HPL lamps

Lamp code Watts Volts
HPL 375/115 375 115
HPL 375/115X 375 115
HPL 375/230X 375 230
HPL 375/240X 375 240
HPL 550/77 550 77
HPL 550/77X 550 77
HPL 575/115 575 115
HPL 575/115X 575 115
HPL 575/120 575 120
HPL 575/120X 575 120
HPL 575/230 575 230
HPL 575/230X 575 230
HPL 575/240 575 240
HPL 575/240X 575 240
HPL 750/115 750 115
HPL 750/115X 750 115
HPL 750/120 750 120
HPL 750/120X 750 120
HPL 750/230 750 230
HPL 750/230X 750 230
HPL 750/240 750 240
HPL 750/240X 750 240
WARNING:

Lens identification

Lenses for the Source Four MultiPAR come in four versions. The type or beam
spread can be identified by the lens texture.
VNSP
Very narrow spot
Clear glass
15° Round beam shape
MFL
Medium flood
Fewer facets, sized 6 x 22mm
21° x 34° Oblong beam shape
www.BulbAmerica.com
Color temp Ave rated life
3,250ºK 300 hour
3,050ºK 1,000 hour
3,000ºK 1,000 hours
3,000ºK 1,000 hours
3,250ºK 300 hour
3,050ºK 2,000 hour
3,250ºK 300 hour
3,050ºK 2,000 hour
3,250ºK 300 hour
3,050ºK 2,000 hour
3,200ºK 400 hour
3,050ºK 1500 hours
3,200ºK 400 hour
3,050ºK 1500 hours
3,250ºK 300 hours
3,050ºK 1000 hours
3,050ºK 2,000 hour
3,050ºK 2,000 hour
3,200ºK 300 hours
3,050ºK 1500 hours
3,200ºK 300 hours
3,050ºK 1500 hours
Use of other lamps may pose a safety risk, damage
the fixture, and will void your warranty.
NSP
Narrow spot
Stipple glass (slight diffuse texture)
19° Round beam shape
WFL
Wide flood
Many facets, sized 6 x 12mm
30° x 51° Oblong beam shape
or CALL TOLL FREE 888-505-2111
Source Four MultiPAR • 3
