LED Illumination
An LED is located on the front of the unit. When
the trigger is pulled, notice a bright LED
illuminates the area including and around the
area being measured for convenience unless
switched off.
Magnetic Base
A removable magnetic base is attached to the
bottom of unit, below the handle. The magnetic
base allows the unit to be attached to any ferrous
metal surface. The magnet's surface has been
engineered not to scratch finishes by recessing
the actual magnets. However, metal shavings
and debris can be inadvertently picked up by the
magnetic, and if not removed and cleaned, can
damage the finish of a surface. The magnetic
base is attached to the unit using a Phillips head
screw and can easily be removed using a
screwdriver.
Reminders
Not recommended for use when measuring
shiny or polished metal surfaces (stainless
steel, aluminum, etc.). See "Emissivity" for
measuring these surfaces.
The unit cannot measure through
transparent surfaces such as glass or
plastic. It will measure the surface
temperature of these materials instead.
Steam, dust, smoke, or other particles can
prevent accurate measurement by
obstructing the unit's optics.
The thermometer can be pointed using the
sighting guides on top of the unit whenever
it is difficult to see the laser sighting
system.
4
Maintenance
Lens Cleaning: Blow off loose particles using
clean compressed air. Gently brush remaining
debris away with a soft brush. Carefully wipe the
surface with a moist cotton swab. The swab may
be moistened with water.
Note:
Do not use solvents to clean the plastic
lens.
Cleaning the housing: Use soap and water on a
damp sponge or soft cloth.
Note:
Do not submerge the unit in water.
CE Certification
This instrument conforms to the following
standards:
EN61326-1 EMC
EN61010-1
EN60825-1 Safety
Tests were conducted using a frequency range of
80–1000 MHz with the instrument in three
orientations.
Note:
Between 165 MHz and 880 MHz at
3V/m, the instrument may not meet its stated
accuracy.
