R-55E-18 (26-Pos.) Frame - AudioArts Engineering audio console r-55e Technical Manual

ITEM#
R-55e / Dec 2004
R-55e-18 26-pos. FRAME PARTS LIST
CLK-55e CLOCK/TIMER ASSEMBLY
MB REAR
PAN BRACE
MB POWER CONNECTOR BRACKET
BLANK FACEPLATE FOR R-55e
QMP-4 LOADED CARD ASSEMBLY
MBE-5508 LOADED CARD ASSEMBLY
MBR-5510 LOADED CARD ASSEMBLY
R55e-18 METAL ARMREST
R55e-18 METERBRIDGE COVER
R55e-18 FRAME PAN
R55e-18 CONNECTOR KIT
LED-3 LOADED CARD
CLK-220 LENSE
PAINTED MDF LEFT SIDEPLATE
PAINTED MDF RIGHT SIDEPLATE
ALUMINUM CONTINUOUS HINGE, 72"X1.06" X .040"
SET RIGHT/LEFT END CAP
SET FRONT/BACK FOAM INSERT
3/8" WIDE X 1/16" THICK X 100' LONG BLACK FELT STRIP
26 COND FLAT RIBBON CABLE
29 7/8" X 17 3/4" X 31 7/8" 275D BOX TOP
29 1/8" X 17 5/16" X 31 3/4" BOX BOTTOM
10 PIN PLUG
3 PIN .098" PLUG FOR #26 AWG
PLASTIC SHELL CHASSIS CONNECTOR
16 PIN RIBBON PLUG
RTS JACK
PIN M MOLEX
PATCH CLIPS
PATCH CLIPS
VU METER
LIGHT BOX FOR AL29 METER WITHOUT LAMP OR
LAMPHOLDER
FLAT WASHER
SHOULDER WASHER
4-40 X .250 HEX ZINC
DESCRIPTION
14-20GA REEL
QTY W#
1 005558
1 003565
1 003567
1 003579
6 005539
1 005549
1 005551
1 005555
1 005577
1 005578
1 005579
1 005596
4 007104
1 026057A
1 100090
1 100091
0.55 110024
1 130231
1 130232
0.02 130248
2.5 150083
1 160046
1 160047
5 230020
2 230028
1 230070
1 250039
1 260005
8 270050A
9 280000
3 280007
4 630004
4 630008
1 822007
1 822008
27 823016
page 11 - 28
