Convergent Design Odyssey7Q Setup Manual page 7

Configure Odyssey7Q RAW Recording
1
Set Odyssey7Q to FS700 Mode
MENU » SETUP » MONITOR --> RECORD » FS700 RAW-->RAW (.DNG)
ODYSSEY
The unit will restart.
Note: When selected for the first time (or after an update) it may take up to
3 minutes to load.
2
Connect Odyssey7Q to FS700
Connect FS700 3G-SDI output to Odyssey7Q SDIA input
Note: Use only 3G-SDI rated cables from FS700 to Odyssey 7Q. Using a 1.5G
SDI cable in not recommended and may cause issues.
3
Set Date & Time to match FS700
MENU » ODYSSEY » SET » TIME
ODYSSEY
SET
ACTIVATION
SSD'S
TIME
ABOUT
DATE
MFG
RESET
MENU » ODYSSEY » SET » DATE
ODYSSEY
SET
ACTIVATION
SSD'S
TIME
ABOUT
DATE
MFG
RESET
( Continued on Next Page » )
Convergent Design, Inc.
4525 Northpark Dr. | Colorado Springs, CO 80918 | USA
TEL: ++ (720) 221-3861 | FAX: ++ (720) 227-9296 | Office Hours: 8:00 A.M. to 5:30 P.M., Monday – Friday [Mountain Time (GMT – 7)]
EMAIL: CDSupport@Convergent-Design.com | WEBSITE: www.Convergent-Design.com
SETUP RECORD INPUTS OUTPUTS
MONITOR --> RECORD
SETUP RECORD INPUTS OUTPUTS
▲
OK X
07:30:11
▼
SETUP RECORD INPUTS OUTPUTS
▲
2014 MAR 19
▼
4:2:2 -> PRORES HD (.MOV)
FS700 RAW -> RAW (.DNG)
CANON RAW -> RAW (.RMF)
ARRIRAW -> RAW (.ARI)
4:2:2/4:4:4 -> 4:4:4 (.DPX)
FS700 4K RAW -> PRORES HD (.MOV)
OK X
7
