- Page 1 Instruction Manual AVT-3155A PC to Video Scan Converter...
-
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting the Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
INTRODUCTION Thanks for purchasing this product from the AV Toolbox Division of TV One. The AVT-3155A PC to Video Scan Converter is designed to convert a variety of computer images, ranging from 640x480 to 1600x1200 pixels, to interlaced NTSC or PAL Video. The AVT-3155A provides both Composite and S-Video output signals, and is ideal for use in applications requiring the viewing of PC images on a standard television monitor. - Page 5 Getting the Best Results There are many factors affecting the quality of results when scaling video signals. Some basic precautions will ensure the best possible performance from your Scan Converter. Output display device – The quality of the output signal will depend largely upon the type and quality of display device used.
-
Page 6: Specifications
CONNECTING THE HARDWARE The first step is to connect a PC video source to the input of the AVT-3155A Scan Converter and then connect its output to a display device and lastly connect the AC to DC converter. The drawings below show the locations of the input, outputs, power switch and power connector. - Page 7 Connecting the Input Before using the AVT-3155A, make certain that the PC is producing a picture on its regular monitor. If it is, disconnect the monitor and connect an HD-15 to HD- 15 cable between the output of the PC and the input of the AVT-3155A.
-
Page 8: Operating The Unit
LED indicator will illuminate. OPERATING THE UNIT Once the AVT-3155A is connected to a PC and an appropriate display, apply power and the unit will automatically detect the resolution being output by the PC. You select the proper television standard (NTSC/PAL) and an image will appear on the display. -
Page 9: 8.0 Regulatory Compliance
8.0 REGULATORY COMPLIANCE The AVT-3155A has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supplies have been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. - Page 10 AV Toolbox USA AV Toolbox Europe 2791 Circleport Drive Continental Approach Erlanger, KY 41018 Westwood Industrial Estate Margate, Kent CT9 4JG, UK Tel 800-235-3280 Tel +44 (0)1843 873307 Tel 859-647-1077 Fax +44 (0)1843 873312 Fax 859-282-8225 sales.europe@avtoolbox.com sales@avtoobox.com www.avtoolbox.com www.avtoolbox.com AV Toolbox Latin America AV Toolbox Mercosur 6991 NW 82nd Avenue #8...
