4. Configuration
Using the Web Interface
To access the web interface:
Procedure
4-8
1. Open your web browser. (Internet Explorer Version 6 or above is
recommended.)
2. Type http:// and the IP address of the BitStorm 2600 into the Address field of
your browser window. For example:
3. A login window appears. Enter the default User ID (admin) and leave
Password blank. Click on OK. The web interface screen appears.
4. Click on the menu tab appropriate to what you would like to do:
— Configuration – To configure the system and interfaces
— Status – To display statistics, status, and contents of memory
— System – To display system information, download firmware, back up
configurations, and modify users
— Diagnostics – To start and stop tests
April 2005
2600-A2-GN20-50
