Assembly and operation of this aircraft must be done by or under the direct
supervision of a responsible adult. If not handled correctly, this model is capable of
inflicting serious bodily harm. It is your responsibility and yours alone to assemble this
model correctly, properly install all R/C components, and to test and operate it in a safe
and responsible manner.
Copyright
1994
INSTRUCTION BOOK
WARNING! THIS IS NOT A TOY!
Sturdy
Birdy
Advertisement
Table of Contents
Related Manuals for Hobbico Sturdy Birdy
Summary of Contents for Hobbico Sturdy Birdy
- Page 1 Sturdy Birdy INSTRUCTION BOOK WARNING! THIS IS NOT A TOY! Assembly and operation of this aircraft must be done by or under the direct supervision of a responsible adult. If not handled correctly, this model is capable of inflicting serious bodily harm. It is your responsibility and yours alone to assemble this model correctly, properly install all R/C components, and to test and operate it in a safe and responsible manner.
-
Page 2: Table Of Contents
Repairing......................18 INTRODUCTION Congratulations on your purchase of the HOBBICO STURDY BIRDY, THE FIRST REAL SUPER TRAINER You now own the BEST FLYING durable trainer available By following these instructions as you assemble the model you will have a great flying plane that will not only teach you how to fly but it will stick with you while you learn, no matter... -
Page 3: Parts List
PARTS LIST Stock #..Description ........Qty Stock # ..Description ........Qty ARF1F01 ..Plastic Fuse Tube......1 ARF1F05 ..Landing Gear Strips.....2 ARF1F02 ..Aluminum Channel ......1 ARF1S04 ..1/16" Ply Stab Doubler....1 ARF1P01 ..Instruction Book......1 DOWEL030.. 1/4" Dowel........4 ARF1R05..1/64" Ply Fin Doubler....1 ARF1M01 ..Hardware Sub-Pack EM2040 ..Engine Mount (Left &... -
Page 4: Additional Item List
FUEL TANK ADDITIONAL ITEMS The STURDY BIRDY was designed to hold a square NEEDED tank We recommend a Great Planes 6 oz. tank (#GPMQ4102). Here is a description of some of the additional items you will need to assemble your STURDY BIRDY. -
Page 5: Fin/Rudder
CONSTRUCTION FIN/RUDDER so that the outer hinges are approximately 1" from the ends of the rudder and the middle hinge is in the center. D 1. The fin is made up of the three pieces shown above. Locate these three pieces and lay them out. D 4. - Page 6 D 6. Trial fit the fin and rudder together using the hinges to check for proper alignment. Do not glue the hinges in place yet! Sand the rudder and/or fin so they match each other at the top. D 7. Remove the hinges from the rudder and bevel the leading edge with your sanding block as shown in the sketch.
- Page 7 D 16. Mark the hinge locations using the same technique D 13. Use a sanding block to round the edges of the you used in step #4. There are five hinges used here. The fin/rudder assembly as shown above. Give the sides a outer hinges are approximately 1"...
-
Page 8: Wing Assembly
bottom of the channel and line the stabilizer up with the slots in the wing to make sure it fits nicely Mix up channel (using the line you just drew) When you are about 1/2 oz of epoxy and spread it throughout the satisfied with the alignment draw a line down both sides slot in one wing panel With the wing panel upside of the channel on the top of the stabilizer. -
Page 9: Covering
If you are planning on doing some aerobatics or combat with your STURDY BIRDY you should also put three D 29. Cut the supplied 2" x 9" CA Hinge Strip into 24 strips of tape on the top surface of the wing. -
Page 10: Fuselage
round off the corners with a sanding block. Test fit the doubler into the front of the plastic fuselage tube as shown in the photo. The firewall doubler should fit into the fuselage with a snug but not tight fit. The front of the fuselage is cut at a slight angle so the firewall and thus the engine will point down slightly. - Page 11 D 37. Cut the "spreader bar" off each mount half. Trim D 40. Temporarily install the engine on the mount with off any burrs or flashing, then snap the mount halves two #4 x 1/2" sheet metal screws. Mark the location of together.
