Bellini BDR603TFG Installation And User Manual

Bellini tilt black glass range hood

Hide thumbs

Quick Links

Tilt Black Glass

Range Hood

Installation and User manual

Content

Safety instructions----------------------------------------2

Product description---------------------------------------4

Operation mode-------------------------------------------5

Installation---------------------------------------------------6

Start using the range hood------------------------------11

Maintenance and cleaning------------------------------14

Warranty-----------------------------------------------------15

For warranty service call 1300 373 199(Australia)

or 0508 123108 (New Zealand) to connect you to

the nearest authorised service centre

20131119 Issue 0

BDR603TFG

BDR603TFG-F

BDR903TFG

BDR903TFG-F

Need help?

Do you have a question about the BDR603TFG and is the answer not in the manual?

Questions and answers

Summary of Contents for Bellini BDR603TFG

Page 1: Table Of Contents
Safety instructions----------------------------------------2 Product description---------------------------------------4 Operation mode-------------------------------------------5 Installation---------------------------------------------------6 Start using the range hood------------------------------11 Maintenance and cleaning------------------------------14 Warranty-----------------------------------------------------15 For warranty service call 1300 373 199(Australia) or 0508 123108 (New Zealand) to connect you to the nearest authorised service centre BDR603TFG BDR603TFG-F BDR903TFG BDR903TFG-F...
Page 2: Safety Instructions
Safety instructions This manual explains the proper installation and use of your range hood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. Never to do: Always to do: This appliance is not intended for use by persons...
Page 3 Safety instructions Never to do: Always to do: This range hood cannot be installed for outdoor use. Attention should be given to ensure that any It is prohibited to fit the range hood over a solid fuel applicable regulations concerning discharge stove of exhaust air are fulfilled.
Page 4: Product Description
Product description Accessories bag Description Picture User Manual Upper decorative chimney bracket Lower decorative chimney bracket Hood mount bracket Dry wall anchors plugs Screw(ST4x8mm) Screw(ST4x30mm) Component list: Technical data: 1. Upper decorative chimney bracket 2. Upper decorative chimney(Inner) Power supply: 220 – 240v, 50Hz 3.
Page 5: Operation Mode
Operation Mode Your range hood can be operated in two optional modes, choose the mode suitable for your kitchen before installation. Air Exaction For air exaction mode, a ducting kit is required, the air is To outside drawn in and cleaned by the grease filters and directed outside.
Page 6: Installation
Installation Dimensions: BDR603TFG, BDR603TFG–F, Width=600; BDR903TFG, BDR903TFG–F, Width=900 Installation: Warning: Check that the installation complies with the standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure the mains voltage corresponds to the voltage on the appliance rating plate inside the range hood.
Page 7 1. Using a spirit level, mark a vertical line on the wall (Central to the cook top installed below) to indicate the centre location of the hood and a horizontal line where the hood base will be positioned. Drill holes as per below drawing and insert dry wall anchor plugs into holes.
Page 8 2. Fit the flexible exhaust pipe onto outlet. If choose air extraction mode, please install the flexible exhaust pipe; if choose air recirculation mode, no need to install the flexible exhaust pipe, please skip this step and jump to step 3 directly 3.
Page 9 7. Install Lower chimney 7.1 Fasten the Lower decorative chimney bracket to the wall with 2 x ST4x30mm screws, put the chimney in position.. 7.2 Sliding the chimney to adjust the chimney height. When the height you required is reached, then hang the fixing hole to the fixing screws as showed in below pictures.
Page 10 9. Extend the upper decorative chimney to desired height and fix it with the upper decorative chimney bracket by 2pcs ST4x8mm screws. 10. Operate the range hood to open the window according to below operation instruction. Remove grease mesh filter and install active charcoal filter onto motor chamber according to below drawing. * If choose air extraction mode, please skip this step;...
Page 11: Start Using The Range Hood
Start using your range hood 10 11 1. On/off button 7. Light On indicator 2. Fan speed adjustment button 8. Lamp On/off button 3. Fan speed indication bar 9. Remote receiver position 4. Fan running indicator 10. Alarm display 5. Time display 11.
Page 12 WORKING MODE. In standby mode, press , the windows will open, display & all button light will turn on and enter in working mode. Now you can start choosing fan speed. If press once, motor stop working, but light will not change statue. If you want to turn off all, press hold for 3 seconds, motor, light will stop working and window start backing, system will come back to standby mode.
Page 13 Prize up here Below shadow area is effective remote controlling area for better using the remote control.
Page 14: Maintenance And Cleaning
Maintenance and cleaning Caution: after cleaning, in working mod, press and hold • Before maintenance or cleaning is carried out, the range hood should be disconnected from the main for 2 second to turn off power supply. Ensure that the range hood is switched off at the wall socket and the plug removed.
Page 15: Warranty
Subject to the other clauses of this warranty, the Company warrants to the Consumer that the Bellini product will be free of manufacturing defects and will perform to the Company’s specifications. The benefit of this warranty extends only to the Consumer as original purchaser of a Bellini product which is installed in a residential property.
Page 16 Bellini product for service nor the service agent’s travelling costs to and from your home. 1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.

This manual is also suitable for:

Bdr903tfg Bdr903tfg-f Bdr603tfg-f
