IMB203 LGA775 ATX Motherboard User's Manual
2.3

Jumper Settings

Proper jumper settings configure the IMB203 to meet your application
purpose.
2.3.1 COM1 Mode Select Jumpers for RS-232/422/485
(JP1, JP3, JP4)
These jumpers select the COM1 port's communication mode to
operate RS-232 or RS-422/485.
Description Function
COM1 RS-232
(Default)
RS-422
RS-485
Jumpers and Connectors
Jumper Setting
JP1 JP3
JP1 JP3
JP1 JP3
JP4
JP4
JP4
7
