Advantech PCE-7210 User Manual

Dual socket 604 intel xeon/lv xeon processor card with pci express/ipmi/ vga/dual gigabit lan/fsb 800mhz
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PCE-7210
Dual Socket 604 Intel® Xeon® / LV Xeon®
Processor Card with PCI Express / IPMI /
VGA/ Dual Gigabit LAN / FSB 800MHz

User Manual

Advertisement

Table of Contents
loading

Related Manuals for Advantech PCE-7210

Summary of Contents for Advantech PCE-7210

  • Page 1: User Manual

    PCE-7210 Dual Socket 604 Intel® Xeon® / LV Xeon® Processor Card with PCI Express / IPMI / VGA/ Dual Gigabit LAN / FSB 800MHz User Manual...

  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted, 2006, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improve- ments to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 Advantech equipment is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known. Your satisfaction is our primary concern. Here is a guide to Advantech’s customer services.

  • Page 4: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 5 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCE-7210, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 6: Initial Inspection

    It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCE-7210, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.
  • Page 7 Verified CPU List Table 1.1: Verified CPU List Core Mfg. Pack- CPU Freq. Spec. Step- Thermal Vcore Tech cache cache age Type ping XEON 3.6 G SL7ZC 110W 1.4V max 90nm 604 pin XEON 3.2 G SL7ZE 110W 1.4V max 90nm 604 pin XEON 3.0 G...
  • Page 8 There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the manufacturer. Discard used bat- teries according to the manufacturer’s instructions. PCE-7210 User Manual viii...

  • Page 9: Table Of Contents

    2 Connecting Peripherals .........20 Introduction ..............20 1st & 2nd IDE Connectors (IDE1, IDE2) ....... 20 Figure 2.1: PCE-7210 IDE1 and IDE2 location ... 20 Floppy Drive Connector (FDD1) ........21 Figure 2.2: PCE-7210 FDD1 location ......21 Parallel Port (LPT1) ............22...
  • Page 10 Figure 2.3: PCE-7210 LPT1 location ......22 VGA Connector (VGA1) ..........23 Figure 2.4:VGA Connector (VGA1) ......23 VGA-2 Connector (VGA2)..........23 Figure 2.5:VGA Connector (VGA2) ......23 DVI connector (DVI1) ............ 24 Figure 2.6:DVI connector (DVI1) ........ 24 Serial Ports (COM1, COM3, COM4) ......25 Figure 2.7:Serial Ports (COM1, COM3, COM4) ..
  • Page 11 Chapter 3 Award BIOS Setup.........36 Introduction ..............36 3.1.1 CMOS RAM Auto-backup and Restore ....... 36 Entering Setup ..............37 Figure 3.1:Award BIOS Setup initial screen ....37 Standard CMOS Setup ............ 37 Figure 3.2:Standard CMOS features screen ....37 Figure 3.3:Standard CMOS features IDE Channel screen...
  • Page 12 Modem Use IRQ............51 3.7.8 Suspend Mode............... 51 3.7.9 HDD Power Down............51 3.7.10 Soft-Off by PWR-BTTN ..........51 3.7.11 CPU THRM-Throttling..........51 3.7.12 PowerOn by LAN ............51 3.7.13 PowerOn by Modem............. 51 3.7.14 PowerOn by Alarm ............51 PCE-7210 User Manual...
  • Page 13 3.7.15 Primary IDE 0 (1) and Secondary IDE 0 (1)....51 3.7.16 FDD, COM, LPT PORT ..........52 3.7.17 PCI PIRQ [A-D]# ............52 3.7.18 PWRON After PWR-FAIL........... 52 PnP/PCI Configuration Setup.......... 52 Figure 3.13:PnP/PCI configurations screen....52 3.8.1 Reset Configuration Data..........
  • Page 14 DVI Connector (DVI1) ..........110 Table B.6:DVI Connector (DVI1) ......110 RS-232 Serial Port (COM1,COM3,COM4)....111 Table B.7:RS-232 serial port (COM1,COM3,COM4) 111 PS/2 Keyboard/Mouse Connector (KBMS1)....112 Table B.8:PS/2 keyboard/mouse connector (KBMS1)..112 External Keyboard Connector (KBMS2)...... 112 PCE-7210 User Manual...
  • Page 15 Table B.9:External keyboard connector (KBMS2) ..112 B.10 CPU Fan Power Connector (CPUFAN1,CPUFAN2) ... 113 Table B.10:CPU Fan Power Connector (CPUFAN1,CPUFAN2) ......113 B.11 Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) ......113 Table B.11:Power LED and Keyboard Lock Connector (JFP3 / PWR_LED &...
  • Page 17 Hardware Configuration...

