Use & Care Guide - Installation Manual
Kenyon International, Inc.
P.O. Box 925
8 Heritage Park Road
Clinton, CT 06413
Phone: 860-664-4906
Fax: 860-664-4907
www.kenyonappliances.com
SilKEN
Induction Cooktops
®
Portrait
240 V Models
KENYON
Custom
Landscape
Part# 143699
Created: May 25, 2010
Revised: December 30, 2010
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Portrait B80101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kenyon Portrait B80101

  • Page 1 Custom SilKEN Induction Cooktops ® Portrait Landscape Use & Care Guide - Installation Manual 240 V Models Kenyon International, Inc. P.O. Box 925 8 Heritage Park Road Clinton, CT 06413 Part# 143699 Phone: 860-664-4906 Created: May 25, 2010 Fax: 860-664-4907 Revised: December 30, 2010 www.kenyonappliances.com...
  • Page 2: Table Of Contents

    Table of Contents Section Page Safety Guidelines ........................... Product Specifications ........................Installation Instructions Step # 1 - Unpacking the Cooktop ..................Step # 2 - Checking the Electrical Supply Requirements ............Step # 3 - Countertop Preparation ..................Step # 4 - Installing the Cooktop ................... Step # 5 - Electrical Connection ....................
  • Page 3: Safety Guidelines

    User Servicing Do not repair or replace any part of the appliance. If service ever becomes necessary, this appliance should be serviced by AUTHORIZED PERSONNEL ONLY or call KENYON Customer Care at (860)664-4906. Storage in or on Appliance Flammable materials should not be stored above, under or near surface cooking units.
  • Page 4 Do not cook on broken cooktop. If cooktop should break, cleaning solutions and spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact an authorized service center or KENYON Customer Care immediately at (860) 664-4906. Clean cooktop with caution.
  • Page 5: Product Specifications

    SilKEN Induction Series Cooktop ® PRODUCT SPECIFICATIONS B80101 - 240V AC - one 5.7” (145mm) @ 1400 watts normal, 1800 watts boost one 8.25” (210mm) @ 2300 watts normal, 3200 watts boost B80105 - 240V AC - one 5.7” (145mm) @ 1400 watts normal, 1800 watts boost one 8.25”...
  • Page 6: Installation Instructions

    Verify and identify the package contents. The following items should be included in the carton. If any components are missing or damaged, call KENYON immediately. •...
  • Page 7: Step # 2 - Checking The Electrical Supply Requirements

    This product must be installed in accordance with national, state and local electric codes. The following table provides the correct voltage, amperage and frequency that must be supplied to the cooktop. Max Connected Required Power Minimum Kenyon Part # Model # Load Supply Input Wire Size B80101...
  • Page 8 A - 13 inches maximum depth of overhead cabinets B - 36 inches is minimum height of countertop above floor C - The minimum flat countertop surface that the cooktop will rest upon must be equal to or greater than the overall cooktop dimensions (refer to the following page for overall cooktop dimensions).
  • Page 9: Step # 4 - Installing The Cooktop

    100% silicone sealant. Attach the two mounting brackets supplied with the KENYON cooktop (as shown) to the inside vertical surface of the cutout. The brackets are to be mounted on opposing sides. Center the bracket in the opening, flush with the countertop and secure with long self-tapping screws that are provided.
  • Page 10: Step # 5 - Electrical Connection

    (Cerama Bryte Ceramic Cooktop Name Plate Cleaner) will provide a clean, shiny coating on Label Location the cooktop surface. The next section of the manual covers cooktop use, maintenance and service information. Please keep these instructions with the KENYON cooktop for future reference.
  • Page 11: Induction Cooking

    OPERATION READ SAFETY INSTRUCTIONS BEFORE OPERATING YOUR APPLIANCE The cooking surface areas of your SilKEN induction cooktop are identified by inset induction ® zones patterns in the cooktop. The appliance is easy to maintain and easy to clean. Keeping the cooktop in top performance can be achieved by following the simple guidelines for use and cleaning below: INDUCTION COOKING...
  • Page 12: Lock Mode

    (Cerama Bryte Ceramic Cooktop Cleaner) will provide a coating on the cooktop prior to its first use. A sample is included with your Kenyon cooktop. The induction cooktop surface should be free of any foreign substances before use.
  • Page 13: Controls Of Induction Cooktop

    CONTROLS OF INDUCTION COOKTOP To activate an induction element, first the master power must be turned on by placing and holding a finger over the circular area next to the master power graphic. An audible beep will be heard and a light next to the master power graphic will illuminate. Then the desired induction element must be turned on, by placing a finger over the circular area marked ON/OFF for that element.
  • Page 14: Safety Thermal Cutout

    All functions will no longer operate until the master power is turned on again. COOLING FAN Your Kenyon SilKEN comes equipped with a cooling fan that automatically turns on to cool off ® internal parts. The fan will automatically turn off when cooling is no longer necessary. During long usage the fan may remain on even after the cooktop has been powered down.
  • Page 15: Cleaning

    SilKEN Maintenance ® The Kenyon induction cooktop is a sealed unit that does not require regular maintenance. Please follow our operating instructions as mentioned above. If your SilKEN requires service, this must ® be preformed by Authorized Personnel only. Please call Kenyon Customer Care at 860-664-4906.
  • Page 16 SilKEN Cooktop Is Not Functioning • Combination of LED’s in horseshoe ® Properly flashing repeatedly. Clear by cycling off power in circuit which supplies cooktop. • Check household fuse or circuit breakers to see if it has been blown or tripped.
  • Page 17: Warranty Information

    Warranty Kenyon International, Inc (the “Company”) warrants its products in normal usage to be free of defects in materials and workmanship subject to the conditions and limitations below. Any part, which proves to be defective in normal usage during the warranty period will be repaired or replaced by the Company.
