    IS-IP200-DN User Manual Ver 1.0 ©Sentry360 2014...

  • Page 2: Table Of Contents

    Table of Contents Overview ..........................3 Features ........................3 Package Contents......................4 Dimensions ........................4 Connectors ........................5 Camera Cabling ......................... 6 Connect Power ......................6 Connect Ethernet Cable ....................6 Lens Mounting ......................6 Connect Alarm I/O ....................... 7 System Requirements ......................

  • Page 3: Overview

    The IS-IP200-DN camera is a Quad-streaming, H.264 & MJPEG encoding, 2.0 Megapixel resolution, IP-addressable network camera. It is designed to deliver full-motion, high-definition, progressive scan digital video across local area networks. The IS-IP200-DN features a design with no moving parts, a 1/2.7” CMOS sensor, Power over Ethernet, and Audio-In/Audio-Out. The IS-IP200-DN is a high-level, cost effective megapixel network camera.

  • Page 4: Package Contents

    Package Contents Please check the package contains the following items listed below. Back focus adjuster Camera Quick Guide Dimensions The IS-IP200-DN dimensions are shown below.

  • Page 5: Connectors

    Connectors The diagram below shows the IS-IP200-DN reset button and various connectors. Definition for each will be given as follows. DC 12V / PoE Connector Definition LINE OUT & LINE IN / Two-way audio transmission MIC IN Power LED Power connection indication (green light)

  • Page 6: Camera Cabling

    100 meters. Connect one end of the Ethernet cable to the RJ-45 connector of the IS-IP200-DN, and the other end of the cable to the network switch or PC. The RJ-45 port networks without routing to the outside plant.

  • Page 7: Connect Alarm I/O

    PIN 1: Output+ PIN 2: Output- PIN 3: Input+ PIN 4: Input- System Requirements To access the IS-IP200-DN via web browser, please ensure your PC has a good network connection, and meets system requirements as described below. Items System Requirement ®...

  • Page 8: Access Camera

    Access Camera Step 1. Power your camera using the correct power source (PoE switch, PoE injector, or 12V adapter). Step 2. Download, install, and run sentryView™, Sentry360’s camera configuration tool, here: http://sentry360.com/product/sentryview/ Step 3. Click the Scan button in sentryView™ to scan your network for connected cameras.
  • Page 9 Step 7. Your cameras are now configured. If you are using sentryCore™ as your Video Management System, please download the latest version here: http://sentry360.com/product/sentrycore/ Step 8. Right click on a camera and select Browse. The prompt for entering the default username and password will appear for logging in to the IS-IP200-DN.
  • Page 10 NOTE: ID and password are case sensitive. Installing DC Viewer Software Online For the initial access to the IS-IP200-DN, a client program, DC Viewer, will be automatically installed to the PC when connecting to the camera. If the web browser doesn’t allow DC Viewer installation, please check the Internet security...
  • Page 11 Image and Focus Adjustment The image displays on the Home page when successfully accessing to the IS-IP200-DN. Adjust zoom and focus as necessary to produce a clear image. Note: Please refer to IS-IP200-DN M for more button function detail.

  • Page 12: Configure Video Streams

    Configure Video Streams Users can setup Video Resolution on the Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming > Video Format. Click on <Save> to confirm the setting.

  • Page 13: Configuration Files Export / Import

    Click on <Save> and specify a desired location for saving the configuration file. Upload To copy an existing configuration file to the IS-IP200-DN, please first click on <Browse> to select the configuration file, and then click on the <Upload> button for uploading.

  • Page 14: Appendix A: Delete The Existing Dc Viewer

    Appendix A: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing the IS-IP200-DN. Deleting the DC Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>.

  • Page 15: Appendix B: Setup Internet Security

    Step 4. Click on <OK> to accept the settings. A prompt window will appear for confirming the setting changes, click <Yes(Y)> to close the Security Setting window. Step 5. Click on <OK> to close the Internet Options screen. Step 6. Close the browser window, and restart a new one to access the IS-IP200-DN.

  • Page 16: Appendix C: Back Focus Adjustment

    Appendix C: Back Focus Adjustment When to adjust back focus Back Focus refers to the distance from the rear lens element to the camera focal plane. In most cases, it is required to adjust back focus only when the camera’s lens cannot hold focus throughout its zoom range.
