AudioArts Engineering audio console r-55e Technical Manual page 77

CRS-55e CONTROL ROOM/STUDIO MODULE PARTS LIST
ITEM#
CRS-55e
CT2
CT1
CT3
CT5-CT7
CT2
U8, U25, U26
U20-U22
U1-U7, U9-U12, U23, U24
Q1
Z3
D1, D2
Z1, Z2
D4
D3
U13-U19
C1-C3, C19-C28, C31-C33, C47, C48, C50,
C65-C68, C97-C99, C102, C105, C109-C112
C29, C30, C95, C96, C101
C49, C53
C69, C71, C73, C83, C86, C89
C4, C6, C7, C9, C11, C13, C14, C16, C34, C36,
C39, C41, C43-C45, C51, C56, C58, C59, C61
C63, C75, C77, C78, C80, C82, C93, C94, C106,
C108
C70, C72, C74
C85, C88, C91
C5, C8, C10, C12, C15, C17, C18, C35, C37, C38,
C40, C42, C46, C52, C54, C55, C57, C60
C62, C64, C76, C79, C81, C92, C100, C103, C104,
C107
C84, C87, C90
R147-R152
R6, R9, R10, R15, R20, R27, R42, R44, R55, R60,
R68, R70, R106, R115, R118, R119, R131
R140, R156, R157, R160, R161
F1, F5, F6
R3, R4, R7, R12, R13, R16-R18, R21, R46, R48,
R49, R52, R53, R57, R62, R103, R104, R107
R112, R113, R116, R133, R142
R-55e / July 2004
DESCRIPTION
FACEPLATE
25 PIN DB CONNECTOR
RIGHT ANGLE 25 PIN PC MOUNT CONNECTOR .318
3 PIN .098" PLUG FOR #26 AWG
6 PIN .098" PLUG FOR #26 AWG
26 PIN RIBBON PLUG
3 PIN .098" HEADER
6 PIN .098" HEADER
26 PIN PC MOUNT STRAIGHT UP SMT HEADER
74ACT74 TTL SMT Dual D-Type Pos-Edge-Triggered
Flip-Flop
LM675 POWER OP AMP
OP-275 DUAL LINEAR OP-AMP SMT
MMBTA55 PNP SMT TRANSISTOR
6.2V 1W ZENER DIODE
1N4002W RECTIFYING 1AMP SMT DIODE
5.1V SMT ZENER DIODE C5V1
1N4148 FAST SWITCHING SMT DIODE
SS14 SCHOTTKY SMT DIODE
74VHC4053 SMT Triple 2-Channel Analog Mux
CAPACITOR, 22µF 25V ELECTROLYTIC SMT
CAPACITOR, 100µF 25V ELECTROLYTIC SMT
CAPACITOR, 330µF 25V ELECTROLYTIC SMT
CAPACITOR, 1µF 35V ELECTROLYTIC SMT TANTALUM
CAPACITOR, 10pF 100V CERAMIC SMT
CAPACITOR, 10pF 100V CERAMIC SMT
CAPACITOR, 33pF 100V CERAMIC SMT
CAPACITOR, 330pF 100V CERAMIC SMT
CAPACITOR, .1µF 50V CERAMIC SMT
CAPACITOR, .1µF 50V CERAMIC SMT
CAPACITOR, .22µF 50V CERAMIC SMT
3.3 OHM 5% .25W MC1206 RESISTOR
10 OHM 5% .25W MC1206 RESISTOR
10 OHM 5% .25W MC1206 RESISTOR
47 OHM 5% .25W MC1206 RESISTOR
100 OHM 5% .25W MC1206 RESISTOR
100 OHM 5% .25W MC1206 RESISTOR
QTY W#
1 005537
1 200018
1 220120
1 230028
3 230031
1 250043
1 250062
3 250065
1 255003
3 305021
3 320007
13 325002
1 345002
1 350013
2 355001
2 355002
1 355003
1 355004
7 385001
32 405002
5 405003
2 405004
6 405005
20 415001
10 415001
3 415002
3 415004
18 415007
10 415007
3 415009
6 435001
17 435002
5 435002
3 435005
19 435007
5 435007
page 11 - 7
