- Page 1 HAMMER STRENGTH BWCDLR - BODY WT CHIN/DIP/LEG RAISE Customer Support Services PARTS MANUAL 1Page 1 of 7...
- Page 2 BWCDLR - BODY WT CHIN/DIP/LEG RAISE Notes: 2Page 2 of 7...
-
Page 3: Table Of Contents
BWCDLR - BODY WT CHIN/DIP/LEG RAISE Contents PAGE COMPONENT ASSEMBLY...4 TOP FRAME ASSEMBLY...5 LEFT SIDE FRAME...6 BOTTOM FRAME ASSEMBLY...7 3Page 3 of 7... - Page 4 1 BWCDLR-CBX-0Bottom Frame Assembly 1 BWCD-CSFL-0 Chin SF Left Assembly 1 BWCD-CSFR-0 Chin SF Right Assembly 1 BWCDLR-CSFL-0 LR Side Frame Right Assembly 1 BWCDLR-CSFR-0 L R Side Frame Left Assembly 1 BWCDLR-CTX-0 Top Frame Assembly 8 HHB.5X3 4 HHB.375X1.5 2 H-HPLUG 8 HHB.5X4.5...
-
Page 5: Top Frame Assembly
BWCDLR - BODY WT CHIN/DIP/LEG RAISE TOP FRAME ASSEMBLY ITEM NO. QTY.PART NO. DESCRIPTION 1 BWCDLR-TX-0 Top Frame 4 H-PEND3 1 1/2 X 3 End Cap 4 H-HPLUG Hole Plug 2 H-NAMEPLATE Name Plate 2 SERIAL NUMBER Serial Number 1 PATENT... -
Page 6: Left Side Frame
BWCDLR - BODY WT CHIN/DIP/LEG RAISE LEFT SIDE FRAME RIGHT SIDE FRAME MIRROR IMAGE ITEM NO. Q TY.PART NO. DESCRIPTION 3 H-PLATE-G1 Small Plate Guard 4 H-PEND2 1 1/2 X 2 Endcap 5 H-HPLUG Hole Plug 1 BWCDLR-SFR-0 HandGrip 6Page 6 of 7... -
Page 7: Bottom Frame Assembly
BWCDLR - BODY WT CHIN/DIP/LEG RAISE BOTTOM FRAME ASSEMBLY ITEM NO. QTY. PART NO. DESCRIPTION BWCDLR-BX-0 Bottom Frame H-NONSKID1 1 1/4 X 9 Nonskid H-HPLUG Hole Plug 7Page 7 of 7...
