Yaesu FT1DR Instruction Manual

144/430mhz digtial/analog transceiver c4fm fdma
Hide thumbs Also See for FT1DR:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Technical Supplement, Instruction Manual
144/430MHz
DIGITAL/ANALOG TRANSCEIVER
C4FM FDMA
FT1DR
FT1DE
Instruction Manual
(WIRES-X Edition)
Thank you for purchasing our product.
This instruction manual explains information related to the "WIRES-X Function".
For information on basic operation of the transceiver, refer to the operating
manual enclosed in the product package.
Company names and products in this manual are trademarks or registered
trademarks of the respective company.

Advertisement

Table of Contents
loading

Related Manuals for Yaesu FT1DR

Summary of Contents for Yaesu FT1DR

  • Page 1 144/430MHz DIGITAL/ANALOG TRANSCEIVER C4FM FDMA FT1DR FT1DE Instruction Manual (WIRES-X Edition) Thank you for purchasing our product. This instruction manual explains information related to the “WIRES-X Function”. For information on basic operation of the transceiver, refer to the operating manual enclosed in the product package.

  • Page 2: Table Of Contents

    Using the WIRES-X Contents Viewing imported data later ..........28 Contents ..................2 What is WIRES-X? ..............3 Deleting imported data..........29 Terminology ..............4 Listening to audio messages..........30 Connecting to a Faraway Station Using WIRES-X ....7 Listening to the information in the local node ....30 Finding a local node .............7 Listening to the WIRES-X server (INT NEWS) Connecting in digital mode ...........8...

  • Page 3: What Is Wires-X

    What is WIRES-X? WIRES (Wide-coverage Internet Repeater Enhancement System) is an Internet communication system which expands the range of amateur radio communication. By relaying radio signals via the Internet, stations can be connected where radio waves cannot reach each other. WIRES uses local nodes (stations connected to the Internet via PCs) as access points which repeat communications of conventional amateur radio stations.

  • Page 4: Terminology

    What is WIRES-X? Terminology ■ Node Radio repeater connected to the Internet via a PC, which repeats communications of conventional amateur radio stations as an access point ● Local node Node within the radio communication range of a conventional amateur radio station ●...
  • Page 5 If you know the ID of the node you want to connect with, you can transmit the DTMF code from the FT1DR/DE, and directly specify the node to connect to by searching by characters (only for digital nodes).
  • Page 6 • By presetting to a shared channel frequency with your friends nodes, you can quickly connect the FT1DR/DE to a local node even while you are traveling in other areas You can use 2 transceivers as nodes, one for the preset search channel (receive only...

  • Page 7: Connecting To A Faraway Station Using Wires-X

    To communicate using WIRES-X, a WIRES-X node station (local node) must be established within radio contact range of the user transceiver. WIRES-X nodes are stations users voluntarily registered with Yaesu. Their information such as locations and operation styles are listed on our website: https://www.yaesu.com/jp/en/wires-x/index.php...

  • Page 8: Connecting In Digital Mode

    Connecting to a Faraway Station Using WIRES-X Connecting in digital mode Caution Before using WIRES-X, press % to set the communication mode of band A (shown on the top part of the screen) to any mode other than [FM]. For details, refer to “Selecting Communication Mode” in the basic operating manual.

  • Page 9: Connecting To A Node Or Room On The Internet

    Connecting to a Faraway Station Using WIRES-X Connected to the local node, successfully connected to Internet nodes or rooms (nodes or rooms are the same as ones previously used) Connected to the local node, successfully connected to Internet nodes or rooms (nodes or rooms are different from ones previously used) is displayed, rotate the O.
  • Page 10 (the number of nodes connecting to each room) appears on the right side. Rotate O to select the connection destination Press H The FT1DR/DE will initiate connection and [Waiting] will flash. When connection is successfully established, [Connected] will appear, followed by the menu list of the connection destination.
  • Page 11 • To edit the name, rotate the , select [Cancel], press , then make changes on the input screen. • If the name you entered is found, the FT1DR/DE will initiate the connection immediately. • The screen will display the room list search results, followed by the node list search results.
  • Page 12 Connecting to a Faraway Station Using WIRES-X Rotate O to select the connection destination Press H The FT1DR/DE will initiate connection and [Waiting] will flash. Instead of H, you can press p to establish connection while continuing to transmit from your transceiver...

  • Page 13: Communicating With Others

    Connecting to a Faraway Station Using WIRES-X Communicating with others When the connection destination is displayed, press The FT1DR/DE will switch to transmit mode. Speak into [MIC] Place the microphone about 5 cm away from your mouth when you speak.
  • Page 14 Connecting to a Faraway Station Using WIRES-X Rotate O to select [PRESET] • Rotating O switches between [MANUAL] and [PRESET]. Tips • The default setting is [MANUAL]. Press H The frequency will appear. Rotate O to select the frequency • Rotating O changes the frequency by the increments Tips specified in setting mode.