  • Page 18: Chapter 1 Hardware Configuration

    PCIe x8 Links which I/O bandwidth is up to 12 GB/s. With this feature PCE-7210 provide two x8 Links and one x4 Link to the PICMG 1.3 backplane, it offers up to 10 GB/s bandwidth for the back- plane.
  • Page 19 RS-232 ports, one enhanced parallel port and floppy disk interface. PCE-7210 retains a legacy PCI-X 32-bit /66 MHz bus from the CPU board to the Backplane. Don't need PCI-Express to PCI-X bridge chip for lower the system cost. Good for the application only needs few legacy PCI Bus.

  • Page 20: Features

    Onboard ATI® Radeon® 7000-M with 16MB frame buffer mem- Onboard IPMI module(Optional) 2 SATA HDDs Support S/W SATA RAID 0,1 4 USB 2.0 ports to Back plane Remote management with SNMP-1000-B1 modules CMOS automatic back and prevent accidental data loss of BIOS setup PCE-7210 User Manual...

  • Page 21: Specifications

    • AC'97 Audio: PCE-7210 can provide audio function with the optional audio extension module PCA-AUDIO-00A1 • USB ports: PCE-7210 supports up to four USB 2.0 ports with transmission rates up to 480Mbps; these ports are linked to the backplane base on PICMG 1.3 specification.

  • Page 22: Vga Interface

    Test program, Intel Max power 100% + BurnIn test 4.0 +12V 20.5 A 3.28 A +3.3V 11.51 A +5VSB 0.42 A -12V 0.01 A 0.01 A • Board size: 338 x 122 mm (13.3 x 4.8 inch) • Board weight: 0.5 kg (1.2 lb) PCE-7210 User Manual...

  • Page 23: Jumpers And Connectors

    1.4 Jumpers and Connectors Connectors on the PCE-7210 single board computer link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application.
  • Page 24 Open: Disable OBS Alarm LAN12 Dual Giga LAN RJ45 connector with Transformer AC97 AC'97 Link connector SATA1 Serial ATA1 SATA2 Serial ATA2 LANLED1 LAN1 and LAN2 LED connector BMC1 BMC connector GPIO1 GPIO header EXPCI1 HIROSA Extended PCI connector (Optional) PCE-7210 User Manual...

  • Page 25: Board Layout: Jumper And Connector Locations

    1.5 Board Layout: Jumper and Connector Locations CPUFAN1 VGA2 Figure 1.1:Jumper and Connector locations...

  • Page 26: Pce-7210 Block Diagram

    1.6 PCE-7210 Block Diagram Xeon Xeon Processor 1 Processor 0 800 MHz FSB G-LAN1 & 2 : Broadcom PCI-E x4 BCM5715C DDR II 400 Channel A DDR II 400 Intel PCI-E x4 E7520 Connector A DDR II 400 PCI-E x8...

  • Page 27: Safety Precautions

    Notice: Before install your PCE-7210 into a chassis, make sure that all components on both sides of the CPU card do not touch any metal parts, especially the chassis wall and add-on card at...

  • Page 28: Jumper Settings

    1.8.2 CMOS clear (CMOS1) The PCE-7210 single board computer contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set CMOS1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 29: Watchdog Timer Output (Jwdt1)

    1.8.3 Watchdog timer output (JWDT1) The PCE-7210 contains a watchdog timer that will reset the CPU in the event the CPU stops processing. This feature means the PCE-7210 will recover from a software failure or an EMI problem. The JWDT1 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped.

  • Page 30: System Memory

    1.9 System Memory The PCE-7210 has four sockets for 240-pin dual inline memory modules (DIMMs) in two separated memory channels. It can operate with single channel or dual channel modules. We recommend using dual channel mode to provide optimized performance. All these sockets use ECC reg- istered DDR2-400 SDRAM.

  • Page 31: Table 1.5:Memory Configuration

    Table 1.5: Memory Configuration Quantity of Location Memory Channel Memory modules (DIMM No.) Type Type One module Either A2 or B2 Non-Limited Single Two modules (A1+A2) or Non-Limited Single (B1+B2) Two modules Only A2 + B2 Same Type Dual Three modules Not Recommend Four modules (A2+B2) and...

  • Page 32: Processor Installation

    The CPU on the board must have a fan and heat sink attached, to prevent overheating. Notice: Owing to limitation of the Intel® E7520 chipset when you only use single CPU on the PCE-7210, the CPU have to be located on the CPU1 socket. Otherwise the system can not boot up normally. Warning:...

  • Page 33: Cpu Cooler Installation

    1.12 CPU Cooler Installation Please ensure that the CPU cooler included with the PCE-7210 is installed as follows: Figure 1.4: CPU Cooler Installation...
  • Page 35 Connecting Peripherals Chapter 2...

  • Page 36: Chapter 2 Connecting Peripherals

    Figure 2.1: PCE-7210 IDE1 and IDE2 location You can attach up to four IDE (Integrated Drive Electronics) drives to the PCE-7210's built-in controller. The primary (IDE1) and secondary (IDE2) connectors can each accommodate two drives. Wire number 1 on the cable is red or blue and the other wires are gray.

