User- and installation manual
Sirius
WARNING - THE COMBUSTION CHAMBER OF THIS
STOVE SHOULD ONLY BE OPENED AND SERVICED BY A
REGISTERED GAS INSTALLER
(i.e. GAS SAFE REGISTERED ENGINEER[GB])
These instructions should be left with the customer
for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sirius and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Element4 Sirius

Summary of Contents for Element4 Sirius

  • Page 1 User- and installation manual Sirius WARNING - THE COMBUSTION CHAMBER OF THIS STOVE SHOULD ONLY BE OPENED AND SERVICED BY A REGISTERED GAS INSTALLER (i.e. GAS SAFE REGISTERED ENGINEER[GB]) These instructions should be left with the customer for future reference...

  • Page 2: Table Of Contents

    Installing Remote Control Electronic Ignition System GV60............23 Arranging The Ceramic Fire-bed ....................24 Log Arrangements ......................24 Gravel Arrangements........................25 COMMISSIONING THE APPLIANCE ..................25 Installation tips..........................26 Installing gasfire Sirius ......................26 Servicing Instructions ........................28 Troubleshooting ...........................29 TECHNICAL INFORMATION......................31 Dimensions...........................31 Technical Details..........................32 Warranty ............................35...

  • Page 3: General Information

    GENERAL INFORMATION Important Safety Notice a registered gas installer be employed for this task. The engineer will provide you with informa- tion about the safety limits of the installation and This appliance has a ceramic Fire-bed arrange- should fix a notice plate in a place where it can ment;...

  • Page 4: General Fitting Information

    GENERAL INFORMATION ment of the Environment, the Building Standards If the appliance is to be fitted against a wall with (Scotland) (Consolidation) Regulations issued by combustible cladding, the cladding must be re- the Scottish Development Department. moved from the area covered, above and around. BS 5440 part 1, BS 5871 part 2 and BS 6891.

  • Page 5: User Information

    Remote control electronic ignition - temperature display in degrees Celsius or USER INFORMATION system RCE GV60 Fahrenheit; USER INFORMATION - time; - thermostat function; The appliance is supplied with a remote control. Remote control electronic ignition sys- - temperature display in degrees Celsius or Remote control electronic ignition - temperature display in degrees Celsius or - timer for thermostat function.
  • Page 6 USER INFORMATION USER INFORMATION USER INFORMATION MAN position I g n i t e t h e a p p l i a n c e f o l l o w s : MAN position I g n i t e t h e a p p l i a n c e a s f o l l o w s : MAN position I g n i t e t h e a p p l i a n c e a s f o l l o w s : By briefly pressing the SET button, you will go...
  • Page 7 USER INFORMATION Flame height / standby Time The flame height can be adjusted continuously by The display can indicate time. using the buttons After placing the battery or simultaneously press- (large flame) and By continuing to lower the flame height, the ap- pliance can be set to the standby position;...
  • Page 8 USER INFORMATION Example Timer for thermostat function By using the Y TEMP function you can keep the Using the timer enables you to set two times per day temperature at 20 °C; while 24 hours for switching on the day temperature you use the 4 TEMP function at night to maintain and two times per 24 hours for switching on the a temperature of 15 °C.
  • Page 9 USER INFORMATION Setting times for the timer Replacing the battery To set the timer, proceed as follows: If the battery is almost empty, the display will Set the day and night temperature as described show “BATT”. above Briefly press the SET button to enter the (P*) To replace the battery, proceed as follows: TIMER position.

  • Page 10: Installer Information

    INSTALLER INFORMATION Installation the supplier, thus the appliance must only be installed with the original flue system, no others Before beginning the installation, check that the may be used details on the rating plate correspond to the gas type and pressure to which the appliance will be The gas fire, in combination with the concentric connected.
  • Page 11 INSTALLER INFORMATION Basements,Lightwells and Retaining The appliance and Flue system should be fitted with a minimum clearance of 500mm from any walls combustible objects or materials, this includes any combustible materials used for the fireplace Flue terminals should not be sited within the con- construction.

  • Page 12: Terminal Locations Wall Mounting

    INSTALLER INFORMATION INSTALLER INFORMATION Terminal Locations Wall Mounting Terminal Locations Wall Mounting Dimension Terminal Position Distance (mm) Dimension Terminal Position Distance (mm) Directly below an opening,air brick, opening window etc. Directly below an opening,air brick, opening window etc. Above an opening,air brick, opening window etc. Above an opening,air brick, opening window etc.

  • Page 13: Terminal Locations Roof Termination

    INSTALLER INFORMATION Terminal Locations Roof Termination “Distance” = minimum distance required for positioning of the outlet to avoid adverse effects with respect to: A ventilation opening serving an occupied room, a toilet or a bathroom A heating air supply, when the supply flows through an occupied room. A window that can be opened and that is near an occupied room, a toilet or a bathroom.