  • Page 15: Connecting To A Registered Node Or Room

    Up to a total of 20 nodes and rooms can be registered in each category. ● Registering category name Press and hold M for 1 second or more The FT1DR/DE will enter setting mode. Rotate O to select [7 WIRES-X] Press H The menu list will appear.
  • Page 16 Connecting to a Faraway Station Using WIRES-X Use the keypad to enter the category name. The characters you have just entered will appear at the center of the screen. Tips • Refer to the following table to enter the category name using up to 16 alphanumeric characters.
  • Page 17 Connecting to a Faraway Station Using WIRES-X Rotate O to select [BACK] Press H The screen will return to the menu options. ● Connecting to the registered node or room Press and hold H for 1 second or more The menu list of the local node will appear. Rotate O to select one of [C1] to [C5] Press H [Waiting] will appear, followed by a list of nodes and...

  • Page 18: Releasing The Wires-X Connection

    The connection destination screen will not appear. You can store DTMF codes consisting of up to 16 digits for 10 channels on the FT1DR/DE. If you register the codes of frequently-used connection destinations in advance, you can easily transmit a code by pressing its abbreviated number while pressing p.

  • Page 19: Disconnecting From A Node Or Room

    Do not continuously transmit over an extended period of time to reduce the risk of overheating, malfunction, or injury. Release p The FT1DR/DE will return to receive mode. Disconnecting from a node or room While pressing p, press the #99999 (DTMF disconnection command) key.

  • Page 20: Returning To The Initial Screen

    Connecting to a Faraway Station Using WIRES-X [Dual band screen] → ← [Single band screen] → ← [When viewing text data of the local node] Dual band → ← Mono band → ← Returning to the initial screen While on the WIRES-X screen, press and hold A for 1 second or more to return to WIRES-X startup screen (initial screen).

  • Page 21: Using The News Function Of Wires-X

    Internet, from the FT1DR/DE transceiver. Caution To read messages, insert a microSD card into the FT1DR/DE in advance. For details, refer to “Using a microSD memory card” in the basic operating manual. Viewing text data in a local node Press and hold H for 1 second or more The menu list of the local node will appear.
  • Page 22 Connecting to a Faraway Station Using WIRES-X Rotate O to select [MESSAGE] Press H [Waiting] will be displayed. If data reception is successful, a list of available data messages will appear. The list will show data in reverse chronological order. Rotate O to select a message Press H [Waiting] will be displayed.

  • Page 23: Viewing Text Data On The Wires-X Server (Int News)

    Not available on the last list. Viewing text data on the WIRES-X server (INT NEWS) You can read text information provided by Yaesu on the WIRES-X server from the FT1DR/DE transceiver. Press and hold H for 1 second or more The menu list of the local node will appear.

  • Page 24: Viewing Text Data In A Node Or Room On The Internet

    Connecting to a Faraway Station Using WIRES-X Rotate O to select a message Press H [Waiting] will be displayed. If data reception is successful, will be displayed. Data will be imported; the content of the message will appear. Rotate O to select [BACK] Press H The data list will appear again.
  • Page 25 On the content display screen, press M to display the sender’s location information when the data was imported. Caution When the category list or data list is displayed, if you press p, the FT1DR/DE transceiver will be ready to transmit audio to the currently connected node or room on the Internet.

  • Page 26: Importing Images

    Internet onto the FT1DR/DE transceiver. Cautions z To import images, insert a microSD card into the FT1DR/DE in advance. For details, refer to “Using a microSD memory card” in the basic operating manual. z Imported images cannot be viewed on the FT1DR/DE. To view images after importing, remove the microSD card from the FT1DR/DE, and then view the data on the card using a PC, etc.

  • Page 27: Importing Images From The Wires-X Server

    Connecting to a Faraway Station Using WIRES-X Importing images from the WIRES-X server You can import images provided by Yaesu on the WIRES-X server onto the FT1DR/DE transceiver. Follow steps 1 to 4 in “Viewing text data on the WIRES-X server” to display the data...

  • Page 28: Viewing Imported Data Later

    Follow steps 4 to 7 “Importing data of a local node” to import data Caution When the category list or data list is displayed, if you press p, the FT1DR/DE will be ready to transmit audio to the currently connected node or room on the Internet. Viewing imported data later You can also view the imported data later.

  • Page 29: Deleting Imported Data

    Connecting to a Faraway Station Using WIRES-X Deleting imported data ● Deleting a file Follow steps 1 to 7 “Viewing imported data later” to display the content of the message or image data information Rotate O to select [DELETE] Press H Rotate O to select [OK?] Press H The file will be deleted, and then the data list will appear...