  • Page 37: Floppy Drive Connector (Fdd1)

    FDD1 Figure 2.2: PCE-7210 FDD1 location You can attach up to two floppy disk drives to the PCE-7210's on board controller. You can use 3.5" (720 KB, 1.44 MB) drives. The single board computer comes with a 34-pin daisy-chain drive con- nector cable.

  • Page 38: Parallel Port (Lpt1)

    Figure 2.3: PCE-7210 LPT1 location The parallel port is normally used to connect the single board computer to a printer. The PCE-7210 includes an onboard parallel port, accessed through a 26-pin flat-cable connector, LPT1. The card comes with an adapter cable which lets you use a traditional DB-25 connector. The cable has a 26-pin connector on one end and a DB-25 connector on the other, mounted on a retaining bracket.

  • Page 39: Vga Connector (Vga1)

    2.5 VGA Connector (VGA1) VGA1 Figure 2.4: VGA Connector (VGA1) The PCE-7210 includes a VGA interface that can drive conventional CRT displays. VGA1 is a standard 15-pin D-SUB connector commonly used for VGA. Pin assignments for CRT connector VGA1 are detailed in Appendix B.

  • Page 40: Dvi Connector (Dvi1)

    2.7 DVI connector (DVI1) DVI1 Figure 2.6: DVI connector (DVI1) The PCE-7210 provides a DVI interface that supports DVI display. The user can choose 26-pin to 20-pin DVI cable (p/n: 1700000821) for pro- viding DVI connector. Pin assignments for DVI connector DVI1 are detailed in Appendix B.

  • Page 41: Serial Ports (Com1, Com3, Com4)

    COM3 COM1 Figure 2.7:Serial Ports (COM1, COM3, COM4) The PCE-7210 offers three serial ports COM1, COM3 and COM4. These ports can connect to serial devices, such as a mouse or to a communica- tions network. The IRQ and address ranges for all ports are fixed. However, if you want to disable the port or change these parameters later, you can do this in the system BIOS setup.

  • Page 42: Ps/2 Keyboard/Mouse Connector (Kbms1)

    2.10 External Keyboard Connector (KBMS2) KBMS2 Figure 2.9: External Keyboard Connector (KBMS2) In addition to the PS/2 mouse/keyboard connector on the PCE-7210's rear plate, there is also an extra onboard external keyboard connector. This gives system integrators greater design flexibility.

  • Page 43: Cpu Fan Connectors (Cpufan1, Cpufan2)

    If a fan is used, this connector supports cooling fans of 12V/1A (12W) or less. 2.12 Front Panel Connectors (JFP1, JFP2, JFP3) JFP1 PWR_SW RESET HDDLED SNMP JFP2 SPEAKER JFP3 PWR_LED&KEY LOCK Figure 2.11: Front Panel Connectors (JFP1, JFP2, JFP3) There are several external switches to monitor and control the PCE-7210. Chapter 2...

  • Page 44: Atx Soft Power Switch (Jfp1 / Pwr_Sw)

    2.12.5 External speaker (JFP2 / SPEAKER) (JFP2 / SPEAKER) is a 4-pin connector for an external speaker. If there is no external speaker, the PCE-7210 provides an onboard buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed.

  • Page 45: Power Led And Keyboard Lock Connector (Jfp3 / Pwr_Led&Key Lock)

    2.12.6 Power LED and keyboard lock connector (JFP3 / PWR_LED&KEY LOCK) (JFP3 / PWR_LED&KEY LOCK) is a 5-pin connector for the power on LED and Key Lock function. Refer to Appendix B for detailed informa- tion on the pin assignments. The Power LED cable should be connected to pin 1-3.

  • Page 46: Hw Monitor Alarm (Jobs1)

    Figure 2.13: HW Monitor Alarm (JOBS1) (JOBS1) is a 2-pin connector for setting enable/disable alarm while the On Board security event acts. Table 2.2: Hardware Monitor Alarm setting Pin setting Function Close Enable OBS alarm open Disable OBS alarm PCE-7210 User Manual...

  • Page 47: Dual Giga Lan Rj45 Connector (Lan12)

    Figure 2.14: Dual Giga LAN RJ45 connector (LAN12) PCE-7210 uses the Broadcom BCM5715C dual ports Gigabit LAN chip is linked to PCIe x4 Link. With this chip PCE-7210 may provide high throughputs for heavy loading networking environment. It provides two RJ-45 connectors in the rear side and is convenient for most industrial applications.

  • Page 48: Serial Ata Interface (Sata1, Sata2)

    SATA1 Figure 2.16: Serial ATA interface (SATA1, SATA2) In addition to the two EIDE interfaces (up to four devices), the PCE-7210 features a high performance serial ATA interface (up to 150MB/s) which eases cabling to hard drives with thin and long cables. These two port can be configured as RAID 0 and RAID 1 applications.

