- Page 1 INSTALLATION MANUAL S U M M U M 1 4 0 P L E A S E L E AV E T H E S E I N ST R U CT I O N S B E H I N D W I T H T H E D E V I C E...
-
Page 3: Table Of Contents
Renovation/new construction Checking the gas lines 9 ELECTRICAL CIRCUIT Parts in the electrical circuit Domotica Modules Element4 ProControl App. 10 MAINTENANCE INSTRUCTION 10.1 Maintenance in the combustion chamber 10.2 Cleaning the glass 11 DECORATION ARRANGEMENT 12 EXPLANATION OF THE ADDITIONAL MODULES 12.1 Operation of the LED Module... -
Page 4: Ce Statement
This declaration loses its validity when changes to the device are Do not place any extra imitation logs or decoration material on made without the written permission by Element4. You can ask the burner or in the combustion chamber. See chapter 11 for an for a copy of the test certificates of all models via our general instruction on how to arrange the decoration properly. -
Page 5: Warranty
In case the installer is not able to fix the problem himself, a request can be made to Element4 to do it for him, as long as the service can be done within the borders of the Benelux. -
Page 6: Remote Control With Full Electronic Ignition
4 REMOTE CONTROL WITH FULL ELECTRONIC IGNITION 4.1) or the The unit is operated using a remote control (Fig. Element4 Puck, connected to a receiver (Fig. 4.2). The receiver is powered by 4 pen lite (type AA) batteries or a 6V adapter;... -
Page 7: Installation Preparation And - Instruction
85 C. Use the ventilation grate (CVRE4) and service hatch 5.4 Requirements flue and wall terminals (BDLE4) by Element4. See the measurements in APPENDIX I More on chimney construction in The European CE-marking for the device is only applicable to THE NEXT CHAPTER. -
Page 8: Fire Safe Installation
I N STA L L AT I O N M A N UA L 6 FIRE SAFE INSTALLATION To install a gas fireplace as safely as possible, several installation preparations need to be made. This overview can be used to assure the fire safety of a conversion of a fireplace. -
Page 9: Assembly Regulations With Flammable Materials
I N STA L L AT I O N M A N UA L 6.3 Assembly regulations with flammable materials (Figure 6.3 and 6.4) Load-bearing walls and ceilings must be covered in a protective fire resistant plate. Never use flammable materials around the fireplace or cove. The minimal distance between the device and non-flammable materials must be at 50 mm to ensure a convection air flow. -
Page 10: Chimney Construction For The Summum 140 4S
I N STA L L AT I O N M A N UA L 6.4 Chimney construction for the Summum 140 4S This instruction is intended for the Summum 140 4S and is a supplement to the general safety requirements for installing a gas fire, as mentioned in this manual. - Page 11 I N STA L L AT I O N M A N UA L Figure 6.6 - Verwijderen van de steunwanden Figure 6.7 - Verwijderen van de steunwanden Figure 6.8 - Inzetten van de glaswanden Figure 6.9 - Positie transportbouten...
- Page 12 I N STA L L AT I O N M A N UA L 6.4.1 Constructing the chimney Step 1: Make sure that the bottom of the fireplace is securely fixed to the floor and that it does not move away from its place for the rest of the installation.
- Page 13 I N STA L L AT I O N M A N UA L Figure 6.12 - Figure 6.13 - Align both the frames Adding vertical insert between the aligned frames Figure 6.14 - Figure 6.15 - Complete base of the frame (no crossbars) Final result of the suspension of the top of the fireplace...
- Page 14 I N STA L L AT I O N M A N UA L Step 4: Pack the construction with fire-resistant material, as indicated and the further desired finish (Figure 6.16). Bear CHAPTER 6.2 in mind that when the finishing materials are flammable, the insulation and air cavities used are suff icient.
-
Page 15: Attention Points Gas Flue
I N STA L L AT I O N M A N UA L 7 ATTENTION POINTS GAS FLUE 8 INSTALLATION CHECK AND FIRST USAGE 8.1 Renovation/new construction To guarantee the fire safety regarding you flue gas configuration a casing is necessary. For this case non-combustible materials should be used. -
Page 16: Electrical Circuit
The app has a user friendly, interactive layout and the design is Flat Burner adjusted for Element4 devices. Up to eight devices can be used First and second (long) logburner with one app, in the situation that multiple fire are installed in Third and fourth (short) logburner the same location. - Page 17 I N STA L L AT I O N M A N UA L (10) (10) MERTIK MAXITROL Receiver (11) RELAIS MODULE Figure 9.1 - Schematic Electronic Circuit...
