IMB203 LGA775 ATX Motherboard User's Manual
The IMB203 ATX industrial Motherboard supports LGA775 socket for
®
™
Intel Core 2 Quad/Core
technology and FSB 800/1066/1333 MT/s. The board integrates
®
Intel Q45 and ICH10/R/DO chipsets (co-layout) that deliver
outstanding system performance through high-bandwidth interfaces,
multiple I/O functions for interactive applications and various
embedded computing solutions. There are four 240-pin DDR3 DIMM
sockets for dual channel DDR3 800/1066, maximum memory capacity
up to 16GB. The board also features Gigabit Ethernet, six serial ATA-
II ports at maximum transfer rate up to 3Gbs, and SATARAID 0/1/5/10
by ICH10-DO. Twelve USB 2.0 high speed compliant ports and built-
®
in Intel HD Audio Digital Header can achieve the best stability and
reliability for industrial applications.
Introduction
INTRODUCTION
™
2 Duo processors with 45/65nm
CHAPTER 1
1