  • Page 30: Listening To Audio Messages

    (LOCAL NEWS) room. Caution You can play and listen to audio files on the FT1DR/DE transceiver but you cannot save audio files to the FT1DR/DE. Listening to the information in the local node ● Listening to emergency information Follow steps 1 to 4 in “Viewing text data in a local node”...

  • Page 31: Listening To The Wires-X Server (Int News) Information

    Listening to the WIRES-X server (INT NEWS) information You can play and listen to the audio data provided by Yaesu on the WIRES-X server. ● Listening to emergency information Follow steps 1 to 3 in “Viewing text data on the WIRES-X server” to display the...

  • Page 32: Listening To Information On A Node Or Room On The Internet

    Connecting to a Faraway Station Using WIRES-X ● Listening to a routine message Follow steps 1 to 4 in “Viewing text data on the WIRES-X server” to display the data type select screen Rotate O to select [VOICE] Press H The data list will appear.

  • Page 33: Transmitting Messages And Images

    You can transmit data such as messages (text data) and images saved on the microSD card inserted into the FT1DR/DE, to a local node, or a node or room on the Internet. You can also create a new message and transmit it.
  • Page 34 Connecting to a Faraway Station Using WIRES-X Rotate O to select [MESSAGE] Press H The data list will appear. Rotate O to select [NEW] Press H The character input screen will appear. Use the keypad to enter a message The characters you have just entered will appear on the top part of the screen.

  • Page 35: Transmitting Data To A Node Or Room On The Internet

    Connecting to a Faraway Station Using WIRES-X On the character input screen, rotate O to select the fixed phrase icon ( ), and then press H to select one of the 19 fixed phrases. Good job wait for you Good day Pick me up Good evening Thank you...

  • Page 36: Transmitting An Audio Message

    Connecting to a Faraway Station Using WIRES-X Rotate O to select [UPLOAD] Press H The data type select screen will appear. Follow steps 4 to 11 in “Creating and transmitting a message” under “Transmitting data to a local node” to create and transmit a message ●...

  • Page 37: Transmitting Data To A Node Or Room On The Internet

    Using WIRES-X and the GM Function Simultaneously Continue to hold p until is displayed and countdown begins. Continue to hold p and speak into the [MIC] The maximum recording time is 1 minute. Transmission of the message will begin. The screen will display and the countdown will be flashing.
  • Page 38 Using the News Function of WIRES-X ● Transmitting a routine message Display the menu list of the node or room on the Internet Press H The upload/download select screen will appear. Follow steps 3 to 6 in “Transmitting a routine message” under “Transmitting data to a local node”...

  • Page 39: Using Wires-X And The Gm Function Simultaneously

    You can use WIRES-X even when using the GM (Group Monitor) function on the FT1DR/DE transceiver. By forming a group including local nodes and organizing the GM, group members can also utilize WIRES-X to communicate with a node or room on the Internet, including exchanging data.

  • Page 40: Using The News Function Of Wires-X In Gm Operation

    Using WIRES-X and the GM Function Simultaneously Press D The screen will return to the frequency display screen. Use the SYNC function after registering the local node as a group member, so that other members can check the local node from their stations. For details, refer to the separate GM instruction manual. Using the News Function of WIRES-X in GM Operation Rotate O, select a node on the group list that lies within communication range...

  • Page 41: Wires-X Setting Mode Menus

    Setting the language displayed on the screen You can select the language displayed on the screen from [JAPANESE] and [ENGLISH]. Press and hold M for 1 second or more The FT1DR/DE will enter setting mode. Rotate O to select [7 WIRES-X] Press H The menu list will appear.

  • Page 42: Setting The Transmission Frequencies For Repeaters/Wires-X

    You can select how to set the transmission frequency used when connecting to a local node. Press and hold M for 1 second or more The FT1DR/DE will enter setting mode. Rotate O to select [7 WIRES-X] Press H The menu list will appear.

  • Page 43: Setting The Item Order On The Node & Room Lists

    Setting the item order on the node & room lists You can select the criteria to sort the list of connection destinations on the Internet. Press and hold M for 1 second or more The FT1DR/DE will enter setting mode. Rotate O to select [7 WIRES-X] Press H The menu list will appear.

  • Page 44: Deleting The Registered Nodes And Rooms

    Deleting the registered nodes and rooms You can delete nodes and rooms registered in the 5 categories. Press and hold M for 1 second or more The FT1DR/DE will enter setting mode. Rotate O to select [7 WIRES-X] Press H The menu list will appear.

  • Page 45: Error Message Guide

    Error Message Guide Error messages and explanations. Displayed when trying to receive data from a local node or a connection node, but no data was available. The error message will be displayed for 2 seconds, and then the previous screen will reappear. Displayed in one of the following scenarios: The error message will be displayed for 2 seconds.
  • Page 46 All rights reserved. No portion of this manual may be reproduced without the permission of YAESU MUSEN CO., LTD. ©2014 YAESU MUSEN CO., LTD. 1410-B0...
