Page 1: User Manual
IS-DM520, HB User Manual Ver 1.0 ©Sentry360 2014... -
Page 2: Table Of Contents
Table of Contents Overview ..........................3 Features ........................3 Package Contents......................4 Dimensions ........................5 Connectors ........................6 Camera Cabling ......................... 7 Connect Power ......................7 Connect Ethernet Cable ....................7 Connect Alarm I/O ....................... 7 System Requirements ...................... 8 Access Camera ......................... -
Page 3: Overview
IP-addressable, network camera. It is designed to deliver full-motion, high-definition, progressive scan digital video across local area networks. The IS-DM520 features a design with a 1/2.5” CMOS sensor, Power over Ethernet, 24 IR LED, heater/blower (HB model only), and Audio-In and Audio-Out. -
Page 4: Package Contents
Package Contents Please check the package contains the following items listed below. Camera DC Jack Cable & Power Terminal Block Rubber Washers (×6) Security Torx Self Tapping Screws Plastic Screw Anchors (×4) (×4) Quick Guide NOTE: The type of the supplied self-tapping screws is mainly for softer substrate/material installation such as wood. -
Page 5: Dimensions
Dimensions The IS-DM520 dimensions are shown below. Top View Side View... -
Page 6: Connectors
Connectors The diagram below shows the IS-DM520 reset button and various connectors. Definition for each connector will be given as follows. Connector Definition Remarks Reset Button Restore to factory default Analog Video Output GND (Input－) Input＋ Alarm I/O Alarm connection Output－... -
Page 7: Camera Cabling
Use of Category 5 Ethernet cable is recommended for network connection; to have best transmission quality, cable length shall not exceed 100 meters. Connect one end of the Ethernet cable to the RJ-45 connector of the IS-DM520, and the other end of the cable to the network switch or PC. -
Page 8: System Requirements
System Requirements To access the IS-DM520 via web browser, please ensure your PC has a good network connection, and meets system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or ® Personal Computer... -
Page 9: Access Camera
Access Camera Step 1. Power your camera using the correct power source (PoE switch, PoE injector, or 12V adapter). Step 2. Download, install, and run sentryView™, Sentry360’s camera configuration tool, here: http://sentry360.com/product/sentryview/ Step 3. Click the Scan button in sentryView™ to scan your network for connected cameras. - Page 10 Step 7. Your cameras are now configured. If you are using sentryCore™ as your Video Management System, please download the latest version here: http://sentry360.com/product/sentrycore/ Step 8. Right click on a camera and select Browse. The prompt for entering the default username and password will appear for logging in to the IS-DM520.
- Page 11 <Finish> to exit the installation process. Step 3. Click on <Finish> to close the DC Viewer installation page. Once the DC Viewer is successfully installed, the IS-DM520 Home page will be able to correctly display as the figure below.
- Page 12 Image and Focus Adjustment The image displays on the Home page when successfully accessing to the IS-DM520. Adjust zoom and focus as necessary to produce a clear image. Note: Please refer to IS-DM520 M for more button function detail.
-
Page 13: Configure Video Streams
Configure Video Streams Users can setup Video Resolution on the Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming > Video Format. Click on <Save> to confirm the setting. -
Page 14: Configuration Files Export / Import
Click on <Save> and specify a desired location for saving the configuration file. Upload To copy an existing configuration file to the IS-DM520, please first click on <Browse> to select the configuration file, and then click on the <Upload> button for uploading. -
Page 15: Appendix A: Delete The Existing Dc Viewer
Appendix A: Delete the Existing DC Viewer For users who have installed the DC Viewer in the PC previously, please first remove the existing DC Viewer from the PC before accessing the IS-DM520. Deleting the DC Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. -
Page 16: Appendix B: Setup Internet Security
Step 4. Click on <OK> to accept the settings. A prompt window will appear for confirming the setting changes, click <Yes(Y)> to close the Security Setting window. Step 5. Click on <OK> to close the Internet Options screen. Step 6. Close the browser window, and restart a new one to access the IS-DM520.