  • Page 49: Bmc Connector (Bmc1)

    2.18 BMC connector (BMC1) BMC1 Figure 2.18: BMC connector (BMC1 PCE-7210 is designed for supporting IPMI 2.0. The BMC module is mounted on board thru this connector. For more detail operating informa- tion, please refer to Chapter 9. 2.19 GPIO header (GPIO1) GPIO1 Figure 2.19: GPIO header (GPIO1)
  • Page 51 Award BIOS Setup Chapter 3...

  • Page 52: Chapter 3 Award Bios Setup

    "CMOS checksum error..." display screen mes- sage appearing. Then enter the "Setup" screen to modify the data. If the "CMOS checksum error..."message appears again and again, please check to see if you need to replace the battery in your system. PCE-7210 User Manual...

  • Page 53: Entering Setup

    3.2 Entering Setup Turn on the computer and press <Del> to enter the BIOS setup. Figure 3.1: Award BIOS Setup initial screen 3.3 Standard CMOS Setup Choose the "Standard CMOS Features" option from the "Initial Setup Screen" menu, and the screen below will be displayed. This menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory.

  • Page 54: Figure 3.3:Standard Cmos Features Ide Channel Screen

    Enter the information directly from the keyboard. This information should be pro- vided in the documentation from your hard disk vendor or the system manufacturer. Figure 3.3: Standard CMOS features IDE Channel screen PCE-7210 User Manual...

  • Page 55: Advanced Bios Features

    The "Advanced BIOS Features" screen appears when choosing the "Advanced BIOS Features" item from the "Initial Setup Screen" menu. It allows the user to configure the PCE-7210 according to his particular requirements. Below are some major items that are provided in the Advanced BIOS Features screen.

  • Page 56: Hard Disk Boot Priority

    3.4.9 Boot Up Floppy Seek Selection of the command "Disabled" will pass the Floppy disk driver during the boot up procedure and it will speed the boot up. Selection of "Enabled" searches disk drives during boot up. PCE-7210 User Manual...

  • Page 57: Boot Up Numlock Status

    3.4.10 Boot Up NumLock Status This feature selects the "power on" state for NumLock. The commands are "Off" or "On". 3.4.11 Gate A20 Option "Normal": A pin in the keyboard controller controls GateA20. "Fast" (Default): Lets chipset control GateA20. 3.4.12 Typematic Rate Setting The typematic rate is the rate key strokes repeat as determined by the key- board controller.

  • Page 58: Mps Version Control For Os

    This is for setting the waiting time that local system waits for Host system response. The selection is "3", "6", "12", "18" second. 3.4.22 Agent after boot When choose "enable" the host system still can monitor local system after local system entering "DOS" environment. PCE-7210 User Manual...

  • Page 59: Advanced Chipset Features

    By choosing the "Advanced Chipset Features" option from the "Initial Setup Screen" menu, the screen below will be displayed. This sample screen contains the manufacturer's default values for the PCE-7210, as shown in Figure 3-6: Figure 3.6: Advanced Chipset features screen...

  • Page 60: Memory Hole At 15M-16M

    DIMM per channel to be held in reserve and brought on-line if another DIMM in the channel becomes defective. 3.5.7 Init Display first Choose the first display interface to initiate while booting. The choices are "PCI Slot and Onboard/AGP". PCE-7210 User Manual...

  • Page 61: Integrated Peripherals

    3.6 Integrated Peripherals The "Integrated Peripherals" screen appears when choosing the "Inte- grated Peripherals" item from the "Initial Setup Screen" menu. It allows the user to configure the PCE-7210 on board device according to his par- ticular requirements. Figure 3.7: Integrated peripherals There are three sub screen of the "Integrated Peripherals"...

  • Page 62: Ide Hdd Block Mode

    SATA is operating in legacy mode. 3.6.5 Serial ATA Port0/Port1 Mode Select the mode for SATA port0 and SATA port1. The choices are "Pri- mary Master", "Primary Slave", "Secondary Master", "Secondary Slave", "SATA0 Master" and "SATA1 Master". Figure 3.9: Onbaord Device PCE-7210 User Manual...

  • Page 63: Usb Controller

    3.6.6 USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) con- troller and you have USB peripherals. The choices: "Enabled", "Dis- abled". 3.6.7 USB 2.0 Controller This entry is to disable/enable the USB 2.0 controller only. The BIOS itself may/may not have high speed USB support.

  • Page 64: Onboard Serial Port 1

    "ECP + EPP" allows normal speed operation in a two-way mode. 3.6.21 EPP Mode Select This field allows you to select EPP port type 1.7 or 1.9. The choices: "EPP1.9", "EPP1.7". 3.6.22 ECP Mode Use DMA PCE-7210 User Manual...

  • Page 65: Onboard Serial Port 3

    This selection is available only if you select .ECP. or .ECP + EPP. In the Parallel Port Mode field. In ECP Mode Use DMA, you can select DMA channel 1, or DMA channel 3. Leave this field on the default setting. 3.6.23 Onboard Serial Port 3 The settings are "3F8", "2F8 ", "3E8 ", "2E8 "and "Disabled"...

