Lite-Touch
Use & Care Guide - Installation Manual
Kenyon International, Inc.
P.O. Box 925
8 Heritage Park Road
Clinton, CT 06413 USA
Phone: 860-664-4906
Fax: 860-664-4907
www.cookwithkenyon.com
Q & Lite-Touch
™
120, 208, and 240 V Models
Q Cortez Cooktops
™
Part # 143719
Created: October 20, 2010
Revised: December 28, 2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kenyon Lite-Touch Q
Summary of Contents for Kenyon Lite-Touch Q
- Page 1 Q & Lite-Touch Q Cortez Cooktops ™ ™ Use & Care Guide - Installation Manual 120, 208, and 240 V Models Kenyon International, Inc. P.O. Box 925 8 Heritage Park Road Clinton, CT 06413 USA Phone: 860-664-4906 Part # 143719...
-
Page 2: Table Of Contents
Table of Contents Section Page Important Safeguards ........................ Product Specifications ......................Installation Instructions Step # 1 - Unpacking the Cooktop ..................Step # 2 - Checking the Electrical Supply Requirements ..........Step # 3 - Countertop Preparation ..................Step # 4 - Installing the Cooktop ..................Step # 5 - Electrical Connection .................. -
Page 3: Important Safeguards
User Servicing Do not repair or replace any part of the appliance. If service ever becomes necessary, this appliance should be serviced by AUTHORIZED PERSONNEL ONLY or call KENYON Customer Care at (860)664-4906. Storage in or on Appliance Flammable materials should not be stored above, under or near surface cooking units. - Page 4 Do not cook on broken cooktop. If cooktop should break, cleaning solutions and spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact an authorized service center or KENYON Customer Care immediately at (860) 664-4906. Clean cooktop with caution.
-
Page 5: Product Specifications
PRODUCT SPECIFICATIONS Lite-Touch™ Q Series 2-Burner Large Models B41540 - 120V AC - one 6.5” (165mm) @ 1200 watts one 8” (200mm) @ 1400 watts B41549 - 208V AC- one 6.5” (165mm) @ 1200 watts one 8” (200mm) @ 1800 watts B41541 - 240V AC - one 6.5”... - Page 6 Lite-Touch™ Q & Lite-Touch Q Cortez Series 2-Burner Trimline Models ™ B41575 & B41775 - 120V AC - two 6.5” (165mm) @ 1200 watts B41579 & B41779 - 208V AC- two 6.5” (165mm) @ 1200 watts B41576 & B41776 - 240V AC - two 6.5” (165mm) @ 1200 watts B41575L &...
-
Page 7: Step # 1 - Unpacking The Cooktop
Verify and identify the package contents. The following items should be included in the carton. If any components are missing or damaged, call KENYON immediately. •... -
Page 8: Step # 2 - Checking The Electrical Supply Requirements
This product must be installed in accordance with national, state and local electric codes. The following table provides the correct voltage, amperage and frequency that must be supplied to the cooktop. Max Connected Required Power Minimum Kenyon Part # Model # Load Supply Input Wire Size B41540... - Page 9 A - 13 inches maximum depth of overhead cabinets B - 36 inches is minimum height of countertop above floor C - The minimum flat countertop surface that the cooktop will rest upon must be equal to or greater than the overall cooktop dimensions (refer to the following page for overall cooktop dimensions).
-
Page 10: Countertop Cutout Dimensions
14 1/4" 14 1/4" 23 1/4" 23 1/4" 3 1/4" 3 1/4" 21 3/4" 21 3/4" 12 3/4" 12 3/4" COUNTERTOP CUTOUT DIMENSIONS COUNTERTOP CUTOUT DIMENSIONS B41540, B41549, & B41541 B41540L, B41549L, & B41541L 12” 21” 3 1/4” 20" 10 3/4" COUNTERTOP CUTOUT DIMENSIONS COUNTERTOP CUTOUT DIMENSIONS B41575, B41579, B41576, B41775,... -
Page 11: Step # 4 - Installing The Cooktop
STEP #4 silicone to seal the Installing the Cooktop glass edge if desired The cooktop is supplied with two metal mounting brackets. These brackets are glass panel designed to hold the cooktop firmly in place. The cooktop does not have a metal frame putty strip and should be sealed to the countertop. -
Page 12: Step # 5 - Electrical Connection
(Cerama Bryte Ceramic Cooktop Name Plate Cleaner) will provide a clean, shiny coating on Label Location the cooktop surface. The next section of the manual covers cooktop use, maintenance and service information. Please keep these instructions with the KENYON cooktop for future reference. -
Page 13: Cookware
OPERATION READ SAFETY INSTRUCTIONS BEFORE OPERATING YOUR APPLIANCE The cooking surface and control areas of your Lite-Touch™ Q cooktop are identified by permanent patterns in the cooktop. The appliance is easy to maintain and easy to clean. Keeping the cooktop in top performance can be achieved by following the simple guidelines for use and cleaning below: COOKWARE Chances are that your existing cookware will work just fine with your glass ceramic cooktop. -
Page 14: Initial Start-Up
(Cerama Bryte Ceramic Cooktop Cleaner) will provide a coating on the cooktop prior to its first use. A sample is included with your Kenyon cooktop. The cooktop surface should be free of any foreign substances before use. -
Page 15: Hot Surface Indicator
HOT SURFACE INDICATOR A hot surface indicator light will illuminate when an element is energized and has been activated for enough time to produce unsafe to touch temperatures of the cooking surface. The light will remain illuminated until the surface is cool. SAFETY THERMAL CUTOUT Another safety feature of the Lite-Touch™... -
Page 16: Cleaning
Lite-Touch™ Q Maintenance The Kenyon cooktop is a sealed unit that does not require regular maintenance. Please follow our operating instructions as mentioned above. If your Lite-Touch™ Q requires service, this must be preformed by Authorized Personnel only. Please call Kenyon Customer Care at... -
Page 17: Warranty Information
Warranty Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company. - Page 18 Get Connected to Find out about special offers, events, & get the latest recipes. Scan this code with your smart phone using the Scan App...
