Display (IBM 5154)
You can use commercially available extension cables to more
easily reach IBM 6150 System Units. Connect this display to the
9-hole connector on the IBM PC Enhanced Graphics Adapter.
Ensure that the display power switch is off. Connect the power
cable to a grounded electrical outlet.
IBM 5154 Personal Computer Enhanced Color Display Connected
to IBM 6150 System Unit
IBM 5154
Power Cable --rt-
JI
Extension
cable
IBM Personal Computer
Enhanced Graphics Adapter
Signal Cable 9-Hole
Display Connector
p.-.• -01
AS07AOZO
Section 2. Connecting Devices 2-17
