Convergent Design Odyssey7Q Setup Manual page 13

Configure FS700 FS700 422 to Apple ProRes 422
1
Set up the FS700 for Recording
MENU » REC/OUT SET » REC SET » HD
Select any of the following frames rates that you wish to record on Odyssey7Q:
Note: 1080/60p, 1090/50p, 1080/100p, 1080/120p are not supported at this time.
2
Set up Record Trigger (FS700 Rec Button)
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI COMMAND » ON
3
Set up FS700 Output Resolution
MENU » REC/OUT SET » VIDEO OUT » SDI/HDMI/COMPONENT » 1080p/480p
4
Set up FS700 Output Frame Rate
MENU » REC/OUT SET » VIDEO OUT » 24/30p Output » 24p/30p
( Next Step: Configure Odyssey7Q for Apple ProRes 422 recording )
?
QUESTIONS or FEEDBACK? We're always available to help! Support@Convergent-Design.com
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ (720) 221-3861 | FAX: ++ (720) 227-9296 | Office Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: CDSupport@Convergent-Design.com | WEBSITE: www.Convergent-Design.com
NTSC
1080/24p
1080/30p
1080/60p
PAL
1080/25p
1080/50p
