AudioArts Engineering audio console r-55e Technical Manual page 83

SPN-55e SUPERPHONE MODULE PARTS LIST
ITEM#
SPN-55e
CT1
CT6, CT7
CT4
U6
U1-U5
Q1, Q2
Z3
D5, D6
Z1, Z2
D1-D4
U7-U11
C2, C3, C23, C27, C29-C31, C35, C37-C39, C44
C10, C22, C28
C5, C6, C8, C11, C13-C15, C17, C19, C20, C24,
C26
C41
C4, C7, C12, C16, C18, C21, C25, C32-C34, C36,
C40, C43, C45
C42
R2, R5, R6, R20, R39, R41
R7, R8, R10, R13, R81, R82
R42, R79
R46
R44, R48, R50, R52
R80
R12, R26, R29, R30
R37, R38, R75-R78
R55, R62-R68, R73, R74
R11, R14, R28, R31
R1, R21, R22, R24, R25, R36, R43, R45, R47, R49,
R51, R57, R59, R69-R72, R83
R40, R54
R35
R15, R32
R34, R53
CR1
R-55e / June 2004
DESCRIPTION
FACEPLATE
RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
6 PIN .098" PLUG FOR #26 AWG
9 PIN .098" PLUG FOR #26 AWG
6 PIN .098" HEADER
9 PIN .098" HEADER
74ACT00 TTL SMT Quad 2-Input NAND
NE5532 DUAL LINEAR OP-AMP SMT
MMBTA55 PNP SMT TRANSISTOR
6.2V 1W ZENER DIODE
1N4002W RECTIFYING 1AMP SMT DIODE
5.1V SMT ZENER DIODE C5V1
1N4148 FAST SWITCHING SMT DIODE
74VHC4053 SMT Triple 2-Channel Analog Mux
CAPACITOR, 22µF 25V ELECTROLYTIC SMT
CAPACITOR, 100µF 25V ELECTROLYTIC SMT
CAPACITOR, 10pF 100V CERAMIC SMT
CAPACITOR, .01µF 50V CERAMIC SMT
CAPACITOR, .1µF 50V CERAMIC SMT
CAPACITOR, .22µF 50V CERAMIC SMT
10 OHM 5% .25W MC1206 RESISTOR
100 OHM 5% .25W MC1206 RESISTOR
220 OHM 5% .25W MC1206 RESISTOR
332 OHM 1% .25W MC1206 RESISTOR
619 OHM 1% .25W MC1206 RESISTOR
1.00 KOHM 1% .25W MC1206 RESISTOR
1.69 KOHM 1% .25W MC1206 RESISTOR
2.43 KOHM 1% .25W MC1206 RESISTOR
4.99 KOHM 1% .25W MC1206 RESISTOR
8.45 KOHM 1% .25W MC1206 RESISTOR
10.0 KOHM 1% .25W MC1206 RESISTOR
22.1 KOHM 1% .25W MC1206 RESISTOR
40.2 KOHM 1% .25W MC1206 RESISTOR
53.6 KOHM 1% .25W MC1206 RESISTOR
88.7 KOHM 1% .25W MC1206 RESISTOR
10K TRIM POT
QTY W#
1 005523
1 220120
2 230031
1 230032
2 250065
1 250066
1 305004
5 325001
2 345002
1 350013
2 355001
2 355002
4 355003
5 385001
12 405002
3 405003
12 415001
1 415006
14 415007
1 415009
6 435002
6 435007
2 435009
1 435010
4 435013
1 435015
4 435017
6 435020
10 435023
4 435026
18 435028
2 435036
1 435039
2 435041
2 435043
1 500021
page 11 - 13
