Convergent Design Odyssey7Q Setup Manual page 8

Configure Odyssey7Q RAW Recording
4
Make FS700 the Record Trigger
MENU » RECORD » TRIGGER » CAMERA
ODYSSEY SETUP
5
Set Timecode Source
MENU » INPUTS » TIMECODE » SOURCE » SDI
ODYSSEY SETUP
6
Format SSDs
MENU » ODYSSEY » SSD'S » FORMAT BOTH
second SSD drive installed.)
7
Connect to Camera and Verify Status Input
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey 7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
The status on your Odyssey7Q will display your camera's output.
Example:
Note: The recorded file will be RAW (.DNG) 2K or 4K.
2K up to 240fps, 4K up to 60fps (sustained) and 4K 100/120 (3-4 second bursts).
