Advantech PCE-5125 Startup Manual

PCE-5125 LGA1156 Intel
Xeon PICMG 1.3 Single Host Board with
®
(ECC) DDR3 / Dual GbE LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 PCE-5125 PICMG 1.3 Single Host Board
2. 1 PCE-5125 startup manual
3. 1 CD with utility
4. 1 user note for full-sized CPU card
5. 2 Serial ATA HDD data cables
6. 2 Serial ATA HDD power cables P/N: 1703150102
7. 1 COM + printer ports cable kit
8. 1 4-port USB cable kit
9. Keyboard and mouse Y cable
10. 1 jumper package
11. 1 warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of PCE-5125, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/suppot/
This manual is for the PCE-5125 Series Rev. A1.
Part No. 2002512510
Printed in China
Core
®
P/N: 2002512510
P/N: 2062512500
P/N: 2002721020
P/N: 1700003194
P/N: 1701260305
P/N: 1700008461
P/N: 1700060202
P/N: 9689000068
P/N: 2190000902
1st Edition,
November 2010
i7/i5/i3/ Pentium
TM
Specifications
General
• LGA1156 Intel Core™ i7/i5/i3/Pentium
®
• BIOS: AMI 64 Mb SPI BIOS
• Chipset: Intel
Q57 (QG2 SKU) and 3450 (WG2 SKU)
®
Chipset
• System memory:
– WG2 SKU: Up to 8 GB in two 240-pin DIMM sockets.
Supports dual-channel DDR3 800/1066/1333 MHz
SDRAM WITH or WITHOUT ECC function
– QG2 SKUs: Up to 8 GB in two 240-pin DIMM sockets.
Supports dual-channel DDR3 800/1066/1333 MHz
SDRAM WITHOUT ECC function
• SATA interface: Supports up to six independent SATA2
hard drives (up to 300 MB/s) with software RAID 0, 1, 5,
10 functions
Note:
PCE-5125 does NOT support IDE port.
• FDD interface: One FDD port
• Serial ports: Two RS 232 with pin Headers
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode
• Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse connector and one external
6-pin header
• Watchdog timer: 255 level timer intervals
• USB (2.0): Nine ports on the CPU card, four ports on the
backplane
• GPIO: One programmable 8-bit GPIO pin-header

VGA Interface

• Chipset: Intel HD Graphics (Only the Core™ i5 6XX,
®
Core™ i3 and Pentium
®
Graphics embedded) embedded) )
• 1 GB maximum shared memory with 2 GB and above
system memory installed

Ethernet Interface

• Chipset supports:
- LAN 1: Intel
82578DM for all SKUs
®
- LAN 2: Intel 82583V for QG2 SKU; Intel
®
WG2 SKU
• Connection: On-board RJ-45 connector x 2
PCE-5125 Startup Manual 1
®
/Xeon
® ®
processors have Intel HD
®
82574L for
®
/
