Bellini CRHR6W02 Installation & Operation Instructions

60/90cm retractable range hood

Hide thumbs

Table Of Contents

Quick Links

INSTALLATION & OPERATION

GSM Retail Australia Pty Ltd ABN: 53 007 582 475

For Warranty and technical queries: 1300 373 199 Aust OR 64800764912 Or 0800 764 912 NZ www.belliniappliances.com.au

Model: CRHR6W02-F FN0195636 AUS Only BRA903SLX2-F FN0195635 AUS & NZ 60/90cm Retractable Range hood

INSTRUCTIONS

60/90cm Retractable Range hood

Model No

CRHR6W02

CRHR6W02-F

BRA903SLX2

BRA903SLX2-F

**Air Extraction Only

FINELINE: 0195636

FINELINE: 0195635

V4 Feb 21

Table of Contents

Need help?

Do you have a question about the CRHR6W02 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bellini CRHR6W02

Page 1 GSM Retail Australia Pty Ltd ABN: 53 007 582 475 For Warranty and technical queries: 1300 373 199 Aust OR 64800764912 Or 0800 764 912 NZ www.belliniappliances.com.au Model: CRHR6W02-F FN0195636 AUS Only BRA903SLX2-F FN0195635 AUS & NZ 60/90cm Retractable Range hood...
Page 2 GSM Retail Australia Pty Ltd ABN: 53 007 582 475 For Warranty and technical queries: 1300 373 199 Aust OR 64800764912 Or 0800 764 912 NZ www.belliniappliances.com.au Model: CRHR6W02-F FN0195636 AUS Only BRA903SLX2-F FN0195635 AUS & NZ 60/90cm Retractable Range hood...
Page 3: Table Of Contents
GSM Retail Australia Pty Ltd ABN: 53 007 582 475 For Warranty and technical queries: 1300 373 199 Aust OR 64800764912 Or 0800 764 912 NZ www.belliniappliances.com.au Model: CRHR6W02-F FN0195636 AUS Only BRA903SLX2-F FN0195635 AUS & NZ 60/90cm Retractable Range hood...
Page 4: Safety Instructions
In case of failure, only the Authorised Technical Service may repair this range hood. Otherwise the guarantee will be null and void. All Bellini Appliances are for domestic use only. Never to do:...
Page 5 Safety Instructions Never to do: Always to do: This range hood cannot be installed for outdoor use. Attention should be given to ensure that any • • It is prohibited to fit the range hood over a solid fuel applicable regulations concerning discharge •...
Page 6: Product Description
Product Description Accessories bag Description Picture Installation & User Manual Metal plate L bracket Outlet( diameter 120mm) Dry wall anchors plugs Screw (M4x10mm) Screw(ST4x30mm) Screw (ST3x12mm)* Washer* Screw (M4x35mm)* *Used in installation method B Component list: Technical data: 1. L bracket(used installation A method) 2.
Page 7: Operation
Operation Mode Your range hood can only be operated in ducting mode (Air Extraction). Air Extraction For this mode, a ducting kit is required, the air is drawn in and cleaned by the grease filters and directed outside. Ducting must be vented to outside atmosphere.
Page 8: Installation
Installation CRHR6W02, CRHR6W02-F,BRA903SLX2,BRA903SLX2-F Dimensions: Installation: Warning: Check that the installatio n complies with the standards of local building, gas and electrical authorities. Before connecting to the mains supply ensure the mains vo ltage corresponds to the voltage on the applian ce rating plate inside the range hood.
Page 9 A: Install against wall Using a spirit level mark a vertical centre line on the wall where the hood is to be positioned, and a horizontal line where the hood base will be. NOTE: The distance from the horizontal line to an electrical cooktop underneath must be minimum of 600mm &...
Page 10 Fit the outlet and flexible exhaust pipe on top of range hood body. Hang on the range hood, fasten 2pcs Screw(ST4x30mm) and L bracket onto two higher holes(with distance to horizontal line (516mm CRHR6W02/-F & BRA903SLX2/-F ), and then fasten 2pcs Screw (M4x10mm) and L bracket onto body.
Page 11 Fit the outlet on top of range hood body. Install the range hood onto the bottom of cabinet board, fasten 6pcs Screw (M4x35mm) with washers. If gap is there between range hood back and cabinet end, fasten 2pcs Screw (ST3x12mm) and metal plate onto body to fill it.
Page 12: Start Using Your Range Hood
Start Using Your Range Hood ○ ○ Speed –select speed to suit cooking conditions Lamp – Turn on/off light “O” – to switch off motor “O” – to switch off light Low( )– light frying/boiling “ ” – to switch on light Medium( ) –...
Page 13: Maintenance And Cleaning
Maintenance and cleaning Caution: GREASE MESH FILTERS • Before maintenance or cleaning is carried out, the The mesh filters can be cleaned either by hand or in range hood should be disconnected from the main the dishwasher. After cleaning ensure that the filters power supply.
Page 14: Warranty
Consumer until the expiry of three (3) year (Warranty Period). If within the Warranty Period a manufacturing defect is discovered in the Bellini product or it fails to perform to the Company’s specifications as a result of some defect in materials, components or workmanship (Defect) then the Company will, at its option, repair the Bellini product or supply a replacement Bellini product free of charge.
Page 15 1.10 If you are required to transport the Bellini product to the Company or its service agent, you must ensure it is safely disconnected by a qualified tradesman and securely packed and insured. The Company does not accept any responsibility for loss or damage of the Bellini product prior to it being received by the Company or its service agent.