  • Page 66: Figure 3.12:Power Management Setup Screen-2

    Figure 3.12: Power management setup screen-2 3.7.1 Power Supply Type PCE-7210 can support both "ATX" and "AT" power supply. Customers can choose the PSU type through this selection. The choices are: "ATX","AT". While selecting "AT", the ACPI function will disable auto- matically.

  • Page 67: Video Off Method

    3.7.4 Video Off Method Use this to select the method to turn off the video. The choices are : "Blank Screen", "V/H SYNC+ Blank", "DPMS". 3.7.5 Video Off In Suspend When the system is in suspend mode, the video will turn off. The choices are "No"...

  • Page 68: Pce-7210 User Manual

    System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system can not boot. The settings are: Enabled and Disabled (Default). PCE-7210 User Manual...

  • Page 69: Resource Controlled By

    3.8.2 Resource Controlled By The Award Plug and Play BIOS has the capacity to automatically config- ure all the boot and Plug and Play compatible devices. However, this capability means absolutely nothing unless you are using a Plug and Play operating system such as Windows®...

  • Page 70: Pc Health Status

    VBAT(V) and 5VSB(V). 3.9.6 Shutdown Temperature The system will shut down automatically when the CPU temperature is over the selected setting. This function can prevent CPU damage caused by overheating. It only works under the ACPI power mode. PCE-7210 User Manual...

  • Page 71: Frequency Control

    3.10 Frequency Control Figure 3.15: Frequency Control screen 3.10.1 Spread Spectrum Use this function to tune the PCI clock frequency. Setting this option to Disabled will limit the clock signal spread, increase the consistency of the frequency, but increase the EMI. Setting this option to Enabled will decrease the EMI.

  • Page 72: Load Setup Defaults

    When you press <Enter> on this item, you get a confirmation dialog box with a message similar to: • Load setup Defaults (Y/N) ? N Pressing 'Y' loads the default values that are factory settings for optimal performance system operations. PCE-7210 User Manual...

  • Page 73: Set Password

    3.12 Set Password Figure 3.17: Set Password screen To change, confirm, or disable the password, choose the "Set Password" option from the Setup main menu and press Enter. The password can be at most 8 characters long. Remember, to enable this feature. You must first select the Security Option in the Advance BIOS FEATURES SETUP to be either "Setup"...

  • Page 74: Save & Exit Setup

    This record is required for the system to operate. 3.14 Exit Without Saving Figure 3.19: Exit Without Saving screen Selecting this option and pressing the Enter key lets you exit the Setup program without recording any new values or changing old ones. PCE-7210 User Manual...
  • Page 75 Chipset Software Installation Utility Chapter 4...

  • Page 76: Chapter 4 Chipset Software Install Utility

    To facilitate the installation of the enhanced display device drivers and utility software, you should read the instructions in this chapter carefully before you attempt installation. The device drivers for the PCE-7210 board are located on the software installation CD. The auto-run function of the driver CD will guide and link you to the utilities and device drivers under a Windows system.

  • Page 77: Windows Xp Driver Setup

    • USB 1.1/2.0 support • Identification of Intel® chipset components in the Device Manager. • Integrates superior video features. These include filtered sealing of 720 pixel DVD content, and MPEG-2 motion compensation for software Note: This utility is used for the following versions of Windows system, and it has to be installed before installing all the other drivers: Microsoft Windows* Server 2003 with Service Pack 1...
  • Page 78 Select the PCE-7210 for entering the following screen. Move the mouse cursor over the "Install" button under the "CSI UTILITY" heading, a message pops up telling you to install the CSI utility before other device drivers, as shown in the following figure. Click on this button.
  • Page 79 Click "Yes" when you see the following message. Click "Next" when you see the following message. Chapter 4...
  • Page 80 When the following message appears, click "Finish" to complete the installation and restart Windows. PCE-7210 User Manual...
  • Page 81 VGA Setup Chapter 5...

  • Page 82: Chapter 5 Vga Setup

    Chapter 5 VGA Setup 5.1 Introduction • The PCE-7210 has VGA onboard; you need to install the VGA driver to enable the function. • The on-board ATI RADEON 7000-M graphic accelerator including 16MB frames buffer memory on chip. It provides dual VGA display and supports DVI interface for panel display.
  • Page 83 Insert the driver CD into your system's CD-ROM drive and choose the directory \\02-VGA_driver\Framework. Double click the "dot- netfx.exe" for installing the Microsoft .NET Framework. Click "Yes" when you see the following message. Choose "I agree" and Click "Install" when you see the following message.
  • Page 84 Windows XP. For other operating systems, please follow the on-screen installation guide. Double click the "6-2_xp- 2k_dd_ccc_wdm_enu_30152.exe". Click the"Install" button when you see the following message. Click "Next" when you see the following message. PCE-7210 User Manual...
  • Page 85 Click "Yes" when you see the following message. Click "Express Recommend" when you see the following message. Chapter 5...

