Summary of Contents for Bodyworx JX740

  • Page 2: Overview Drawing

    1. OVERVIEW DRAWING...

  • Page 3: Important Safety Instructions

    2. IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the followings: Read all instructions before using the treadmill. DANGER – To reduce the risk of electric shock: Always unplug this appliance from the electrical outlet immediately after using and before cleaning.

  • Page 4: Grounding Instructions

    3. GROUNDING INSTRUCTIONS The products must be grounded first. If malfunction or breakdown occurs, grounding will provide a path of least resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug.

  • Page 5: Motorized Treadmill Pre-Assembly

    4. MOTORIZED TREADMILL PRE-ASSEMBLY Handrail control button and heart rate strap are optional items in the package 1. Heart rate can be measured in this treadmill. Attach strap to chest during exercise, the heart rate value will display on the PULSE window. 2.

  • Page 6: Assembly Steps

    5. ASSEMBLY STEPS 1. After pull out Control Wire with Guide Thread in right Upright (D), put left and right Uprights (C, D) to the suitable place and then fix with Allen Bolt (b). Ps. To avoid unexpected accident, always assemble the treadmill with an assistant, do not assemble by oneself.
  • Page 7 3. Turn Handlebar Assembly upwards and connect with the Computer. Tighten with Allen Bolt (c). 4. Put Computer Console (A) on the treadmill and connect all control wires. Then thread them into the tube of the left and right Handrails. Assemble Computer Console to the Handrails and fix with Screw (d).
  • Page 8 5. After finish above steps, cap left and right Upper Handrail Covers (G, H) and Lower Handrail Covers (I, J) to the Uprights. Fix with Self Tapping Screw (e). Ps. When fix the screws, pay attention that do not damage control wires in the tube. Ps.
  • Page 9 6. CAUTION Note: Made of high pressure, the cylinder must be takeN care to avoid danger caused by the impact with other objective. Note: If the cylinder is hit, it may cause damage and make the use not smooth. When the user is folding the treadmill, it may result in the falling of the frame and cause injury.

  • Page 10: Maintenance

    7. MAINTENANCE 1. Walking Belt Centering. If the Walking Belt tracks off center to the right or left of the deck, first turn the power off. Then use 6mm Allen wrench to tighten the rear roller bolt on the side of the treadmill toward which the belt is moving.

  • Page 11: Start Display

    8. COMPUTER OPERATION INSTRUCTIONS This picture is the jack of MP3. If the machine has MP3 function, it will have this jack. Start Display: This picture is the jack of MP3. If the machine has MP3 function, it will have this jack.

  • Page 12: Edit Mode

    does not need to set in PROGRAM. It means you can use the value after starting. You must set newly after starting again. 2. During working, the beeper will make a sound for warning if the safety key works off, then the treadmill will stop working.

  • Page 13: Program Mode

    STOP is the only function which can be carried out. 4. PROGRAM has 32 levels in all. The three anterior are WARM UP，the three later are COOL DOWN. Everyone is 3 minutes. The setting time except anterior and later which mean 6 minutes will be execute averagely by surplus 26 levels.
  • Page 14 this function to edit the values. Time setting range: 5~99 minutes，the preset value is 20 minutes, step is 1 minute. Distance setting range:1~99 kilometers，the preset value is 5 kilometers，step is 1. Calorie setting range: 40~999 calories，the preset value is 200 calories，step is 1. 1.1.
  • Page 15 PROGRAM has 32 levels in all (SE01~SE32) and the pre-set values all are lowest value. Setting：time，program execute value (setting time can execute in 32 level averagely） . P10 HRC distinguish as 65%、75%、85%、THR (Target Heart Rate) This function must be attached with heart beat to finish.) Dot Matrix window displays HRC.
  • Page 16 status. ** The chart below will show the relationship between different age and heart rate of this product of HRC function ： Pre-set Pre-set Pre-set Pre-set ●PULSE function: It will start to detect the message under sport mode, the calculation range is 40～220.
