6
Fuel cutoff lever
Dump body support rod
Dump lever
LOWER
Lock plate
Operation
Stopping with Fuel Cutoff Lever
1. Open engine cover.
2. Move fuel cutoff lever to stop the engine.
Do not open engine cover while engine is running. If
it is absolutely necessary to open engine cover while
engine is running, pay attention to moving or hot
parts.

6.5 Operating Dump

If any part of your body is under the load deck while it is raised and
the load deck falls, you could be seriously injured or killed. If you
must place any part of your body under the load deck when the deck
is raised, engage the load deck drop prevention safety prop before
doing anything else under the raised load deck. Bystanders may be
injured or killed if struck by the loading deck when it is being raised
or lowered or by a load being dumped from the load deck. Be certain
that no one is in the immediate vicinity of the machine when raising or
lowering the load deck or when dumping a load from the load deck.
Raising or lowering the load deck on a steep slope can make the
machine unstable, causing it to shift suddenly or to turn over.
If the machine shifts suddenly or turns over, you or bystanders could
be seriously injured or killed, or the machine could be damaged.
Avoid performing dump operations on a steep slope. If performing a
dump operation on a slope is unavoidable, bring the machine to as
level position as possible by driving the treads over a fallen tree or
some other large, immobile object.
When Raising Dump Body
1. Start the engine, move the accelerator lever to the
[ (HI)]position, and raise the engine speed.
2. Remove the lock plate from the dump lever.
RAISE
3. Move the dump lever gradually to the [
position.
4. When the dump body is raised to the upper limit,
a relief sound (hiss) is heard, so return the dump
lever quickly to the [HOLD] position.
-29-
WARNING
WARNING
WARNING
6
(RAISE)]