  • Page 14: Concentric Flue Parts Identification

    INSTALLER INFORMATION Concentric Flue Parts Identification The following pages identify the parts that may be used in the Balanced Flue installation of this appliance. The Item number in the table refers to the item number of the part in the Identification pages, this Item number is also the number that will be used to identify parts in the Installation suggestion diagrams.
  • Page 15 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 16 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 17 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 18 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 19 INSTALLER INFORMATION INSTALLER INFORMATION USVK 100 130 REDUCER Ø130 - Ø100 USDHC 130 HORIZONTAL TERMINALØ130...
  • Page 20 INSTALLER INFORMATION INSTALLER INFORMATION USBI 100 130 Elbow 90° with inspection cover USI 100 130 Inspection Element...

  • Page 21: Rigid Balanced Flue Connection Possibilities

    Rigid Balanced Flue Connection Possibilities Horizontal Wall Termination Sirius has a rear back flue and can be installed directly with a wall terminal 200/130. In this situ- ation the maximum horizontal flue is 1.5 meter. When using a direct wall terminal it is important to fit the 60 mm flue restrictor across the flue outlet inside the fire.

  • Page 22: Vertical Roof Terminations

    INSTALLER INFORMATION INSTALLER INFORMATION Vertical Roof Terminations Vertical Roof Terminations When installing the appliance with a roof termination (classification 31) it is important to fit a flue When installing the appliance with a roof termination (classification 31) it is important to fit a flue restrictor across the flue outlet inside the fire.

  • Page 23: Installing Remote Control Electronic Ignition System Gv60

    INSTALLER INFORMATION INSTALLER INFORMATION Installing the controls Installing the controls Electronic Ignition System RCE GV60) Electronic Ignition System RCE GV60) This requires no external electrical power to This requires no external electrical power to operate. The receiver unit has only one lead. operate.

  • Page 24: Arranging The Ceramic Fire-Bed

    INSTALLER INFORMATION Log Arrangements - Sirius Only the ceramics supplied with this appliance are to be used. The ceramics must be laid only as shown on this page. Replacement parts are available from your dealer, but should only be installed by a qualified installation engineer.

  • Page 25: Gravel Arrangements

    Gravel Arrangements / Blackstones / Commissioning the appliance Brilliants INSTALLER INFORMATION Ensure that the Grate , is sitting firmly in the base A soundness test MUST be made before the of the fire box, with the long slot in the centre of installed stove is left with the customer.

  • Page 26: Installation Tips

    Installing gasfire Sirius The Sirius is delivered in a crate, which can be opened by taking out the 4 screws at the sides of the bottom of the crate. The top part of the crate can now be lifted easily.
  • Page 27 INSTALLER INFORMATION Installing the wall bracket: Installing the fire Determine the position for the flue and fix the Connect the fire to the gaspipe. Install the GV60 metal wall bracket to the wall with the flue remote control set and test the appliance.Now located in the center of the circular cut out.

  • Page 28: Servicing Instructions

    SERVICING INFORMATION SERVICING INFORMATION Troubleshooting Servicing instructions Troubleshooting Servicing instructions On the next pages you will find remedies for The following outlines only the minimum work that On the next pages you will find remedies for The following outlines only the minimum work problems which may accur when using fires should be performed on an annual basis.

  • Page 29: Troubleshooting

    TROUBLE SHOOTING "Problem” "Possible cause” "Remedy” A. No transmission 1. The (new) communication code 1. Hold down the reset button of the receiver, until you hear a long beep between receiver and remote control (motor will not run) . Let go of the reset button after the must still be confirmed.
  • Page 30 TROUBLE SHOOTING “Problem” “Possible cause” “Remedy” F. Electronics keep sparking while the 1. Receiver is damaged. 1. Replace the receiver and confirm the code pilot burner is ignited (remedy 1 at A) 1.1 Measure the voltage, using a 1. Thermocouple does not function. G.

  • Page 31: Technical Information

    TECHNICAL INFORMATION TECHNICAL INFORMATION Technical drawing Sirius Technical drawing Sirius...

  • Page 32: Technical Details

    TECHNICAL INFORMATION Countries of Destination The following table gives detail of the Countries that these appliances are approved for use within. The tables following immediately on give the technical characteristics of the appliances. Natural Austria I2H G20@20mbar ü Belgium I2E+ G20/G25@20/25mbar ü...
  • Page 33 TECHNICAL INFORMATION Austria ü I3B/P G30/G31@50mbar Belgium ü I3+ G30/G31@28-30/37mbar CH Switzerland ü I3B/P G30/G31@50mbar, I3+ G30/G31@28-30/37mbar CY Cyprus ü I3B/P G30/G31@30mbar Czech Republic ü I3B/P G30/G31@50mbar, I3+ G30/G31@28-30/37mbar DE Germany ü I3B/P G30/G31@50mbar DK Denmark ü I3B/P G30/G31@30mbar Estonia ü...
  • Page 34 Please carefully read and use this installation manual. Please carefully read and use this installation manual. We hereby declare that the design and construction of Element4’s atmospheric gas heating ap- We hereby declare that the design and construction of Element4’s atmospheric gas heating ap- pliance comply with the essential requirements of the Gas Appliance Directive.

  • Page 35: Warranty

    WARRANTY Warranty The warranty for your Element4 appliance will be provided by your supplier. In case of complaints, you must always contact him. Your supplier will contact Element4 if necessary. The factory warranty is valid for 24 months after date of purchase.
  • Page 36 Element4 B.V. Paxtonstraat 23 8013 RP Zwolle September 2014 The Netherlands...
