INSTRUCTIONS
KENYON
P.O. Box 925
#8 Heritage Park Road
Clinton, CT 06413 USA
Phone:
(860) 664-4906
Fax:
(860) 664-4907
INSTALLATION
Lite-Touch Touch Control
Glass Ceramic Cook-tops
4BTC Mediterranean
4BTC Caribbean
(B44001 & B43001)
KENYON
for
™
Models:
Revision 9/16/02
Part # 006633
\\Mrpserver\KENYON ENGINEERING\MANUALS\4BTC MARINE
®
Advertisement
Table of Contents
Related Manuals for Kenyon 4BTC Mediterranean
Summary of Contents for Kenyon 4BTC Mediterranean
- Page 1 KENYON ® INSTALLATION INSTRUCTIONS ™ Lite-Touch Touch Control Glass Ceramic Cook-tops Models: 4BTC Mediterranean 4BTC Caribbean (B44001 & B43001) KENYON P.O. Box 925 #8 Heritage Park Road Revision 9/16/02 Clinton, CT 06413 USA Part # 006633 Phone: (860) 664-4906...
- Page 2 Thank you for purchasing a Kenyon glass ceramic cook-top. Kenyon glass ceramic cook-tops feature good looks and an easy-to-use surface that stays clean and stays looking like new with very little maintenance. These cook-tops are designed for recess countertop installation Installation Instructions for Kenyon Ceramic Glass Cook Tops Important- Save these instructions for the local inspector’s use.
- Page 3 This product must be installed in accordance with national electric codes, as well as state and local codes. The following table provides the correct voltage, amperage, and frequency that must be supplied to the appliance. Kenyon Part # Model Connected...
- Page 4 Step #4- Counter Top Preparation: Please read this section carefully prior to making the counter cutout. It is important to plan out your cook top installation keeping the following dimensions and distances in mind when planning your installation. Refer to cabinet/counter figure- Figure A below: A- 13 inches maximum depth of overhead cabinets B- 36 inches is minimum height of counter top above floor C- The minimum flat counter top surface that the cook-top will rest upon must be equal to or...
- Page 5 Before making the counter top cutout, check for clearance. Check to see if the cook top will clear the front and side walls of the base cabinet. It is also important to provide enough ventilation. Adequate ventilation of the space below the counter top must be provided to ensure proper operation of the cook top.
- Page 6 We recommend a very small bead of silicone sealant. Attach the two mounting brackets supplied with your Kenyon Cook Top, as shown to the inside vertical surface of the cutout. The long bracket should be mounted to the right side of cook top (control side).
- Page 7 Please refer to the table on page 3 (Step #2) for appropriate electrical requirements. Kenyon Cook top is supplied with a 48 inch long conduit for a connection to an accessible junction box. The conduit consists of three insulated wires.