  • Page 86: Microsoft® Windows Server™ 2003 & Windows Server 2003 X64 Driver Setup

    Before you install the driver for Microsoft® Win- dows Server™ 2003 & Windows Server 2003 x64, you need to set the display property by following these steps. Right click the desk top screen and choose the “Properties”. PCE-7210 User Manual...
  • Page 87 Choose the “Setting” tag. Choose the “Advanced” icon. Chapter 5...
  • Page 88 Choose the “Troubleshoot” tag. Move the “Hardware Acceleration” to full. Go to the directory: \\02-VGA_driver\Windows_2003_XP_x64 and run setup.exe; then, follow the setting procedure to ensure the driver can be installed successfully. PCE-7210 User Manual...
  • Page 89 LAN Configuration Chapter 6...

  • Page 90: Chapter 6 Lan Configuration

    Chapter 6 LAN Configuration 6.1 Introduction The PCE-7210 designed with Broadcom BCM5715C which is a 10/100/ 1000BASE-T dual-port LAN controller for high performance server application. It provides a single x4 PCI express host interface and two integrated Gigabit Ethernet Controllers which may provide higher Thru- put than the chips interface with PCI bus.
  • Page 91 Choose "I accept the terms in the license agreement" and then click "Next" when you see the following message. Click "Install" when you see the following message. Then the driver installation procedure will be run automatically. Click "Finish" when you see the following message. Chapter 6...
  • Page 92 After installing the driver, you may choose to install the S/W utility for this LAN chip. You may choose the "Users Guide" for more detail infor- mation about the LAN function. PCE-7210 User Manual...
  • Page 93 Onboard Security Setup Chapter 7...

  • Page 94: Chapter 7 Onboard Security Setup

    • Main voltage: -5 V, -12 V. 7.2 Windows XP Driver Setup 1. Insert the driver CD into your system’s CD-ROM drive and choose the PCE-7210 for seeing the following screen. Then click the install button of the OBS driver.: PCE-7210 User Manual...
  • Page 95 2. Click "Next" when you see the following message. 3. Click "Next" when you see the following message. 4. Click "Next" when you see the following message. Chapter 7...
  • Page 96 5. Click "Finish" when you see the following message. 6. Click "Yes" if you want to create a short cut for the hardware doctor. 7. Click "Yes" to restart your system after the OBS utility installed fin- ish. PCE-7210 User Manual...

  • Page 97: Using The Obs Hardware Doctor Utility

    7.3 Using the OBS Hardware Doctor Utility After completing the setup, all the OBS functions are permanently enabled. When a monitored reading exceeds safe limits, a warning mes- sage will be displayed and an error beep tone will activate to attract your attention.
  • Page 99 SATA RAID Setup Chapter 8...

  • Page 100: Chapter 8 Sata Raid Setup

    2000, Windows Server 2003, Windows XP; Linux: Red Hat Advanced Server 2.1 and 3.0, SuSE SLES 8.0 and 8.2, SuSE 9.0, United Linux 1.0, Miracle Linux 2.1 Note: Device drivers and utility software require around 20 MB disk space PCE-7210 User Manual...

  • Page 101: Windows Xp Driver Setup

    8.2 Windows XP Driver Setup Note: The following installation guide is only the basic procedure for S/W SATA RAID driver, if you want to know more detail information, please check the User Guide in the driver CD. Path: \\04SATA_RAID_driver\user’s guide Before you install the SATA RAID driver under, the BIOS has to be set accordantly.
  • Page 102 Double Click “Device manager” and you will see the device with question mark. Right Click “RAID Controller” which with question mark. And choose update driver. PCE-7210 User Manual...
  • Page 103 Choose “No, not this time” and click “Next”. Choose “Install from a list or specific location (advanced)” and click “Next”. Choose “Include this location in the search” and click “Browse”. Chapter 8...

  • Page 104: Utility For Sata Raid

    8.3 Utility for SATA RAID There is a basic storage management utility attached in this driver CD. Path: \\04-SATA_RAID_driver\Adaptec Embedded SATA Hos- tRAID\utility-ASM_BE\ASM 4494\ASM 4494\books. If you want to use this utility, please read the user guide in folder "books". PCE-7210 User Manual...
  • Page 105 IPMI Chapter 9...

