiViS... - Page 4 Preface This document is a basic manual for the DiViS CHSM48016 users. The manual describes the appearance and name of products, how to configure the system program, and how to use the system. Please review the whole contents before using DiViS CHSM48016, and access the product with caution.
- Page 5 Do not place a heavy object on the body. • Handle with care while moving the equipment. In case of any smoke or odor emitted, immediately block the power switch and contact the company you purchased the products to consult it with a special technician. DiViS...
-
Page 6: Table Of Contents
6-2. Search by Recording Type 6-3. Search by Time & Date 6-4. Playback 6-5. Backup 7. USB Mouse Operation 7-1. Mouse Operation on Live Display 7-2. Mouse Operation on Search 8. Firmware Update Appendix 1. DiViS CHSM48016 Specification Appendix 2. Description of Terminals DiViS... -
Page 7: Product Contents
1. Product Contents At the point of purchase, please verify that following contents are included: • DiViS CHSM48016 - 16CH MPEG-4 Stand Alone DVR • Power Supply (12V/5.8A) • Power cord • User’s manual • Install CD • Remote controller (two ‘AAA’ batteries included) -
Page 8: Features
2. Features is an embedded Stand-Alone DVR, based on Linux. It is capable to record 16 DiViS CHSM48016 channels of video and audio. It is also capable to playback, live display, back-up and network function while it is continuously recording. And it also offers the following features: •... -
Page 9: Product Description
16 Loop-Through outputs Cameras (1~16 Ch.) 3 Composite & • • • • • 1 S-Video Output 2 Audio Power RS232 Outputs Supply 16 Audio Inputs (12V, 5.8 A) 4 Alarm 16 Sensor Outputs Inputs 1 VGA Output (Ethernet) DiViS... -
Page 10: Front Panel Description
+ ENTER: Display system information (video format, HDD info, IP Address, version, etc.). • FUNC + MENU : Opens interface to select a channel for audio output. • FUNC + ESC : Turns on/off motion detection display, for channels with motion recording. DiViS... - Page 11 12) FF This button controls fast forward speed under playback mode, supports 2 to 16 times playback speed as pressed repeatedly. Also, it controls zoom-in under PTZ mode. 13) MENU This button is to enter main menu of DVR. DiViS...
-
Page 12: Rear Panel Description
3-4. Rear Panel Description 1. 16 Ch. Video Input: 16 channels of composite video inputs with BNC connectors. DiViS CHSM48016 automatically detects video format (NTSC or PAL) at power on, and both NTSC and PAL video sources are acceptable. - Page 13 11. RS485 Connect to PTZ cameras to control through DVR system. 12. Ethernet Port (RJ-45) Connect to the network to allow remote connection over the network. Remote connection allows users to access live monitoring, searching and other available functions via the network. DiViS...
-
Page 14: Remote Controller
4. “F1” + “1, 2, 3… 0, +10”: Select a Remote Controller ID. Once the ID is selected, only the DVR with corresponding Remote Controller ID will receive command. It is applicable only for DVR units that have REMOTE ID configured (refer to Chapter 4-3.System Setup). DiViS... -
Page 15: Main Menu Programming
CAMERA 4-1. Overview Main Menu Before using DiViS CHSM48016 for the first time, it is necessary to initialize the system with information that need to be manually adjusted, such as time and date, password, display mode, recording mode, network configuration and so on. -
Page 16: Dvr Menu Tree
4-2. DVR Menu Tree DiViS... -
Page 17: System Setup
PTZ, remote in via network, and change private option. Note: While changing the name of a sub user, on screen keyboard will be available as shown on the left. Press MODE to toggle between different sets of characters. DiViS... - Page 18 11. FACTORY RESET Return to factory default setting value. Note: When all of settings are finished and exiting from the main menu, the user will be prompted as shown below. Check box must be selected to apply all of changes made. DiViS...
-
Page 19: Display Setup
9. CH QUALITY SET Adjust brightness, contrast, hue, and saturation on the selected channel. Once selected, each attributes can be adjusted between 1% and 99%. 10. QUALITY RESET Reset quality controls including brightness, contrast, hue, and saturation to the factory initial values. DiViS... -
Page 20: Recording Setup
(All 16 Ch.) NTSC Max. 480 Fps Max. 400 Fps 2 CIF (Half D1) Max. 240 Fps Max. 200 Fps 4 CIF (Full D1) Max. 120 Fps Max. 100 Fps * CIF: 320 x 240 in NTSC, 320x 288 in PAL DiViS... -
Page 21: Event Setup
VERY HIGH. Sensor: Select sensor type between NO and NC. Input: Select an input from 1 ~ 16. Out: Select a relay output from 1 ~ 4. Buzzer: Turn ON or OFF the audible warning upon event detection. DiViS... - Page 22 ESC: Exit from motion area setting and returns to the event setup. Note: While selecting segment(s) for motion area Func (F1 on remote controller) toggles selection as following: • FUNC + 1: Select all • FUNC + 2: Deselect all • FUNC + 3: Reverse selection DiViS...
