INSTRUMENTS, FEATURES AND CONTROLS

Side Covers

Your motorcycle is equipped with two removable side covers. Remove the left side cover to access the battery.
Remove the right side cover to access the fuses and the rear brake fluid reservoir.
To remove either side cover, pull the lower corners of the side cover out slightly until lower tab is disengaged. Pull
evenly on upper left and right side to disengage the two top tabs. Remove cover from the motorcycle. Be sure
rubber grommets are in place before reversing the above procedure to install the side covers.
Sidestand
The sidestand is located on the left side of the motorcycle.
WARNING
Correctly retract the sidestand before operating the motorcycle. An improperly retracted sidestand
could come into contact with the ground and cause loss of control.
To extend the sidestand, swing it out from the end until it is fully extended. Lean the motorcycle toward the
sidestand until the sidestand firmly supports the motorcycle.
To retract the sidestand, lean the motorcycle away from the sidestand until the motorcycle is fully upright. Swing
the sidestand back into its fully retracted position.
46