  • Page 106: Table 9.1:Supported Ipmi Commands

    IPMI Device Global Com- Mandatory / NetFn mands Optional Get Device Id 0x01 Cold Reset 0x02 Get Self Test Results 0x04 Manufacturing Test On 0x05 Set ACPI Power State 0x06 Get ACPI Power State 0x07 Get Device GUID 0x08 PCE-7210 User Manual...
  • Page 107 BMC Device and NetFn Mandatory / Messaging Commands Optional Set BMC Global Enables 0x2e Get BMC Global Enables 0x2f Clear Message Flags 0x30 Get Message Flags 0x31 Enable Message Channel 0x32 Receive Get Message 0x33 Send Message 0x34 Read Event Message Buffer 0x35 Get System GUID 0x37...
  • Page 108 SDR Device Commands NetFn Mandatory / Optional Get SDR Repository Info Storage 0x20 Reserve SDR Repository Storage 0x22 Get SDR Storage 0x23 Get SDR Repository Time Storage 0x28 Set SDR Repository Time Storage 0x29 Run Initialization Agent Storage 0x2c PCE-7210 User Manual...
  • Page 109 FRU Device Commands NetFn Mandatory / Optional Get FRU Inventory Area Info Storage 0x10 Read FRU Inventory Data Storage 0x11 Write FRU Inventory Data Storage 0x12 Sensor Device NetFn Mandatory / Commands Optional Set Sensor Hysteresis 0x24 Get Sensor Hysteresis 0x25 Set Sensor Threshold 0x26...

  • Page 110: Table 9.2:Oem Commands List

    3 = fail in User Info module 4 = fail in Serial module 5 = fail in SOL module 6 = fail in PEF module 7 = fail in Firewall module 8 = fail in System Information PCE-7210 User Manual...
  • Page 111 Programming the Watchdog Timer Appendix A...

  • Page 112: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watch- dog Timer A.1 Watchdog Timer The PCE-7210's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function after the programmed period. This section describes the operation of the watchdog timer and how to program it.
  • Page 113 Unlock W83627HF Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog time Lock W83627HF Appendix A...

  • Page 114: Table A.1:Watchdog Timer Registers

    (hex). This number decides how long the watchdog timer waits for strobe before generating an inter- rupt or reset signal. Writing a new value to this register can reset the timer to count with the new value. PCE-7210 User Manual...

  • Page 115: Example Program

    F7 (hex) read/write Bit 6: Write 1 to enable key- board to reset the timer, 0 to disable.[default] Bit 5: Write 1 to generate a timeout signal immediately and automatically return to 0. [default=0] Bit 4: Read status of watch- dog timer, 1 means timer is ""time out""."...
  • Page 116 Out dx,al Enable watchdog timer and set 5 minutes as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h PCE-7210 User Manual...
  • Page 117 Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h Out dx,al al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 118 ; Enable watchdog timer to be reset by mouse Mov al,0f7h Out dx,al al,dx Or al,80h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h PCE-7210 User Manual...
  • Page 119 Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 120 Out dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al PCE-7210 User Manual...
  • Page 121 I/O Pin Assignments Appendix B...

  • Page 122: Appendix B I/O Pin Assignments

    SIGNAL GND DISK DMA REQUEST IO WRITE IO READ IO CHANNEL READY CSEL HDACKO* IRQ14 IDSC16- ADDR 1 PDIAG ADDR 0 ADDR 2 HARD DISK SELECT 0* 38 HARD DISK SELECT 1* IDE ACTIVE* * low active PCE-7210 User Manual...

  • Page 123: Floppy Drive Connector (Fdd1)

    B.2 Floppy Drive Connector (FDD1) Table B.2: Floppy drive connector (FDD1) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active Appendix B...

  • Page 124: Parallel Port Connector (Lpt1)

    B.3 Parallel Port Connector (LPT1) Table B.3: Parallel port connector (LPT1) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCE-7210 User Manual...

  • Page 125: Vga Connector (Vga1)

    B.4 VGA Connector (VGA1) Table B.4: VGA connector (VGA1) Signal Signal GREEN BLUE H-SYNC V-SYNC B.5 VGA-2 Connector (VGA2) Table B.5: VGA-2 Connector (VGA2) Signal CRT2_R1 CRT2_G1 CRT2_B1 D2_HS1OUT D2_VS1OUT DDC3_SDAOUT DDC3_SCLOUT VCC_VGA03 Appendix B...

  • Page 126: Dvi Connector (Dvi1)

    B.6 DVI Connector (DVI1) Table B.6: DVI Connector (DVI1) Signal Signal #TMDS1_0 AGP_5V_TMDS2 DDC3_SDAOUT TMDS1_0 #TMDS1_2 #TMDS1_2 TMDS1_2 TMDS1_CK ATI_12C_DAT #TMDS1_1 AGP_5V_TMDS2 ATI_12C_CLK #TMDS1_1 CPIS_ENA_BL DDC3_SCLOUT CPIS_VDD_VCL PCE-7210 User Manual...

  • Page 127: Serial Port (Com1,Com3,Com4)

    B.7 RS-232 Serial Port (COM1,COM3,COM4) Table B.7: RS-232 serial port (COM1,COM3,COM4) Signal Appendix B...

  • Page 128: Ps/2 Keyboard/Mouse Connector (Kbms1)

    B.8 PS/2 Keyboard/Mouse Connector (KBMS1) Table B.8: PS/2 keyboard/mouse connector (KBMS1) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.9 External Keyboard Connector (KBMS2) Table B.9: External keyboard connector (KBMS2) Signal KBCLK KBDAT MSDAT MSVCC MSCLK PCE-7210 User Manual...

