Convergent Design Odyssey7Q Setup Manual page 4

Configure FS700 4K/2K RAW Recording
1
Set up the FS700 for RAW Recording
MENU » REC/OUT SET » REC SET » RAW SET
Select any of the following frames rates that you wish to record on Odyssey7Q:
Once the selection is made you will need to press EXEC on the
camera, to return to live / record.
2
Set Gamma (required for RAW recording)
PICTURE PROFILE » PP7 » SETTING » GAMMA » S-LOG2
PP7 is the default profile for S-LOG2, Note that only S-LOG2 is supported when
recording RAW.
Once the camera is set to the desired frame rate, then connect to the Odyssey 7Q
3
Set the S&Q button for Raw High Speed
MENU » OTHERS » S&Q BUTTON SET » 2K SUPER SLOW
NOTE: 4K Super slow is not supported on the Odyssey7Q; the camera only outputs a
maximum of 4K 60p, thus this mode will use internal buffering, and then will need to
playback the footage to an Odyssey7Q.
NOTE: For 2K up to 240fps sustained, or 4K up to 60p sustained, but 4K 100/120 7-8
second burst.
( Continued on Next Page » )
© 2014 Convergent Design, Inc. - All Rights Reserved.
NTSC
4096x2096/24p
4096x2096/30p
4096x2096/60p
2048x1080/24p
2048x1080/30p
2048x1080/60p
PAL
4096x2160/25p
4096x2160/50p
2048x1080/25p
2048x1080/50p
» REC Command » ON
(BACK)
4
