LS-55e LINE SELECT MODULE PARTS LIST
ITEM#
LS-55e
CT2
CT1
CT2
R1-R12
SW1-SW6
1-6 SWITCH BUTTON
PCB_LS2600
R-55e / Dec 2004
DESCRIPTION
FACEPLATE
25 PIN DB CONNECTOR
RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
26 PIN PLUG
26 PIN PC MOUNT STRAIGHT UP SMT HEADER
10.0 KOHM 1% .25W MC1206 RESISTOR
6 STATION 4 POLE INTERLOCKED SWITCH, 12.5MM
SPACING
SOLID GREY LUMA-230 BUTTON
PRINTED CIRCUIT BOARD
D SUB STANDOFFJACK HARDWARE 3/16" LONG
PEM FASTENERS
QTY W#
1 005526
1 200018
1 220120
1 250043
1 255003
12 435028
1 510040
6 530273
1 700679
4 820047
3 821009
page 11 - 15