-
Page 18: Maintenance Instruction
I N STA L L AT I O N M A N UA L 10 MAINTENANCE INSTRUCTION This part of the manual focuses on maintenance. To ensure the optimal flame picture of your device, an annual maintenance by a competent company or installer is prescribed. 10.1 Maintenance in the combustion chamber Depending on the configuration of the Summum 140, for example a front or corner model, the glass must be removed in... - Page 19 I N STA L L AT I O N M A N UA L Figure 10.2 - Remove side trims Figure 10.5 - Using the suction cup Figure 10.3 - Remove Lower Trims Figure 10.6 - Removing the suction cup Figure 10.4 - Removing Glass Cords Figure 10.7 - Removing side windows (when necessary)
- Page 20 I N STA L L AT I O N M A N UA L 10.1.3 (Dis)assembly of the trims for the Summum 140 RD & T (see image 10.8) For a tight finish of the fireplace, trims are available. During maintenance these trims must be removed, before the glass can be removed.
- Page 21 I N STA L L AT I O N M A N UA L Figure 10.9 - Remove side trims Figure 10.12 - Put on the suction cup Figure 10.10 - Remove bottom trim Figure 10.13 - Remove glass Figure 10.11 - Remove glass clamps...
-
Page 22: Cleaning The Glass
Use cleaning supplies qualified by Element4. Remove trims • When you clean your Anti-Reflective glass, make sure you use this with the special Element4 cleaner, which is available only via Element4. • Use only a microfibre cloth. Other materials such as kitchen towels, steel wool etcetera can cause scratches or damage the coating on the glass. - Page 23 I N STA L L AT I O N M A N UA L Figure 10.16 - Figure 10.17 - Remove glass clamps on the sides Put on the suction cups Figure 10.19 - Figure 10.18 - Removal of long side glass Take out long side glass...
- Page 24 I N STA L L AT I O N M A N UA L Figure 10.20 - Figure 10.21 - Remove glass clamps on the short side Put the suction cup on the short side Figure 10.22 - Figure 10.23 - Take out side glass Removal of short side glass...
- Page 25 I N STA L L AT I O N M A N UA L Figure 10.24 - Figure 10.25 - Removal of the top clamp of the glass panel in between Put on the suction cup (if necessary) Figure 10.26 - Figure 10.27 - Take out the inbetween glass Removal of the inbetween glass...
-
Page 26: Decoration Arrangement
I N STA L L AT I O N M A N UA L 11 DECORATION ARRANGEMENT Position the decoration logs as shown on the image below. Only the decoration ceramics supplied with this appliance are to be used. The ceramics must be laid only as shown on this page. Make sure that the pilot flame area and the second thermocouple Replacement parts are available from your dealer, but should are always free of any decorative material to make certain that... -
Page 27: Explanation Of The Additional Modules
9.1 electronics. See also for the connection diagram. The Summum fireplaces from Element4 are equipped with lighting under the burner grate. All fireplaces work with the same 10 button remote control (Figure 12.1). -
Page 28: Operation Of The Quadburner
I N STA L L AT I O N M A N UA L 12.2 Operation of the Quadburner The fireplaces of Element4 that are provided with a Quadburner come with the same remote control used by all other fireplaces (figure 12.1). -
Page 29: User Instruction
(sanding) sponges, abrasives and cleaning agents with ammonia is prohibited. Only use a neutral cleaning product 13.1 Hand over to the customer (neither acidic nor alkaline), such as Element4 window cleaner (Item No. 4500926). The cleaning agents that you normally use •... - Page 30 I N STA L L AT I O N M A N UA L...
- Page 31 I N STA L L AT I O N M A N UA L A P P E N D I C E S...
-
Page 32: A First Aid For Malfunction
A P P E N D I C E S A FIRST AID FOR MALFUNCTION Below you will find an overview of the possible cause and solution in the event of a failure. Problem Possible Cause Solution No transmission 1 Batteries in the receiver empty Replace the batteries (4x 1.5V AA) (motor will not 2 Batteries hand remote empty... - Page 33 A P P E N D I C E S 4,5 mV 4,5 mV 4,5 mV 4,5 mV Figure A-1: Bend pin Figure A-4: Testpoint A Figure A-5: interrupter Figure A-2: Antenna Figure A-6: Wiring receiver Figure A-7: Pilot set Figure A-3: Torx screw...
