Convergent Design Odyssey7Q Setup Manual page 14

Configure Odyssey7Q FS700 to Apple ProRes 422
1
Set Odyssey7Q to FS700 to Apple ProRes 422 Mode
MENU » SETUP » MONITOR --> RECORD » 4:2:2->PRORES HD (.MOV)
ODYSSEY
2
Set up Odyssey7Q for your FS700
MENU » SETUP » 4:2:2/4:4:4 SOURCE » SONY FS700
ODYSSEY
3
Make FS700 the Record Trigger
MENU » RECORD » TRIGGER » CAMERA
ODYSSEY
4
Set Timecode Source
MENU » INPUTS » TIMECODE » SOURCE » SDI
ODYSSEY
© 2014 Convergent Design, Inc. - All Rights Reserved.
SETUP RECORD INPUTS OUTPUTS
MONITOR --> RECORD
SETUP RECORD INPUTS OUTPUTS
MONITOR --> RECORD
4:2:2/4:4:4 SOURCE
SETUP RECORD INPUTS OUTPUTS
TRIGGER
REC BUTTON
CLIP
CAMERA
PROJECT
REMOTE
SETUP RECORD INPUTS
AUDIO
TIMECODE
4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
ARRI
CANON
PANASONIC
RED
SONY FS700
OUTPUTS
SOURCE
SDI
LTC
SEED/REC RUN
Note: If recording S-LOG2 use
Sony FS700 S-LOG2 setting
SONY FS700 (S-LOG2)
