AudioArts Engineering audio console r-55e Technical Manual page 93

TMR-55e TIMER PARTS LIST (for 18-pos. frame)
ITEM#
Y1
DS8-DS11
CT7
CT2
U5
U4
U3
U1
Q11
Q12
Q9
Q10
Q1-Q8
D1
Z1
D2
D3, D4
Y1
C1, C41, C42
C6
C5
C13, C14
C27, C29, C31, C40
C2-C4, C7-C12, C15-C18, C21-C26, C28, C32-C39
C19, C30
J3, J4
R45
R57
R39, R40, R44, R48, R51, R53, R60, R64, R69, R80
R4, R7, R9, R11, R13, R15, R18, R21, R36, R37,
R58, R66, R71, R85
R1-R3, R6, R17, R20, R41-R43, R46, R47, R49,
R50, R52
R62, R65, R70, R77
R23, R25, R27, R29, R33, R34, R38, R61, R63, R68,
R75, R76, R78, R83, R84
R54, R73
R5, R8, R10, R12, R14, R16, R19, R22, R87
R24, R26, R28, R30-R32, R35, R67, R74, R79, R81,
R86, R88
R-55e / Sep 2004
DESCRIPTION
14 PIN .3" DIP SMT SOCKET
20 POSITION SNAP APART SOCKET, .1" SIL
40 PIN BREAKAWAY HEADER STRIPS, STRAIGHT .1" SIL
10PIN BOXED HEADER, STRAIGHT
DS1706RESA TTL SMT 3.3V MicroMonitor
DS1306E 32KHZ RTC SMT
XCF01SV020CE PROM
XC2S30_100 SPARTAN II GATE ARRAY smt
LT1117 3.3V 800mA REGULATOR SMT
LT1117 2.5V 800mA REGULATOR SMT
PQ05DZ11 5V 1A REGULATOR WITH ENABLE SMT T/R
MMBTA05 NPN SMT TRANSISTOR
FDN340P 2A P-CHANNEL FET SMT TRANSISTOR
1N4002W RECTIFYING 1AMP SMT DIODE
5.1V SMT ZENER DIODE C5V1
1N4148 FAST SWITCHING SMT DIODE
BAT54S SCHOTTKY SMT 2 SERIES DIODES 200mA
32.768 KHZ TEMPERATURE-COMPENSATED CRYSTAL
OSCILLATOR
150UF 10V TANTALUM CAPACITOR, SMT
CAPACITOR, 33pF 100V CERAMIC 0603 SMT
CAPACITOR, 330µF 35V MID/LOW ESR ELECTROLYTIC
SMT
CAPACITOR, 33pF 100V CERAMIC 0603 SMT
CAPACITOR, .01µF 50V CERAMIC 0603 SMT
CAPACITOR, .1µF 25V CERAMIC 0603 SMT
CAPACITOR, 220pF 100V CERAMIC 0603 SMT
0 OHM 5% .25W JUMPER-RESISTOR
1.0 MOHM 5% .25W MC1206 RESISTOR
5.1 OHM 5% 1/16W 0603 RESISTOR SMT
10.0 KOHM 1% 1/16W 0603 RESISTOR SMT
1.00 KOHM 1% 1/16W 0603 RESISTOR SMT
51 OHM 1% 1/16W 0603 RESISTOR SMT
33 OHM 1% 1/16W 0603 RESISTOR SMT
4.99 KOHM 1% 1/16W 0603 RESISTOR SMT
40.2 KOHM 1% 1/16W 0603 RESISTOR SMT
332 OHM 1% 1/16W 0603 RESISTOR SMT
220Ω 5% 0603 SMT RESISTOR
QTY W#
1 245002
2 250014
0.15 250016
1 250077
1 305054
1 305057
1 315077
1 315080
1 335004
1 335005
1 335011
1 345001
8 345005
1 355001
1 355002
1 355003
2 355006
1 370036
3 405008
1 405011
1 405014
2 415011
4 415012
28 415013
2 415015
2 430100
1 435049
1 435057
10 435060
14 435061
14 435062
4 435065
15 435067
2 435068
9 435070
13 435073
page 11 - 23