-
Page 23: Schedule Setup
FUNC + 1: Apply selected value (Event or Manual) to all segments • FUNC + 2: Cancel all and clear recording schedule. • FUNC + 3: Reverse selection. Scheduled (Event or Manual) to blank and blank to selected value. DiViS... -
Page 24: Network Setup
DDNS Status must be OK, which ensure the internet accessibility. 7. DDNS STATUS Display Dynamic DNS status and address of it. STATUS will display OK while normally connected, NONE if DDNS is not used, and ERR if DDNS IP update failure. DiViS... -
Page 25: Copy Setup
Note: Backup File Player will be automatically copied with copied data files. The application is simple version of File Player. For the usage of Backup File Player, please refer to the description of File_Player on the software manual. For actual Copy (Backup) procedure, please refer to chapter 6-5. Backup (page 34). DiViS... -
Page 26: Hard Disk Setup
First recorded area in HDD can be replaced with new recording data. 2. FORMAT HDD Execute formatting HDD. Once the formatting is done, “Format Complete” message will be displayed. 3. INFO Display installed HDD information, including a number of HDD installed, total HDD capacity mounted, and available space on it. DiViS... -
Page 27: Camera Setup
3. PTZ TYPE Select a type of PTZ protocol if applicable. In order to control PTZ cameras from the DVR system and remote, it is necessary to properly set this section. DiViS CHSM48016 supports following protocols: DiViS- D, Panasonic, Pelco-D, Pelco-P, Techwin, Niko, DRX502A (DSC230s), KRE 302 (301), GC755NP, TOA (CC) 554, RAS716(LS), LPF100, KD, INTR-M, LILIN MLP2 and so on. -
Page 28: Live Display & Recording
5. Live Display & Recording DiViS CHSM48016 supports full picture, quad picture, 9 picture and 16 picture view along with sequential switching mode. Also it supports event popup if motion or alarm event is configured. 5-1. Live Picture Display Mode 1. -
Page 29: Osd (On Screen Display) On Live Mode
1 through Ch.16. 6. Live audio selection for speaker output DiViS CHSM48016 allows recording audio per each channel of video inputs, and audio outputs are available for only one selected channel at a time. In order to select an audio channel for audio output, press FUNC... -
Page 30: Ptz Control
6. To exit from PTZ control mode, press ENTER. The PTZ mode icon will be disappeared. 5-4. Recording Options DiViS CHSM48016 is capable to record 16 channels of video and audio simultaneously, real-time (30 FPS) for each channel. Also each channel can be independently configured for its resolution, recording quality, frame rate, audio recording and so on. -
Page 31: Search And Backup
4. Calendar Display days with available data based on OPTION selected. The calendar displays the month that corresponds to the selected DATE. 5. EXIT Return to the monitoring screen by exit button on the front panel or remote controller. DiViS... -
Page 32: Search By Recording Type
) button to search a specific date and time. The following screen will be displayed: The user is able to select specific date and time to start playback. Once the date and time are selected, press ENTER to playback from that moment. Refer to 6-4.Playback for detail instruction on playback. DiViS... -
Page 33: Playback
4. Jog and Shuttle: It is convenient controller to control playback speed easily. Works same as fast forward and rewind explained above. 5. Live audio selection for speaker output DiViS CHSM48016 allows the user to retrieve video and audio simultaneously. Similar to audio selection under live display mode, press FUNC... -
Page 34: Backup
ENTER. Note: On DiViS CHSM48016, recorded data is managed in the unit of each hour. Copy start time and end time should be within same hour frame. For example, if 9:50 AM ~10:05 AM needs to be backed up, the user must perform copy twice: once for 9:50:00 AM ~ 9:59:59 AM, and then 10:00.00 AM ~ 10:05:00 AM. -
Page 35: Usb Mouse Operation
7. USB Mouse Operation DiViS CHSM48016 supports USB Mouse to control the unit along with the front panel buttons and the remote controller. For the convenience, connect a USB mouse (which is not included) to the port available on the front panel. All icons under main menu are accessible with mouse. -
Page 36: Mouse Operation On Search
Press this icon to stop playback and back to search screen, same as STOP on the front panel. Press these icons to control playback direction and speed (-16 ~ 16), same as REW and FF on the front panel. Press this button to close this icon set for mouse operation. DiViS... -
Page 37: Firmware Update
4. While update is in progress, “Please wait” will be displayed, and when it is done, the system will be automatically reboot to complete update. 5. After the system is rebooted, please check on the setting to make sure the version information is changed to the new version. DiViS... -
Page 38: Appendix 1. Divis Chsm48016 Specification
Appendix 1. DiViS CHSM48016 Specification Description Specification Input 16CH, composite Video, BNC Video 2 Ch. Monitor / 1 Ch. Spot / 16 Ch. Loop-through / 1 S-Video / 1 Output VGA Output (Max. 1024x768) Audio Input/Output 16 Ch. Input / 2 Ch. Output... -
Page 39: Appendix 2. Description Of Terminals
SHIELD SYNC Not Used Not Used 3. RS232 Pin Descriptions Slave Unit like PTZ Camera Pin NO. Pin description Pin NO. Pin description RS485 D+ (TX +) RS485 D+ (RX +) RS485 D- (TX -) RS485 D- (RX -) DiViS... - Page 40 GND (Common) GND (Common) Relay output NO4 Sensor input 09 Relay output NC4 Sensor input 10 GND (Common) Sensor input 11 Sensor input 12 GND (Common) Sensor input 13 Sensor input 14 Sensor input 15 Sensor input 16 GND (Common) DiViS...
- Page 41 Pin description RS485 D+ (TX +) RS485 D+ (RX +) RS485 D- (TX -) RS485 D- (RX -) 6. LAN port (RJ-45) Pin Descriptions Pin NO. Pin description TXD+ TXD- RXD+ Not Used Not Used RXD- Not Used Not Used DiViS...
