Summary of Contents for Ganz ZN-S100AE
-
Page 2: Table Of Contents
Table of Contents 1. Introduction............................4 2. Product Description .......................... 5 2.1. Specifications..........................5 2.2. Functions ..........................6 2.2.1. Front Panel........................6 2.2.2. Rear Panel ........................8 2.3. Serial Number / MAC Address....................13 3. Installation ............................14 3.1. Basic Connections ........................14 3.2. -
Page 3: Safety Precautions
Safety Precautions Users are strongly advised to adhere to directions and recommendations offered in this manual. Failure to do so may result in problems during operation. • Make sure the correct voltage is being supplied before turning the power ON. •... -
Page 4: Introduction
ZN-S100AE, ZN-S1000AE, ZN-S2000AE and ZN-S4000AE compress video/audio data and transmit the compressed video/audio data through the network in real time. GANZ encoder provides a high quality video image with a limited bandwidth and storage capacity. These products are ideally suited for a wide range of surveillance and remote monitoring applications. -
Page 5: Product Description
GANZ MPEG-4 Encoder Series Hardware Manual 2. Product Description 2.1. Specifications GANZ encoder series specification is shown as following Table 1. ZN-S100AE ZN-S1000AE ZN-S2000AE ZN-S4000AE 1ch MPEG-4 1ch MPEG-4 2ch MPEG-4 4ch MPEG-4 25/30fps@D1 25/30fps@D1 50/60fps@D1 100/120fps@D1 Single Dual Single... -
Page 6: Functions
Status LED is turned on. After completion of booting, for a successful network connection, the green Network LED blinks indicating that data is being transmitted. If network connection fails, please check the LAN cable is connected or restart GANZ encoder. 2. Video streaming service When an application runs, the Status LED blinks each second. - Page 7 Vout is used for ZN-S4000AE to display quad, switching view in external monitor. ⑦ Reset Switch (Reset) Reset switch is used for restarting GANZ encoder or resetting GANZ encoder as Factory Default (FD). Refer to ‘4.1. Factory Default Settings’ for detailed procedures.
-
Page 8: Rear Panel
⑩ ⑪ ⑫ Figure 3. Rear Panel of ZN-S100AE ①, ⑨ Audio Input Jack (Ain 1,2 and Ain 3,4) ZN-S2000AE and ZN-S4000AE have mono audio input channels using stereo audio socket. Therefore, a special cable is needed to connect audio devices. There are two kinds of cables. Stereo cable is a stereo jack to 2 RCA connectors (for ZN-S2000AE/4000) and Mono cable is a mono jack to 1 RCA connector (for ZN-S100AE and ZN-S1000AE). - Page 9 (Detailed instructions are being prepared.) ② Audio Output Jack (Aout) GANZ encoder provides one mono audio by using the stereo socket. Even if a stereo speaker is connected, the both side have the same sound (mono output). GANZ encoder audio outputs very low-watt, therefore it requires amplifier speaker (Do not use headphone /earphone directly) Figure 7.
- Page 10 GANZ MPEG-4 Encoder Series Hardware Manual ③ Digital Input (DI 1~4) ZN-S1000AE/2000 use 6 port terminal block for 2 channel Digital Outputs. ZN-S4000AE uses 8 port terminal block for 4 channel Digital Outputs as shown Figure 2. It can be connected either voltage type sensor or relay type sensor as following Figure 8 and Figure 9.
- Page 11 GANZ MPEG-4 Encoder Series Hardware Manual Figure 9. Relay Type Digital Input Connection Please pay attention to electric characteristics during installation. (Detailed instructions are being prepared.) ④ Digital Output (DO 1~4) ZN-S1000AE/2000 use 6 port terminal block for 2 channel Digital Outputs. ZN-S4000AE uses 8 port terminal block for 4 channel Digital Outputs as shown Figure 2.
- Page 12 ZN-S4000AE needs a DC 12V 3A adapter for power supply, and ZN-S1000AE/2000 uses a DC 12V 1A adapter. ⑫ Reset Switch (Reset) Reset switch is used for restarting GANZ encoder or resetting GANZ encoder as Factory Default (FD). Refer to ‘4.1. Factory Default Settings’ for detailed procedures. ⑬ Video Input BNC Connector (Vin) This connector is used for video input.
-
Page 13: Serial Number / Mac Address
GANZ MPEG-4 Encoder Series Hardware Manual 2.3. Serial Number / MAC Address Serial number and MAC address is attached on the bottom as shown in Figure 13. 550012345 MAC Address MAC 00-1C-B8-C0-14-B1 ZN-S4000AE P122404010000-10002 Serial Number Figure 13. Serial Number/ MAC Address... -
Page 14: Installation
GANZ MPEG-4 Encoder Series Hardware Manual 3. Installation 3.1. Basic Connections Figure 14 and Figure 15 illustrate the basic connection of ZN-S4000AE. Figure 14. Front Panel Connection 2010/2-1 O... -
Page 15: Package Contents
- AC100 ~ AC 240V power cable is included ZN-S4000AE uses a 12V 3A adaptor. ZN-S100AE, ZN-S1000AE and ZN-S2000AE use a 12V 1A adaptor. ZN-S4000AE uses 8 port x 2ea terminal blocks. ZN-S1000AE and ZN-S2000AE use 6 port x 2ea terminal blocks. -
Page 16: Installation Example
GANZ MPEG-4 Encoder Series Hardware Manual 3.3. Installation Example Figure 16. GANZ encoder series Application Example Normal operation may not be possible if temperature or humidity exceed levels recommended in the GANZ encoder specification. Problems may also occur in wireless environments. 2010/2-1 O... -
Page 17: Operation Description
GANZ MPEG-4 Encoder Series Hardware Manual 4. Operation Description 4.1. Factory Default Settings Factory default settings are as follows: • IP address: 192.168.xx.yy (refer to 2.3 Serial Number / MAC Address) • Mask: 255.255.0.0 • Gateway: 192.168.0.1 • User ID: root •... -
Page 18: Power Over Ethernet (Poe)
The PoE module used in GANZ encoder is commercially available module without modification. The standard GANZ encoder does not include PoE module in it. PoE module is included on the request of a customer. For the detailed information, please contact sales person. -
Page 19: Poe Compatibility
GANZ MPEG-4 Encoder Series Hardware Manual Figure 19. ZN-S1000AE without PoE module Figure 20. ZN-S1000AE with PoE module installed 5.3. PoE compatibility With non Power Sourcing Equipment (PSE) When it is connected with non PSE, the power adaptor should be connected. -
Page 20: Power Classfication
GANZ MPEG-4 Encoder Series Hardware Manual 5.4. Power classfication The PoE Power Class supported by GANZ network camera/encoder is as following Table 4. Model Power Class ZN-D310AE ZN-D(N)T3500AE ZN-S100AE ZN-S1000AE ZN-S2000AE ZN-S4000AE Table 4. Power Class supported by GANZ network camera/encoder Table 5 shows IEEE 802.3af power classes. -
Page 21: Electrical Characteristics
GANZ MPEG-4 Encoder Series Hardware Manual 6. Electrical characteristics 6.1. Operating conditions Parameters Typical Units Video Peak to peak 1.35 input range amplitude Sync amplitude Horizontal lock % of line length ±6.2 range Color sub-carrier ±450 Lock-in range Audio input range 0.01...
