® Hotwire ATM Line Cards Models 8335, 8355, 8365, 8375, and 8385 Installation Instructions Document Number 8335-A2-GZ40-60 March 2005 Contents Software and Firmware License Agreement Hotwire ATM Line Cards Product Documentation Online Installation Overview Planning the Installation Cables You Need...
Page 2: Software And Firmware License Agreement
6. In no event will Paradyne be liable to Licensee for any consequential, incidental, punitive or special damages, including any lost profits or lost March 2005 8335-A2-GZ40-60...
Page 3: Hotwire Atm Line Cards
® 8335, 8355, 8365, 8375, and 8385 Asynchronous Transfer Mode ® 2.2 concurrent with POTS. Hotwire ATM Line Cards, Models 8335, 8355, 8365, 8375, and 8385, User’s Guide Hotwire Central Office Universal POTS Splitter, Models 6050 and 7020, Installation Instructions...
Page 4: Installation Overview
After the ATM Line Card is installed, there are configuration procedures that must be performed before you can begin to use it. Refer to the Line Cards, Models 8335, 8355, 8365, 8375, and 8385, User’s Guide detailed configuration procedures. Hotwire ReachDSL Modem, Model 6390 with Inline Phone Filter,...
Page 5: Cables You Need
POTS splitter for more information. For the ATM Uplink: Refer to the Card User’s Guide For more information refer to Connector Pin Assignments in the Cards, Models 8335, 8355, 8365, 8375, and 8385, User’s Installing DSL Cards HANDLING PRECAUTIONS FOR STATIC-SENSITIVE DEVICES This product is designed to protect sensitive components from damage due to electrostatic discharge (ESD) during normal operation.
Page 6: Connecting To The Atm Network
D AT THE SOURCE WARNING! THIS PWR ENTRY MODULE POWER MUST BE DISCONNECTE BEFORE REMOVING OR INSTALLING D AT THE SOURCE THIS PWR ENTRY MODULE SERIAL ALARM CLOCK SMCM Hotwire Shelf for more information. March 2005 ALARM S Major Minor 00-16709 8335-A2-GZ40-60...
Page 7: Connecting To An Mdf Or Adsl Pots Splitter
Connecting to an MDF or ADSL POTS Splitter You can connect the ATM Line Card to an MDF or other demarcation point. Do not connect the Model 8335 or 8385 to a POTS splitter. Refer to the 8620 or 8820 BLC Installation Guide for more information.
Page 8: Front Panel Leds
Front Panel LEDs The following table describes the meaning and states of the LEDs on the front panel. Type SYSTEM ATM BUS DSL PORT 8335 ALT BANK ALT BANK 9-16 13-24 8365 1-12 24-Port Models ALT BANK 8335 G.DMT SDSL ReachDSL G.Lite...
Page 9: Logging In To The Mcc Card
You can configure VC connections from the line card to the endpoint with the ATM Cross Connect screen. To access the ATM Cross Connect screen, follow this menu selection sequence: Configuration 8335-A2-GZ40-60 for information about selecting the unit from the → →...
Page 10: Asynchronous Terminal Interface Menu
Asynchronous Terminal Interface Menu The following diagram shows the menu paths to the functions available through the asynchronous terminal interface.
Page 11: Warranty, Sales, Service, And Training Information
Hotwire and ReachDSL are registered trademarks of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners. Copyright 2005 Paradyne Corporation. Printed in U.S.A. 8335-A2-GZ40-60 March 2005...
