HAND CRIMP TOOL WIRING INSTRUCTIONS

The supplied hand crimping tool (W/S#850067) is used for all I/O wiring con-
nections to and from the console. It is to be used with the supplied pin (figure 1)
intended for 22"-28" gauge wire.
(2) The terminal conductor tabs (pointing UP) are
placed in anvil 18-22; the terminal's insulation tabs
extend in front towards the camera.
(3) The stripped wire is placed into the terminal and
crimped. Note the wire's insulation must stop just
short of the conductor tabs (detail)
(4) Final step: jaws fully closed; the insulation tabs
have been crimped.
R-55e / July 2004
I N S T A L L A T I O N a n d P O W E R
INSULATION
(1) Pin crimp terminal
proper wire stripper, rotate one half turn, and
pull insulation off wire).
crimping tool fully open (engraved side toward
you) bring a terminal into position from the
unmarked side of the tool. Place the conductor
tabs (inner set as shown in figure 1) on the
"18-22" or "24-30" (depending on the wire) an-
vil (slightly curved surface) so that the circular
portion of the tabs rests in the curved surface
of the anvil and the two tabs face up into the
walls of the female jaw. The insulation tabs will
be flush with the top of the tool (figure 2).
of holding the terminal in position (figure 2).
lation is stopped by conductor tabs (figure 3).
CRIMP by squeezing handles until jaws are fully
closed (figure 4).
change is needed, you'll need to use an extrac-
tor tool to remove terminals (see next page).
connector are also supplied with the console.
CONDUCTOR
TABS
TABS
INSULATION
STOPS HERE
1) Strip wire approximately 3/16" (insert in
2) Leaving wire aside for the moment, with
3) Close tool very slightly, only to the point
4) Insert wire into terminal until wire insu-
5) If there is an insertion error or if a circuit
Note that metallized plastic hoods for each
