- Page 1 Instruction Manual AVT-3320 Analog Video to UXGA Scaler...
-
Page 3: Table Of Contents
Table of Contents Introduction Specifications Checking Package Contents Connecting the Hardware Operating The Unit Troubleshooting Limited Warranty Regulatory Compliance Contact Information... -
Page 4: Introduction
INTRODUCTION Thanks for purchasing this product from the AV Toolbox Division of TV One. The AVT-3320 Analog Video to UXGA Scaler is designed to convert interlaced NTSC or PAL Video––S-Video or Composite Video format––to XGA, SXGA or UXGA resolutions which allows the viewing of standard television images on your PC monitor. - Page 5 Getting the Best Results There are many factors affecting the quality of results when scaling video signals. Some basic precautions will ensure the best possible performance from your Up Converter. Output display device – The quality of the output signal will depend largely upon the type and quality of display device used.
-
Page 6: Specifications
UL, CUL, CE, PSE, GS, RoHS Mechanical Dimensions–HxWxD 0.9”x3.9”x2.5” (24x100x64mm) Weight 0.44lbs (200g) Power Requirement External Power Supply 100~240VAC to 5VDC Adapter Accessories Included 1x Power Adapter US, UK or Euro 1x User Manual Model Number AVT-3320 AVT-3320 Analog Video to UXGA Scaler... -
Page 7: Checking Package Contents
CONNECTING THE HARDWARE The first step is to connect a Video Source to the input of the AVT-3320 Analog Video to UXGA Scaler, connect its output to a PC monitor and lastly connect the AC to DC Power Adapter. The drawings below show the locations of the input, outputs, power switch and power connector. -
Page 8: Operating The Unit
If you have connected a Composite Video signal to the AVT-3320, press the input switch on the top of the unit until the LED indicator turns Green. If you have connected an S-Video (Y/C) signal, press the input switch until the LED indicator turns Orange. -
Page 9: Limited Warranty
After trying the above suggestions sh ould the problem still persist, contact your dealer for additional suggestions before contacting TV One. Should the dealer’s technical personnel be unable to assist you, contact TV One via our support website: http://tvone.crmdesk.com. Create a technical support request on the site and our support team will respond within a short period of time. -
Page 10: 8.0 Regulatory Compliance
8.0 REGULATORY COMPLIANCE The AVT-3320 has been tested for compliance with appropriate FCC and CE rules and regulations. The Power Adaptor/Supplies have been tested for compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. These Products and Power Adapters are RoHS Compliant.
