Sentry360 IS-DM830 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IS-DM830

User Manual

Ver 1.0
©Sentry360 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS-DM830 and is the answer not in the manual?

Questions and answers

Related Manuals for Sentry360 IS-DM830

Summary of Contents for Sentry360 IS-DM830

  • Page 1: User Manual

    IS-DM830 User Manual Ver 1.0 ©Sentry360 2016...

  • Page 2: Table Of Contents

    Table of Contents Overview ............................3 Features ............................3 Package Contents .......................... 4 Dimensions ............................ 5 Connectors ............................ 6 Camera Cabling ...........................7 Connect Power ..........................7 Connect Ethernet Cable ........................ 7 System Requirements .........................8 Access Camera ..........................9 Configure Video Streams ......................13 Configuration Files Export / Import ...................

  • Page 3: Overview

    It is designed to deliver full-motion, high-definition, progressive scan digital video across local area networks. The IS-DM830 features a design with a 1/1.7” CMOS sensor, Power over Ethernet, 6 IR LED, heater, and Audio-In and Audio-Out. The IS-D830is a cost-effective, high- level, megapixel network camera.

  • Page 4: Package Contents

    Package Contents Please check the package contains the following items listed below. IS-DM830 3-Pin RS-485 Terminal Block 2-Pin Power Terminal Block Self-Tapping Screws (x2) Plastic Screw Anchors (x2) Quick Guide...

  • Page 5: Dimensions

    NOTE: The type of the supplied self-tapping screws is mainly for softer substrate/material installation such as wood. For other installation environment such as cement wall, it is required to pre-drill and use plastic anchors before fastening the supplied self-tapping screw on the wall. Dimensions The IS-DM830 dimensions are shown below.

  • Page 6: Connectors

    Connectors The diagram below shows the IS-DM830 reset button and various connectors. Definition for each connector will be given as follows.

  • Page 7: Camera Cabling

    100 meters. Connect one end of the Ethernet cable to the RJ-45 connector of the IS-DM830, and the other end of the cable to the network switch or PC. NOTE: In some cases, you may need use an Ethernet crossover cable when connecting the IS- DM830 directly to the PC.

  • Page 8: System Requirements

    System Requirements To access the IS-DM830 via web browser, please ensure your PC has a good network connection, and meets system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or ® Personal Computer...

  • Page 9: Access Camera

    Step 1. Power your camera using the correct power source (PoE switch, PoE injector, or 12V adapter). Step 2. Download, install, and run sentryView™, Sentry360’s camera configuration tool, here: http://sentry360.com/product/sentryview/ Step 3. Click the Scan button in sentryView™ to scan your network for connected cameras.
  • Page 10 Step 7. Your cameras are now configured. If you are using sentryCore™ as your Video Management System, please download the latest version here: http://sentry360.com/product/sentrycore/ Step 8. Right click on a camera and select Browse. The prompt for entering the default username and password will appear for logging in to the IS-DM830.
  • Page 11 NOTE: ID and password are case sensitive. Installing DC Viewer Software Online For the initial access to the IS-DM830, a client program, DC Viewer, will be automatically installed to the PC when connecting to the camera. If the web browser doesn’t allow DC Viewer installation, please check the Internet security settings or...
  • Page 12 Image and Focus Adjustment The image displays on the Home page when successfully accessing to the IS-DM830. Adjust zoom and focus as necessary to produce a clear image. Note: Please refer to IS-DM830 M for more button function detail.

  • Page 13: Configure Video Streams

    Configure Video Streams Users can setup Video Resolution on the Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming > Video Format. Click on <Save> to confirm the setting.

  • Page 14: Configuration Files Export / Import

    <Save> and specify a desired location for saving the configuration file. Upload To copy an existing configuration file to the IS-DM830, please first click on <Browse> to select the configuration file, and then click on the <Upload> button for uploading.

  • Page 15: Appendix A: Delete The Existing Dc Viewer

    Appendix A: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing the IS-DM830. Deleting the DC Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>.

  • Page 16: Appendix B: Setup Internet Security

    Step 3. Click on the <Security> tab, and select <Internet> zone. Step 4. Down the page, click on the <Default Level> button and click on <OK> to confirm the setting. Close the browser window, and restart a new one later to access the IS-DM830. ActiveX Controls and Plug-ins Settings Step 1.