  • Page 129: Cpu Fan Power Connector (Cpufan1,Cpufan2)

    B.10 CPU Fan Power Connector (CPUFAN1,CPUFAN2) Table B.10: CPU Fan Power Connector (CPUFAN1,CPUFAN2) Signal +12V Detect B.11 Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) Table B.11: Power LED and Keyboard Lock Connector (JFP3 / PWR_LED & KEY LOCK) Function LED power (+5 V) KEYLOCK#...

  • Page 130: External Speaker Connector (Jfp2 / Speaker)

    B.12 External Speaker Connector (JFP2 / SPEAKER) Table B.12: External Speaker Connector (JFP2 / SPEAKER) Function SPK+ SPK_IN SPK- B.13 Reset Connector (JFP1 / RESET) Table B.13: Reset connector (JFP1 / RESET) Signal RESET # PCE-7210 User Manual...

  • Page 131: Hdd Led (Jfp2 / Hddled)

    B.14 HDD LED (JFP2 / HDDLED) Table B.14: HDD LED (JFP2 / HDDLED) Signal IDE LED+ IDE LED- B.15 ATX Soft Power Switch (JFP1 / PWR_SW) Table B.15: ATX soft power switch (JFP1 / PWR_SW) Signal 5VSB PWR-BTN Appendix B...

  • Page 132: Ac'97 Link Connector (Ac97)

    3 Sync 4 BITCLK 5 SDOUT 6 SDIN0 7 SDIN1 8 AC-RST 9 +12V 10 GND 11 GND 12 N/C B.17 SM Bus Connector (JFP2 / SNMP) Table B.17: SM bus onnector (JFP2 / SNMP) Signal SMB_DATA SMB_CLK PCE-7210 User Manual...

  • Page 133: Lan1 And Lan2 Led Connector (Lanled1)

    B.18 LAN1 and LAN2 LED connector (LANLED1) Table B.18: LAN1 and LAN2 LED connector (LANLED1) Signal #LAN1_ACT V33_AUX #LAN1_LINK1000 #LAN1_LINK100 V33_AUX #LAN2_ACT V33_AUX #LAN2_LINK1000 #LAN2_LINK100 Appendix B...

  • Page 134: Gpio Header (Gpio1)

    B.19 GPIO header (GPIO1) Table B.19: GPIO header (GPIO1) Signal GPIO_1 GPIO_5 VCC_GPIO GPIO_2 GPIO_6 GPIO_3 GPIO_7 GPIO_4 GPIO_8 PCE-7210 User Manual...

  • Page 135: System I/O Ports

    B.20 System I/O Ports Table B.20: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 136: Dma Channel Assignments

    B.21 DMA Channel Assignments Table B.21: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available PCE-7210 User Manual...

  • Page 137: Interrupt Assignments

    B.22 Interrupt Assignments Table B.22: Interrupt assignments Priority Interrupt# Interrupt source Parity error detected IRQ0 Interval timer IRQ1 Keyboard IRQ2 Interrupt from controller 2 (cascade) IRQ8 Real-time clock IRQ9 Cascaded to INT 0A (IRQ 2) IRQ10 Available IRQ11 Available IRQ12 PS/2 mouse IRQ13 INT from co-processor...

  • Page 138: Pci Bus Map

    REQ A PCI slot 2 AD30 INT C, D, A, B GNT B REQ B PCI slot 3 AD29 INT B,C,D,A GNT C REQ C PCI slot 4 AD28 INT A, B, C, D GNT D REQ D PCE-7210 User Manual...
  • Page 139 Programming the GPIO and Watchdog Timer Appendix C...

  • Page 140: Appendix C Programming Gpio & Watchdog Timer

    Extended Function Index Registers (EFIRs) The EFIRs are write-only registers with port address 2Eh or 4Eh on PC/ AT systems. Extended Function Data Registers(EFDRs) the EFDRs are read/write registers with port address 2Fh or 4Fh on PC/ AT systems. PCE-7210 User Manual...

  • Page 141: Gpio Example Program-1

    C.1.2 GPIO Example program-1 ------------------------------------------------ Enter the extended function mode, interruptible double-write ------------------------------------------------ MOV DX,4EH MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------- Configurate logical device 7(GP10~GP17), configuration register CRF0,CRF1,CRF2 --------------------------------------------------------------- MOV DX,4EH MOV AL,07H ; point to Logical Device Number Reg. OUT DX,AL MOV DX,4FH MOV AL,07H ;...
  • Page 142 OUT DX,AL MOV DX,4FH MOV AL,??H ; Put the output value into AL OUT DX,AL ------------------------------------------ Exit extended function mode | ------------------------------------------ MOV DX,4EH MOV AL,AAH OUT DX,AL PCE-7210 User Manual...

Table of Contents