- Page 34 A P P E N D I C E S Problem Possible Cause Solution The pilot light goes 1 Insufficient voltage across the thermocouple or Place the measuring pins of the multimeter on the ground and on but goes out too much resistance in the thermocouple circuit black cable of the breaker.
- Page 35 A P P E N D I C E S Figure A.8: Second thermocouple Figure A.11: “Double plus”-button on the remote Figure A.9: Button A on “On” Figure A.13: SI-port Figure A.10: RESET-button Figure A.11: Aux-position receiver Figure A.14: Domotica system...
-
Page 36: B Errors Codes Procontrol App
A P P E N D I C E S B ERRORS CODES PROCONTROL APP B.1 Messages shown in app Error Message in App Description Possible cause code Contact Service. • 5 sec. beep from Receiver • Microswitch not making contact with cam on motor knob •... -
Page 37: Messages Shown In Remote
A P P E N D I C E S Error Message in App Description Possible cause code Contact Service. • Fire is not responding • Receiver or Wi-Fi Box malfunction • No electronic control of fire • Connection cable from Receiver to Wi-Fi Box defective Check Wi-Fi •... -
Page 38: C Faults And Error Codes In The Remote
A P P E N D I C E S C FAULTS AND ERROR CODES IN THE REMOTE This appendix can be consulted when error messages occur in the application for smartphone and tablet. C.1 F41 error This message will appear if there is no or bad Wi-Fi reception, this can be between app and router or Wi-Fi box and router By closing the App and opening it again, this is solved in most cases. -
Page 39: D Location Terminal
A P P E N D I C E S D LOCATION TERMINAL D.1 Terminal location with vertical exhaust (C11) D.2 Terminal location with Horizontal exhaust (C31) Distance Exhaust 1,2 of 3 Position terminal dist. (mm) At the same roof level >... -
Page 40: E General Rules For Flue Gas Extraction
A P P E N D I C E S E GENERAL RULES FOR FLUE GAS EXTRACTION E.1 Power-Fan For flue configurations that do not function on natural draft , the PowerFan can be used. For extensive installation instructions and the operation of the PowerFan we refer to the manual of the PowerFan. -
Page 41: F Calculation Table Flue Gas Reduction
A P P E N D I C E S F CALCULATION TABLE FLUE GAS REDUCTION The calculation table shows when you need to place a flue gas ristrictor Result Action No ristrictor required √ Position the resitrictor No good operation guaranteed * F.1 Horizontal terminal flue diameter 200/130 F.2 Vertical terminal flue diameter 200/130 For a vertical terminal the minimal starting length is 0,5 meter... -
Page 42: G Technical Data
A P P E N D I C E S G TECHNICAL DATA The dataplate specifies for which type of gas, gas pressure and for which country this appliance is intended. The nameplate is attached to a chain. It must remain attached to the chain. Note: Check whether the appliance is suitable for the gas type and gas pressure on site. -
Page 43: H Ecodesign
A P P E N D I C E S H ECODESIGN Since 1 January 2018 every fireplace has been provided with an eco-label which is always supplied with the fireplace. The ecolabel shows which category the fireplace belongs to. H.1 Ecolabels The ecolabels for the different types of gas are indicated below, respectively G20, G25 and G30. -
Page 44: I Dimensional Drawings
A P P E N D I C E S I DIMENSIONAL DRAWINGS On this page and the following ones you will find dimensional drawings of the Summum 140 model and accessories with some of the important dimensions that you have to take into account when installing and installing your fireplace. - Page 45 A P P E N D I C E S I.2 - Technical drawing of Summum 140 F...
- Page 46 A P P E N D I C E S I.3 - Technical drawing of Summum 140 C...
- Page 47 A P P E N D I C E S I.4 - Technical drawing of Summum 140 3S...
- Page 48 A P P E N D I C E S I.5 - Technical drawing of Summum 140 RD...
- Page 49 A P P E N D I C E S I.6 - Technical drawing of Summum 140 T...
- Page 50 A P P E N D I C E S 450,00 288,00 380,00 400,00 405,00 65,00 155,00 422,00 662,00 677,00 732,00 I.7 - Technical drawing of Summum 140 4S...
- Page 52 E L E M E N T 4 B .V. Paxtonstraat 23 8013 RP Zwolle The Netherlands Info@element4.nl www.element4fires.com R E L E A S E DAT E | 1 4 / 0 8 / 1 9...
